High Load Capacity 31-40t Customized Tractor with Air Suspension Seat Zz4257n3247e1h

Certification
China Jining Huahang International Trade Co., Ltd. certification
China Jining Huahang International Trade Co., Ltd. certification
I'm Online Chat Now

High Load Capacity 31-40t Customized Tractor with Air Suspension Seat Zz4257n3247e1h

High Load Capacity 31-40t Customized Tractor with Air Suspension Seat Zz4257n3247e1h
High Load Capacity 31-40t Customized Tractor with Air Suspension Seat Zz4257n3247e1h High Load Capacity 31-40t Customized Tractor with Air Suspension Seat Zz4257n3247e1h High Load Capacity 31-40t Customized Tractor with Air Suspension Seat Zz4257n3247e1h

Large Image :  High Load Capacity 31-40t Customized Tractor with Air Suspension Seat Zz4257n3247e1h

Product Details:
Certification: SGS
Payment & Shipping Terms:
Delivery Time: 7-15days

High Load Capacity 31-40t Customized Tractor with Air Suspension Seat Zz4257n3247e1h

Description
Model NO.: ZZ4257N3247E1H Drive Wheel: 6×4
Seats: ≤5 Horsepower: 351-450hp
Engine Capacity: >8L Tire Certification: ECE, GCC, ISO, DOT
Tire Design: Tubeless Condition: New
Usage: Towing Semi Trailer Fuel Tank: 400L, 600L, 1000L
Driver Seat: Air Suspension Seat Color: Customized
Cargo Box Material: Carbon Steel Steering System: Hydraulic Steering With Power Assistance
Transport Package: Nude Packing Specification: 6.8x2.5x3.8m
Trademark: Faw Origin: China
Supply Ability: 1000pieces/Year After-sales Service: 6 Months
Warranty: 6 Months Transmission Type: Manual
Power: CNG/Gas Load Capacity: 31-40t
Emission Standard: Euro 5 Customization: Available | Customized Request

Product Use

1. Definition of Tractor
A tractor is an exceptionally versatile light truck, expertly designed for towing a wide array of vehicles or objects along various roadways. Outfitted with one or more sets of wheels and axles, it plays an indispensable role in heavy-duty transport. Common applications include pulling semi-trailers, transporting luxury yachts, and moving construction machinery.
2. The Structure of the Tractor
A tractor typically comprises essential components like the engine, transmission, tires, and frame. For enhanced functionality and optimal control, it can also be outfitted with additional devices such as tow hooks, sophisticated locking systems, and advanced remote controls.
3. Tractor Application Fields
1. Transportation: Tractors are vital to the long-distance freight industry, adeptly towing semi-trailers and large trucks to ensure goods are delivered securely and punctually.
2. Construction Field: In the construction sector, tractors are indispensable, towing a variety of heavy machinery including excavators, bulldozers, and cranes, thus facilitating the efficient transport of essential equipment to job sites.

Basic Info.

Model NO. faw tractor   Displacement >8L
Gearbox Manual   Fuel Diesel
Braking System Other   Color Red
Road Conditions Road   Product Name FAW Tractor Changchun 6X4
Load Capacity 9800kg   Engine Ca60L2-35e3
Number of Springs 10   Power 279kw
Number of Tires 10   Year of Manufacture 2019
Max Speed 125km/H   Driving Cab Roof Flat
Transport Package Bulk   Specification 6800*2496*3450mm
Trademark Faw   Origin Shandong


Product Description

Customizable Zz4257n3247e1h Heavy Duty Tractor with Air Suspension SeatCustomizable Zz4257n3247e1h Heavy Duty Tractor with Air Suspension Seat
BRAND FAW Jiefang JH6 CNG
DRIVING TYPE 6x4
CABIN HIGH/TWO SLEEPER
Engine

WP13NG430E52

EMISSION STANDARDS Euro 5
HORSEPOWER 430HP
TIRE SPECIFCATIONS 12R22.5
OVERALL DIMENSIONS 7.415X2.495X3.91M
YEAR OF MANUFACTURE 2016-2017YEAR

Maximum speed

109KM/h
TRANSMISSION TYPE FAW Jiefang CA12TAX210M3

Customizable Zz4257n3247e1h Heavy Duty Tractor with Air Suspension Seat
Customizable Zz4257n3247e1h Heavy Duty Tractor with Air Suspension Seat

Customizable Zz4257n3247e1h Heavy Duty Tractor with Air Suspension Seat
Product Details

Customizable Zz4257n3247e1h Heavy Duty Tractor with Air Suspension SeatCustomizable Zz4257n3247e1h Heavy Duty Tractor with Air Suspension SeatCustomizable Zz4257n3247e1h Heavy Duty Tractor with Air Suspension SeatCustomizable Zz4257n3247e1h Heavy Duty Tractor with Air Suspension Seat

Product Description

Faw Jiefang JH6 (430HP) CNG tractor parameter information
The basic information Announcement model: CA4250P25K27T1E5M1 Drive form: 6X4
The wheelbase: 3800 + 1350 mm Engine: Weichai WP13NG430E52
Transmission: FAW Jiefang CA12TAX210M5 Rear axle speed ratio: 4.1
Body length/Width/Height: 7.445*2.495*3.85 (m)
Front wheel base: 2020mm Rear wheel base: 1830/1830mm
Weight: 10.03 tons Total mass: 25 tons
Total traction mass: 38.775 tons Maximum speed: 109km/h
Version: CNG version Market segment: Transport of dangerous goods
Origin: Qingdao/Chengdu Tonnage level: heavy truck
Engine parameter Engine model: Weichai WP13NG430E52 Engine brand: Weichai
Cylinder number: 6 Fuel type: LIQUEFIED natural gas (CNG)12 cylinders
Cylinder arrangement: in - line Capacity: 12.54 L
Emission standard: National 5 Maximum horsepower: 430 horsepower
Maximum output power: 316kW Maximum torque: 2000N·m
Maximum torque speed: 1100-1400RPM Rated speed: 1900RPM
Bridge parameters Cab: High top Cab suspension: four point air bag suspension
Number of passengers: 3 Number of rows: Half
Cab lift: electric
Transmission parameters Gearbox model: FAW Jiefang CA12TAX210M5 Gearbox brand: FAW Jiefang
Shell material: aluminum alloy Shift mode: manual
Forward gear: 12 gears Reverse gear: 1
The chassis parametersrs Frame size: 300×80×8mm Suspension form: leaf spring
Front axle Description: 2020 front axle Rear Axle Description: 457 Upgraded blanking bridge
Allowable load of front axle: 7000kg Rear axle allowable load: 18000(two axle group)kg
Ratio: 4.1 Number of spring pieces: 3/4 Saddle: Yost 90 traction disc
tire Tires: 10 Tyre size: 12R22.5
Manipulation of the configuration ABS anti-lock: standard
External configuration Aluminum alloy gas storage tank: standard
The internal configuration Multi-function steering wheel: standard Air conditioning mode: automatic
Electric Windows: standard Electric rearview mirror: standard


Our Factory
Customizable Zz4257n3247e1h Heavy Duty Tractor with Air Suspension Seat


Shipment

We typically ship our trucks via RO-RO vessels or bulk vessels. For added convenience, we also offer special container shipping options.
Customizable Zz4257n3247e1h Heavy Duty Tractor with Air Suspension Seat


Original Spare Parts
We offer original spare parts supported by a comprehensive after-sales service system. Our After-market Division excels in service delivery, leveraging an efficient supply chain to ensure prompt parts distribution and ultimate customer satisfaction.

Our Product
Customizable Zz4257n3247e1h Heavy Duty Tractor with Air Suspension Seat
Thank You for Choosing Us
Q: How about the delivery time?
A: For in-stock trucks and machinery, delivery is within 7 days. Special orders generally require around 30 days for production.

Q: How many units of trucks do you produce per year?
A: We manufacture nearly 30,000 units annually, with around 5,000 units updated each month.

Q: How do you control the quality of your products?
A: Our factory features a state-of-the-art production workshop, manned by a highly skilled workforce. Each product undergoes an exhaustive inspection process to ensure excellence. We meticulously recondition our trucks and machinery on a specialized production line.

Q: Do you accept custom orders? What is your MOQ?
A: Yes, we accept custom orders. Our minimum order quantity (MOQ) is just 1 unit.
