| Model NO.: | SZZG 936 | Condition: | New |
|---|---|---|---|
| Rated Load: | <1t | Transmission: | Hydraulic - Mechanical |
| Load And Unload Mode: | Front Discharge | Walking Mode: | Wheeled |
| Type: | Small Loader | Color: | Yellow |
| Engine: | Euro 5 Engine | Model: | Hangzhou Meite 816 |
| Rear Camera: | Valta Antifreeze Battery | Transport Package: | Naked |
| Specification: | 495 × 185 × 245cm | Trademark: | China Heavy Truck |
| Origin: | China | HS Code: | 8429590000 |
| Supply Ability: | 5000 | Package Size: | 495.00cm * 185.00cm * 245.00cm |
| Package Gross Weight: | 3900.000kg | Lead Time: | 15 Days (1 - 5 Pieces) To Be Negotiated ( > 5 Pieces) |
| After-sales Service: | 6 Months | Warranty: | 6 Months |
| Certification: | TUV, ISO, RoHS, CE | Customization: | Available | Customized Request |
| Shipping Cost : | About Shipping Cost And Estimated Delivery Time. | : | Initial Payment Full Payment |
| Currency: | US$ | Return&refunds: | You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
| Electronic control on joystick | Air condition |
| Hydraulic Line(per one more) | LED lights |
| Rear Video Camera | Varta Anti-Freeze Battery |
| Whole drive system | Hydraulic system(torque converter) | |
Specification | Overall weight(kg) | 3900 |
| L×W×H(mm) | 4950×1850×2450 | |
| Rated bucket capacity(m3) | 0.8-0.9 | |
| Rated load(kg) | 1600 | |
| Dump height (mm) | 2180 | |
| Dump distance(mm) | 510 | |
| Wheel base(mm) | 1500 | |
| Thread(mm) | 2280 | |
| Total time(s) | 8 | |
| Engine | Model | CHANGCHAI490 |
| Type | Direct injection, Horizontal, Water-cooled, Four stroke | |
| Rated power(KW) | 36.8 | |
| Rated speed(r/min) | 2400 | |
| Working system | Gearbox type | ZL-10 |
| Walking pump | ZK-240 | |
| Working pump (Double Pump) | CBQL-F532 | |
| Steering system | Max. turning angle | 45 |
| Min turning radius(mm) | 3600 | |
| Hydraulic system | Working pressure | 16Mpa |
| Boom lifting time | 4.8S | |
| Tank capacity | 45L | |
| Tires | Standard tires | 20.5-16 |
| Stand bucket | Width (mm) | 1800 |
