| Model NO.: | DUMP TRUCK | Drive Wheel: | 6×4 |
|---|---|---|---|
| Engine Capacity: | 4-6L | Seats: | ≤5 |
| Horsepower: | 351-450hp | Tire Certification: | ISO |
| Tire Design: | Tubeless | Dumping Type: | Front Lifting Style |
| Condition: | Used | Tyre: | New |
| Steering System: | Hydraulic Steering With Power Assistance | Chassis Brand: | Sinotruk Chassis |
| Color: | Customized | Cab: | Air Conditioner |
| Cargo Box Material: | Carbon Steel | Electric System: | Battery:2X12V/165ah; Alternator:28V-1500 Kw; Sta |
| Transport Package: | Naked Packing | Specification: | 8.5x2.6x3.6m |
| Trademark: | FAW | Origin: | China |
| HS Code: | 870423009 | Supply Ability: | 10000pieces/Year |
| After-sales Service: | 6 Months | Warranty: | 6 Months |
| Transmission Type: | Manual | Power: | Diesel |
| Load Capacity: | 21-30t | Emission Standard: | Euro 3 |
| Customization: | Available | Customized Request |
| driver license: | A1,A2,B2 | Announcement Model: | ZZ3257W414HF1 |
| Drive type: | 6X4 | Wheelbase: | 4100+1400mm |
| engine: | Weichai WP13.510E62 | Gearbox: | Sinotruk HW25712XSJ |
| Rear axle ratio: | 5.26 | Body length: | 8.915m |
| Body width: | 2.55 m | Ride height: | 3.45 m |
| Front track: | 2041mm | Rear track: | 1860/1860mm |
| Vehicle weight: | 12.5 tons | Rated load: | 12.37 tons |
| Total mass: | 25 tons | Tonnage level: | Heavy Truck |
| Approach Angle: | 16 degrees | Departure angle: | 20 degrees |
| Origin: | Shandong Jinan | Market segments: | Urban construction waste |
| Remark: | Optional: 12.3-inch full HD central control screen, 360-degree surround view; | Overall speed ratio: | 5.26 |
| Fuel Type: | diesel fuel | | |
| engine model: | Weichai WP13.510E62 | Engine Brand: | Weichai |
| Number of cylinders: | 6 cylinders | Fuel type: | diesel fuel |
| Displacement: | 12.54L | Emission Standards: | National VI |
| Maximum horsepower: | 510 hp | Maximum output power: | 375kW |
| Maximum Torque: | 2400N·m | Maximum torque speed: | 950-1400rpm |
| Rated speed: | 1900rpm | Engine Type: | CR+DOC+DPF+Hi_SCR |
| Length of cargo box: | 6 meters | Cargo box width: | 2.35 m |
| Cargo box height: | 1.5 m | Cargo box form: | Self-unloading |
| Gearbox Model: | Sinotruk HW25712XSJ | Gearbox brand: | Sinotruk |
| Forward gears: | 12 gears | Reverse gear number: | 2 |
| Frame size: | 8+8mm | Permissible load on front axle: | 7000kg |
| Rear Axle Description: | MCP16ZG | Permissible load on rear axle: | 18000(two-axle group)kg |
| Speed ratio: | 5.26 | Number of springs: | 10/12 |
| Tire specifications: | 12.00R20 | Number of tires: | 10 |
Our exceptional track record is a testament to our unwavering dedication! Each year, we triumphantly export over 1,000 Sinotruk Chassis Used Tipper Trucks to a multitude of African nations. This impressive feat underscores our unparalleled commitment to quality, reliability, and excellence in heavy-duty transportation solutions. Our remarkable achievements consistently surpass industry standards, ensuring we exceed the diverse needs of our global clientele with unparalleled service and superior products.
