Experience the epitome of power and reliability with the Shacman X3000 Sinotruk HOWO 6X4 10 Tires 371HP Heavy Duty Dump Truck. Designed for superior performance, this formidable machine features an impressive 18-25cbm capacity, ensuring effortless management of any substantial task. Built to conquer the toughest of challenges, this truck stands as a testament to unmatched engineering excellence.
Product Description
Our adaptable Dump Truck-also referred to as a Dumper Truck, Tipper Truck, or simply Tipper-is intricately constructed to fulfill all your heavy-duty hauling needs with unparalleled efficiency.
Meticulously engineered for superior performance, these dump trucks boast a durable chassis, a spacious tipping box, and a powerful hydraulic cylinder. Ideal for transporting sand, stone, gravel, and more. As a leading supplier, we provide a variety of configurations including 4x2, 6x4, and 8x4 models, precisely tailored to meet your distinct requirements.
Advantages of this dump truck include:
1. Perfect for earthwork, gravel, and bulk materials.
2. Boosted production efficiency with a precise unloading angle.
3. Significant transportation cost reductions.
4. Customizable designs to cater to diverse customer needs.
Dump Truck Description:
The loading carriage automatically tips over at a specific angle for unloading, dramatically reducing unloading time and labor. This accelerates the transportation cycle, enhances production efficiency, and cuts down costs. As such, it is a highly popular special transport vehicle.
1. By appearance: Single-axle, double-axle, flat-head, pointed tip, front four-back eight, double-axle semi-trailer, and three-axle semi-trailer dump trucks.
2. By purpose: Agricultural, mining, garbage, coal transportation, construction machinery, and sludge dump trucks.
3. By driving modes: 6x4, 8x4 for unloading, and semi-trailer dump trucks.
4. By use: Mining dump trucks for coal, sand, and gravel; environmental sanitation and green dump trucks for garbage transportation.
5. By car rollover direction: Front lift, rollover dump trucks, and two-way side dump trucks, mainly used in construction projects.
| Name | Shacman Dump Tipper Truck |
| Types | Used |
| Load capacity | 25000kg |
| Horsepower | 8x4 |
| Horsepower | 400 |
| Gearbox type | FAST12JS160T |
| Emission Standards | Euro3 |
| Fuel | Diesel |
| Displacement | 9.726L |
| Size:Length * width * height | 8.5X2.6X3.6M |
| Total weight | 12100kg |
| Color | optional |
| Engine | WP10.340E32 |
| Fuel tank capacity | 400L |
| Number of springs | 10/12 |
| Power | 250KW |
| Number of tires | 10 |
| Tire specifications | 12.00R20 |
| Cabin | Flat |
| Production Year | 2013-2017 |
Main Specifications:
Driver's Cab(Single sleeper with A/C)
| Model | Shacman X3000 Cab, with one sleeper beds, two seats, with A/C |
| Type | Forward control cab, hydraulically tiltable by 60o |
| Construction | Current standard all steel construction |
| Instrument panel | Clearly visible,indicators of compressed air pressure,
coolant temperature, engine oil pressure and battery
charging |
| Seats | 4-point support fully floating suspension + shock
absorbers driver adjustable & passenger fixed |
| Seat belts | For driver & passenger |
| Glass | Tempered safety glass |
| Sun visors | Dual, adjustable |
| Mirrors | Large, truck type convex |
| Wind screen wiper | 3 arm wind screen wiper system with 3 speeds |
| Entertainment system | FM/AM/SW, 4 band radio with cassette player, two speaker and antenna |
| Steering wheel | Adjustable steering wheel |
| Horn | Air horn |
| Panel | LCD Panel with LED light |
Engine
| Engine brand | SHACMAN |
| Engine model | WD615.47, 380hp |
| Emission Standard | EURO III |
| Engine type | Diesel 4-stroke direct injection engine,
6-cylinder in-line
with water cooling, turbo-charging &
Inter-cooling |
| Displacement | 9.726 liters |
| Max. Output | 400hp@2200rpm |
| Max. torque | 1250Nm @1100-1600 rpm |
| Bore/Stroke | 126/130mm |
| Compression ratio | 17:1 |
| Specific fuel consumption | ≤193g/kW.h |
Cooling System
| Medium | Water |
| Radiator | heavy duty type |
| Cooling fan | Visco static fan tropical type |
| Thermostat | Opening at 70-80ºC |
| Warning device | Audible & visual |
Clutch
| Type | Φ430 Diaphragm type, Single dry frictional disc, Hydraulic boosting hydraulically operating with air assistance |
Transmission
| | Type | Heavy duty, manual fuller type |
| | Model | HW19712 |
| | No of speeds | 12 forward + 2 reverse |
| | |
| Model | Torque(Nm) | Gear Ratios | Oiling
(L) | |
| 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | R1 | R2 | |
| HW19710 | 1900 | 14.28 | 10.62 | 7.87 | 5.88 | 4.38 | 3.27 | 2.43 | 1.80 | 1.34 | 1.00 | 13.91 | 3.18 | 12 | |
| | | | | | | | | | | | | | | | | | |
Front Axle
| Type | HF9 tons steering with double T-cross section beam |
| Capacity | 9000kg |
Rear Axle
| Type | HC16(16 ton, punching-welding axle housing, double reduction driving axle, inter-wheel differential and differential lock) |
| Capacity | 16T |
Chassis
| Frame | Heavy duty, reinforced sub frame,
300mmx80mmx8mm
(inner: 280mmx70mmx7mm) |
| Front suspension | semi-elliptic leaf springs with hydraulic telescopic double-action
shock absorbers and stabilizer, 1500mm |
| Rear suspension | semi-elliptic springs ,and bogie springs, and stabilizer
, 1739mm |
Air Intake System
| Air cleaner type | Heavy duty type |
| Pre filter | Cyclone |
Exhaust System
| Capable of maintaining the sound level as low as possible. |
Steering
| Location | Left hand |
| Model | ZF 8098 (Made in Germany) hydraulic steering with power assistance |
| Variable ratios | 22.2-26.2, 17.0-20.0 |
| Max. pressure | 170+10 bar |
| Max. output torque | 7618 Nm |
| Weight | 42 kg |
Bumper
| Installed heavy duty front and rear steel bumpers |
Brake System
| Service brake | Dual circuit compressed air brake. |
| Parking brake | Spring energy, compressed air operating on rear wheels |
| Assistant brake | Engine exhaust valve brake |
Wheels & Tyres
| Wheels | Single front and dual rear |
| Tyres | Double Coin brand,12.00R20 |
| Quantity | 13 |
Air Supply System
| Warning device | Audible & visual |
| Air line | Heavy duty steel pipes |
Electrical System
| Operating Voltage | 24V, Negative grounded; Starter 24V, 7.5KW |
| Battery type | 2x12V, 165Ah/180Ah |
| Alternator | 28V, 1500W |
| Cigar | Lighter, horn, head lamps, fog lights, brake lights, indicators and reverse lamp |
Dimensions
| Wheel base | 4800mm+1350 |
| Overall length | 9775mm |
| Overall width | 2496mm |
| Overall height | 3730mm |
Cargo Body
| Internal Size | 8200x2300x1800mm |
| Thickness of body steel | Side 6mm & bottom 8mm |
| Tipping type | Front lift type with hydraulic system (HYVA hydraulic cylinder) |
| |
Jining Huahang International Trade Co., Ltd. shines as a distinguished leader in the export of both new and pre-owned trucks, construction machinery, and semitrailers. With over 15 years of unparalleled expertise in trailer manufacturing and 8 years of marketing excellence in pre-owned trucks and machinery, we have forged a reputation built on unwavering trust and exceptional performance.
At Jining Huahang International Trade Co., Ltd., our unwavering attention to detail sets us apart from the competition. Each vehicle undergoes a rigorous road test inspection by our seasoned engineers before delivery, ensuring that our esteemed customers receive only the highest quality products.
With an impeccably refined fleet of vehicles, we stand firmly behind the superior quality of our trucks and trailers. We proudly offer a Three-Month Comprehensive Warranty on all our products. Our mission, 'Buy Easily, Service Assured,' reflects our steadfast dedication to customer satisfaction, which remains our topmost priority.
Our exceptional track record speaks volumes of our unwavering dedication! Each year, we pride ourselves on successfully exporting over 1,000 Sinotruk Chassis Used Tipper Trucks to a diverse range of African nations. This extraordinary accomplishment underscores our unparalleled commitment to delivering quality, reliability, and excellence in heavy-duty transportation solutions. Our remarkable achievements not only meet but consistently surpass industry standards, ensuring we exceed the diverse needs of our global clientele with unmatched service and superior products.
At Jining Huahang International Trade Co., Ltd., we leave no stone unturned to ensure perfection. Our Shacman Sinotruk FAW Heavy Duty Dump Trucks undergo an exhaustive and meticulous inspection protocol before reaching your hands. Each truck chassis is scrutinized to guarantee exceptional quality and unparalleled performance, ensuring your complete satisfaction with every purchase.
1. Engine: We guarantee flawless engine starts by meticulously inspecting for any signs of oil leakage and performing rigorous emissions tests. We diligently check for black smoke, blue smoke, and white smoke, ensuring all emissions comply with our stringent environmental standards.
We meticulously inspect for black smoke, blue smoke, and white smoke, ensuring all emissions comply with our stringent environmental standards.
2. Transmission: Our thorough verification process ensures the accuracy of each transmission gear position, guaranteeing seamless gear shifting and optimal performance under diverse driving conditions.
3. Axle: We conduct exhaustive inspections for oil leakage and smooth driving performance, ensuring a hassle-free and smooth driving experience.
4. Frame: Detailed checks for any deformities in the frame are conducted, ensuring the structural integrity and safety of our trucks.
5. Additional Checks: All headlights and wipers are rigorously tested for full functionality, providing you with utmost confidence and peace of mind on every journey.
Thank you for selecting Jining Huahang International Trade Co., Ltd. - Your Reliable Partner in Heavy Duty Dump Truck Chassis Sale.
Q: How about the delivery time?
A: We take immense pride in our efficiency. Most of our trucks and machinery are readily available in stock and can be dispatched within an impressive 7-day window. For specially ordered items, the production timeline is approximately 30 days, ensuring complete customization to meet your exact requirements.
Q: How many units of trucks do you handle per year?
A: We are proud to manage nearly 30,000 units annually, with an extraordinary turnover rate of 5,000 units per month. This showcases our expansive capacity and steadfast reliability in the market.
Q: How do you ensure the quality of your products?
A: Our factory boasts a state-of-the-art production workshop staffed by highly skilled workers. Every product undergoes a meticulous inspection process. All our trucks and machinery are meticulously reconditioned by professionals, assuring you of the highest quality standards.
Q: Do you accept custom orders? What is your minimum order quantity (MOQ)?
A: Absolutely! We accommodate custom orders tailored precisely to your specifications. Our minimum order quantity (MOQ) is a mere 1 unit, providing utmost convenience for all our clients.
