Model NO.: | 6x4 Dump Truck | Power: | Diesel |
---|---|---|---|
Load Capacity: | 21-30t | Emission Standard: | Euro 5 |
Drive Wheel: | 6×4 | Engine Capacity: | 4-6L |
Seats: | ≤5 | Horsepower: | 351-450hp |
Tire Certification: | ECE, GCC, ISO, DOT | Tire Design: | Tubeless |
Dumping Type: | Front Lifting Style | Condition: | Used |
Tyre: | New | Steering System: | Hydraulic Steering With Power Assistance |
Chassis Brand: | Sinotruk Chassis | Color: | Customized |
Cab: | Air Conditioner | Cargo Box Material: | Carbon Steel |
Electric System: | Battery:2X12V/165ah; Alternator:28V-1500 Kw; Sta | Transport Package: | Naked Packing |
Specification: | 6.92x2.6x3.2m | Trademark: | Sinotruk |
Origin: | China Liangshan | HS Code: | 870423009 |
Supply Ability: | 10000pieces/Year | Package Size: | 692.00cm * 260.00cm * 320.00cm |
Package Gross Weight: | 88700.000kg | After-sales Service: | 6 Months |
Warranty: | 6 Months | Transmission Type: | Manual |
Customization: | Available | Customized Request | Shipping Cost : | About Shipping Cost And Estimated Delivery Time. |
: | Initial Payment Full Payment | Currency: | US$ |
Return&refunds: | You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
driver license: | A2 | Announcement Model: | XGA4250D6WC |
Drive type: | 6X4 | Wheelbase: | 3400+1350mm |
engine: | Weichai WP13.550E62 | Gearbox: | Fast C12JSDQXL240T |
Rear axle ratio: | 2.846 | Body length: | 6.92 m |
Body width: | 2.55 m | Ride height: | 3.12 m |
Front track: | 2020mm | Rear track: | 1860/1860mm |
Vehicle weight: | 8.87 tons | Total mass: | 25 tons |
Total traction mass: | 40 tons | Maximum speed: | 90km/h |
Market segments: | Logistics distribution | Origin: | Xuzhou Jiangsu |
Tonnage level: | Heavy Truck | Remark: | The speed ratio can be selected as 3.364/3.7, and the head-up display system (HUD), front vehicle collision avoidance and track departure warning system (FCWS/LDWS), xenon headlights, and leather seats are optional. |
Fuel Type: | diesel fuel | | |
engine model: | Weichai WP13.550E62 | Engine Brand: | Weichai |
Number of cylinders: | 6 cylinders | Fuel type: | diesel fuel |
Cylinder arrangement: | series | Displacement: | 12.54L |
Emission Standards: | National VI | Maximum horsepower: | 550 hp |
Maximum output power: | 405kW | Maximum Torque: | 2550N·m |
Maximum torque speed: | 950-1400rpm | Rated speed: | 1900rpm |
Cab: | High Top | Cab suspension: | Four-point airbag suspension |
Number of passengers allowed: | 2 people | Number of Seat Rows: | Half row |
Cab lift: | electric | Driver's seat type: | Airbag shock absorbing seat |
Skylight: | Manual sunroof | | |
Gearbox Model: | Fast C12JSDQXL240T | Gearbox brand: | Fast |
Shifting method: | Manual | Forward gears: | 12 gears |
Number of downs: | 2 | | |
Fuel tank capacity: | 1100L | | |
Frame size: | 300×80×8mm | Front axle description: | 6.5T |
Rear Axle Description: | 469 | Permissible load on front axle: | 7000kg |
Permissible load on rear axle: | 18000(two-axle group)kg | Speed ratio: | 2.846 |
Number of springs: | 2/- | Saddle: | 90# |
Number of tires: | 10 | Tire specifications: | 12R22.5 |
We have achieved remarkable success by exporting over 1,000 of our top-tier Shacman Cargo Trucks annually to various African countries. This stands as a testament to the unparalleled reliability and exceptional performance of our vehicles. Our success in these diverse markets underscores the trust and satisfaction of our customers, driven by the superior quality and durability that our Shacman Cargo Trucks consistently deliver. We take immense pride in our commitment to excellence, ensuring that each vehicle meets the highest standards of performance and reliability, making them the preferred choice for businesses across the region.
