| Model NO.: | Shacman X5000 | Power: | Diesel |
|---|---|---|---|
| Load Capacity: | 31-40t | Emission Standard: | Euro 3 |
| Drive Wheel: | 6×4 | Seats: | ≤5 |
| Horsepower: | ＞450hp | Engine Capacity: | ＞8L |
| Tire Certification: | ECE, GCC, ISO, DOT | Tire Design: | Tubeless |
| Condition: | New | Usage: | Towing Semi Trailer |
| Fuel Tank: | 400L, 600L, 1000L | Driver Seat: | Air Suspension Seat |
| Color: | Red | Cargo Box Material: | Carbon Steel |
| Steering System: | Hydraulic Steering With Power Assistance | Transport Package: | Nude Packing |
| Specification: | 7.86x2.55x3.7m | Trademark: | SHACMAN |
| Origin: | China Liangshan | HS Code: | 8708991000 |
| Supply Ability: | 1000pieces/Year | Package Size: | 7500.00cm * 255.00cm * 370.00cm |
| Package Gross Weight: | 8800.000kg | After-sales Service: | 6 Months |
| Warranty: | 6 Months | Transmission Type: | Automatic |
| Customization: | Available | Customized Request | Shipping Cost : | About Shipping Cost And Estimated Delivery Time. |
| : | Initial Payment Full Payment | Currency: | US$ |
| Return&refunds: | You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
| driver license: | A2 | Announcement Model: | SX4259XD4TLQ1 |
| Drive type: | 6X4 | Wheelbase: | 3775+1400mm |
| engine: | Weichai WP13NG460E61 | Gearbox: | Fast C12JSDQXL260 |
| Rear axle ratio: | 3.7 | Body length: | 7.86 m |
| Body width: | 2.55 m | Ride height: | 3.7 m |
| Front track: | 2036mm | Rear track: | 1860/1860mm |
| Vehicle weight: | 8.8 tons | Total mass: | 25 tons |
| Total traction mass: | 40 tons | Maximum speed: | 110km/h |
| Market segments: | Logistics distribution | Origin: | Xi'an, Shaanxi |
| Tonnage level: | Heavy Truck | Fuel Type: | Liquefied Natural Gas (LNG) |
| engine model: | Weichai WP13NG460E61 | Engine Brand: | Weichai |
| Number of cylinders: | 6 cylinders | Fuel type: | Liquefied Natural Gas (LNG) |
| Cylinder arrangement: | In-line | Displacement: | 12.54L |
| Emission Standards: | National VI | Maximum horsepower: | 460 hp |
| Maximum output power: | 338kW | Maximum Torque: | 2300N·m |
| Maximum torque speed: | 1100-1500rpm | Rated speed: | 1900rpm |
| Technical route: | LNG | | |
| Cab: | High Top | Cab suspension: | Four-point airbag suspension |
| Number of passengers allowed: | 3 people | Number of Seat Rows: | Half row |
| Gearbox Model: | Fast C12JSDQXL260 | Gearbox brand: | Fast |
| Shifting method: | Manual | Forward gears: | 12 gears |
| Reverse gear number: | 2 | | |
| Fuel tank capacity: | 1350L | | |
| Rear Axle Description: | 11.5T MAN single-stage reduction axle | Permissible load on front axle: | 7000kg |
| Permissible load on rear axle: | 18000(two-axle group)kg | Speed ratio: | 3.7 |
| Number of springs: | 2/3 | Saddle: | Yost 90 Lightweight |
| Number of tires: | 10 | Tire specifications: | 12R22.5 18PR |
