Model NO.: | 6x4 Dump Truck | Drive Wheel: | 6×4 |
---|---|---|---|
Engine Capacity: | 4-6L | Seats: | ≤5 |
Horsepower: | 351-450hp | Tire Certification: | ISO |
Tire Design: | Tubeless | Dumping Type: | Front Lifting Style |
Condition: | Used | Tyre: | New |
Steering System: | Hydraulic Steering With Power Assistance | Chassis Brand: | Sinotruk Chassis |
Color: | Customized | Cab: | Air Conditioner |
Cargo Box Material: | Carbon Steel | Electric System: | Battery:2X12V/165ah; Alternator:28V-1500 Kw; Sta |
Transport Package: | Naked Packing | Specification: | 7.27x2.55x3.5m |
Trademark: | Howo | Origin: | China Liangshan |
HS Code: | 870423009 | Supply Ability: | 10000pieces/Year |
After-sales Service: | 6 Months | Warranty: | 6 Months |
Transmission Type: | Manual | Power: | Diesel |
Load Capacity: | 21-30t | Emission Standard: | Euro6 |
Customization: | Available | Customized Request |
driver license: | A1,A2,B2 | Announcement Model: | ZZ3257V364GF1 |
Drive type: | 6X4 | Wheelbase: | 3625+1350mm |
engine: | Sinotruk MC11.43-61 | Gearbox: | Sinotruk HW19712CL |
Rear axle ratio: | 5.92 | Body length: | 7.275 m |
Body width: | 2.55 m | Ride height: | 3.55 m |
Front track: | 2020mm | Rear track: | 1860/1860mm |
Vehicle weight: | 12.5 tons | Rated load: | 12.37 tons |
Total mass: | 25 tons | Tonnage level: | Heavy Truck |
Approach Angle: | 17 degrees | Departure angle: | 32 degrees |
Origin: | Shandong Jinan | Market segments: | Urban construction waste |
Fuel Type: | diesel fuel | | |
engine model: | Sinotruk MC11.43-61 | Engine Brand: | Sinotruk |
Number of cylinders: | 6 cylinders | Fuel type: | diesel fuel |
Displacement: | 10.518L | Emission Standards: | National VI |
Maximum horsepower: | 430 hp | Maximum output power: | 319kW |
Rated speed: | 1900rpm | Engine Type: | Inline six-cylinder, water-cooled, four-stroke, supercharged, intercooled, high-pressure common rail |
Length of cargo box: | 5 meters | Cargo box width: | 2.35 m |
Cargo box height: | 1.2 meters | Cargo box form: | Self-unloading |
Gearbox Model: | Sinotruk HW19712CL | Gearbox brand: | Sinotruk |
Forward gears: | 12 gears | Number of downs: | 2 |
Frame size: | 8+5/300mm | Front axle description: | VPD75 |
Permissible load on front axle: | 7000kg | Rear Axle Description: | MAT16ZG |
Permissible load on rear axle: | 18000(two-axle group)kg | Speed ratio: | 5.92 |
Number of springs: | 11/11/12 | | |
Tire specifications: | 12.00R20 16PR | Number of tires: | 10 |
We have successfully exported our product to African countries, achieving a remarkable milestone of over 1,000 trucks per year.
Contact Person: Mr. Liu
Tel: +86 13153796988
