Experience unparalleled strength and reliability with the Sinotruk HOWO 8X4 12 Tires 380HP Heavy Duty Dump Truck. Expertly crafted for superior performance, this remarkable machine features an impressive 18-25cbm capacity, ensuring no task is too challenging. From rugged construction sites to demanding industrial environments, this truck stands as the ultimate solution for heavy-duty performance needs.
Product Description
Our versatile Dump Truck-also known as a Dumper Truck, Tipper Truck, or simply Tipper-meets all your heavy-duty hauling demands with exceptional efficiency. Whether transporting bulk materials or managing earthwork, this truck is designed to surpass expectations.
Constructed with meticulous precision, our dump trucks feature a robust chassis, an expansive tipping box, and a powerful hydraulic cylinder. Ideal for transporting sand, stone, gravel, and more, we offer various configurations, including 4x2, 6x4, and 8x4 models, ensuring a perfect match for your specific requirements.
Key Advantages of this Dump Truck:
1. Ideally suited for earthwork, gravel, bulk materials, and more;
2. Capable of precise angle dumping for efficient unloading, enhancing production efficiency;
3. Significantly lowers transportation costs;
4. Customizable designs to meet diverse customer needs, providing tailored solutions for your business.
Dump Truck Description:
The automatic tipping feature of the loading carriage facilitates unloading at specific angles, significantly saving time and labor. This capability shortens transportation cycles, boosts production efficiency, and reduces transportation costs. It is an essential vehicle for specialized transport tasks, transforming heavy-duty operations.
1. Appearance Classification: Single-axle dump truck, double-axle dump truck, flat-head dump truck, pointed-tip dump truck, front four-back eight dump truck, double-axle semi-trailer dump truck, three-axle semi-trailer dump truck.
2. Purpose Classification: Agricultural dump truck, mining dump truck, garbage dump truck, coal transportation dump truck, construction machinery dump truck, sludge dump truck.
3. Classification by Driving Mode: 6x4, 8x4 configurations, and semi-trailer dump trucks.
4. Use-based Classification: Mining dump trucks for coal, sand, and gravel; environmental sanitation and green dump trucks for garbage transport.
5. Directional Classification: Includes front lift and rollover dump trucks, and two-way side dump trucks primarily used in construction projects.
| Name | Howo Dump Tipper Truck |
| Types | Used |
| Load capacity | 25000kg |
| Horsepower | 8x4 |
| Horsepower | 380 |
| Gearbox type | FAST12JS160T |
| Emission Standards | Euro3 |
| Fuel | Diesel |
| Displacement | 9.726L |
| Size:Length * width * height | 8.5X2.6X3.6M |
| Total weight | 12100kg |
| Color | optional |
| Engine | WP10.340E32 |
| Fuel tank capacity | 380L |
| Number of springs | 10/12 |
| Power | 250KW |
| Number of tires | 10 |
| Tire specifications | 12.00R20 |
| Cabin | Flat |
| Production Year | 2013-2017 |
Main Specifications:
Driver's Cab(One sleeper with A/C)
| Model | HW76 Cab, with one sleeper beds, two seats, with A/C |
| Type | Forward control cab, hydraulically tiltable by 60o |
| Construction | Current standard all steel construction |
| Instrument panel | Clearly visible,indicators of compressed air pressure,
coolant temperature, engine oil pressure and battery
charging |
| Seats | 4-point support fully floating suspension + shock
absorbers driver adjustable & passenger fixed |
| Seat belts | For driver & passenger |
| Glass | Tempered safety glass |
| Sun visors | Dual, adjustable |
| Mirrors | Large, truck type convex |
| Wind screen wiper | 3 arm wind screen wiper system with 3 speeds |
| Entertainment system | FM/AM/SW, 4 band radio with cassette player, two speaker and antenna |
| Steering wheel | Adjustable steering wheel |
| Horn | Air horn |
| Panel | LCD Panel with LED light |
Engine
| Engine brand | SINOTRUK |
| Engine model | WD615.47, 380hp |
| Emission Standard | EURO III |
| Engine type | Diesel 4-stroke direct injection engine,
6-cylinder in-line
with water cooling, turbo-charging &
Inter-cooling |
| Displacement | 9.726 liters |
| Max. Output | 400hp@2200rpm |
| Max. torque | 1250Nm @1100-1600 rpm |
| Bore/Stroke | 126/130mm |
| Compression ratio | 17:1 |
| Specific fuel consumption | ≤193g/kW.h |
Cooling System
| Medium | Water |
| Radiator | heavy duty type |
| Cooling fan | Visco static fan tropical type |
| Thermostat | Opening at 70-80ºC |
| Warning device | Audible & visual |
Clutch
| Type | Φ430 Diaphragm type, Single dry frictional disc, Hydraulic boosting hydraulically operating with air assistance |
Transmission
| | Type | Heavy duty, manual fuller type |
| | Model | HW19712 |
| | No of speeds | 12 forward + 2 reverse |
| | |
| Model | Torque(Nm) | Gear Ratios | Oiling
(L) | |
| 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | R1 | R2 | |
| HW19710 | 1900 | 14.28 | 10.62 | 7.87 | 5.88 | 4.38 | 3.27 | 2.43 | 1.80 | 1.34 | 1.00 | 13.91 | 3.18 | 12 | |
| | | | | | | | | | | | | | | | | | |
Front Axle
| Type | HF9 tons steering with double T-cross section beam |
| Capacity | 9000kg |
Rear Axle
| Type | HC16(16 ton, punching-welding axle housing, double reduction driving axle, inter-wheel differential and differential lock) |
| Capacity | 16T |
Chassis
| Frame | Heavy duty, reinforced sub frame,
300mmx80mmx8mm
(inner: 280mmx70mmx7mm) |
| Front suspension | semi-elliptic leaf springs with hydraulic telescopic double-action
shock absorbers and stabilizer, 1500mm |
| Rear suspension | semi-elliptic springs ,and bogie springs, and stabilizer
, 1739mm |
Air Intake System
| Air cleaner type | Heavy duty type |
| Pre filter | Cyclone |
Exhaust System
| Capable of maintaining the sound level as low as possible. |
Steering
| Location | Left hand |
| Model | ZF 8098 (Made in Germany) hydraulic steering with power assistance |
| Variable ratios | 22.2-26.2, 17.0-20.0 |
| Max. pressure | 170+10 bar |
| Max. output torque | 7618 Nm |
| Weight | 42 kg |
Bumper
| Installed heavy duty front and rear steel bumpers |
Brake System
| Service brake | Dual circuit compressed air brake. |
| Parking brake | Spring energy, compressed air operating on rear wheels |
| Assistant brake | Engine exhaust valve brake |
Wheels & Tyres
| Wheels | Single front and dual rear |
| Tyres | Double Coin brand,12.00R20 |
| Quantity | 13 |
Air Supply System
| Warning device | Audible & visual |
| Air line | Heavy duty steel pipes |
Electrical System
| Operating Voltage | 24V, Negative grounded; Starter 24V, 7.5KW |
| Battery type | 2x12V, 165Ah/180Ah |
| Alternator | 28V, 1500W |
| Cigar | Lighter, horn, head lamps, fog lights, brake lights, indicators and reverse lamp |
Dimensions
| Wheel base | 4800mm+1350 |
| Overall length | 9775mm |
| Overall width | 2496mm |
| Overall height | 3730mm |
Cargo Body
| Internal Size | 6400x2300x1800mm |
| Thickness of body steel | Side 6mm & bottom 8mm |
| Tipping type | Front lift type with hydraulic system (HYVA hydraulic cylinder) |
| |
At Jining Huahang International Trade Co., Ltd., we take pride in exporting an extensive selection of premium new trucks, pre-owned trucks, cutting-edge construction machinery, and versatile semitrailers. With over 15 years of unrivaled prowess in trailer manufacturing and 8 years of distinguished marketing experience in the realm of used trucks and machinery, we have firmly established ourselves as a dependable and reputable partner in the heavy-duty vehicle industry.
At Jining Huahang International Trade Co., Ltd., our commitment to precision and excellence is evident in every vehicle. Prior to delivery, each vehicle undergoes a rigorous road test inspection executed by our experienced engineers to guarantee peak performance and steadfast reliability.
With our meticulously perfected vehicles, we confidently endorse the superior quality of our trucks and trailers. We proudly provide a Three-Month Warranty on all our products, a testament to their exceptional durability and performance. Our mission is encapsulated in our motto: 'Buy Easily, Service Assured.' Your utmost satisfaction is our highest pursuit.
Our extraordinary success is highlighted by the annual export of over 1,000 robust and reliable Heavy Duty HOWO 6X4 Dump Trucks to diverse African nations. This achievement exemplifies our unwavering commitment to delivering excellence and underscores our expansive global reach. Our ability to consistently provide durable and high-performance trucks has solidified our status as a trusted partner in the international market, particularly in Africa.
Prior to delivery, we meticulously inspect each Customized Color Sinotruk Heavy Duty Dump Truck Chassis, ensuring it aligns with our rigorous quality standards for exceptional reliability.
1. Thorough Engine Check: We guarantee the engine starts flawlessly, identify any potential oil leaks, and monitor emissions for black, blue, or white smoke, ensuring it performs at peak efficiency.
and adheres to the latest environmental standards.
2. Transmission Verification: We meticulously verify the precise positioning of transmission gears, ensuring smooth and proper engagement to provide a seamless and comfortable driving experience.
3. Axle Inspection: We rigorously inspect for any oil leaks, ensuring the axle operates efficiently and reliably during driving.
4. Frame Integrity: We conduct a detailed inspection of the frame for any signs of deformation, guaranteeing the truck's structural integrity and enduring durability.
5. Electrical Components Check: We ensure that all electrical components, including headlights and wipers, are fully operational, maximizing safety and visibility.
Thank You for Choosing Jining Huahang International Trade Co., Ltd.
Q: What is the usual delivery time for your products?
A: We pride ourselves on efficiency. For most trucks and machinery that we stock, delivery can be executed within just 7 days. However, items that are specially ordered will require a production lead time of approximately 30 days.
Q: What is your annual production capacity for trucks?
A: We have an impressive production capacity, manufacturing nearly 30,000 units annually. On a monthly basis, we update and roll out about 5,000 units.
Q: How do you maintain the quality standards of your products?
A: Our factory is a hallmark of excellence, equipped with state-of-the-art production workshops and staffed by highly skilled workers. Each product undergoes rigorous inspection procedures. Additionally, we recondition our trucks and machinery to meet the most stringent quality standards.
Q: Are custom orders accepted? What is the minimum order quantity (MOQ)?
A: Absolutely, we welcome custom orders. The minimum order quantity (MOQ) is remarkably low-just 1 unit. Explore Our Diverse Business Lines
