| Model NO.: | ZZ4257N3247E1H | Power: | Diesel |
|---|---|---|---|
| Load Capacity: | 31-40t | Emission Standard: | Euro 5 |
| Drive Wheel: | 6×4 | Seats: | ≤5 |
| Horsepower: | >450hp | Engine Capacity: | >8L |
| Tire Certification: | ECE, GCC, ISO, DOT | Tire Design: | Tubeless |
| Condition: | New | Usage: | Towing Semi Trailer |
| Fuel Tank: | 400L, 600L, 1000L | Driver Seat: | Air Suspension Seat |
| Color: | Customized | Cargo Box Material: | Carbon Steel |
| Steering System: | Hydraulic Steering With Power Assistance | Transport Package: | Nude Packing |
| Specification: | 6.91x2.55x3.96m | Trademark: | SITRAK |
| Origin: | China Shandong | HS Code: | 8708991000 |
| Supply Ability: | 1000pieces/Year | Package Size: | 691.00cm * 255.00cm * 396.00cm |
| Package Gross Weight: | 8800.000kg | After-sales Service: | 6 Months |
| Warranty: | 6 Months | Transmission Type: | Automatic |
| Customization: | Available | Customized Request | Shipping Cost : | About Shipping Cost And Estimated Delivery Time. |
| : | Initial Payment Full Payment | Currency: | US$ |
| Return&refunds: | You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
| Basic Information | |||
| Announcement Model | ZZ4256V323HE1B | ||
| Manufacturing Origin | Zhangqiu, Shandong | ||
| type | |||
| Drive type | 6X2 | ||
| Wheelbase(mm) | 3200+1400mm | ||
| Body length | 6.91 m | ||
| Body width | 2.55 m | ||
| Ride height | 3.96 m | ||
| Total traction mass | 37.2 tons | ||
| Maximum speed | 101km/h | ||
| Minimum turning diameter | |||
| Remark | |||
| Engine parameters | |||
| engine model | Sinotruk MC13.54-50 | ||
| Cylinder arrangement | |||
| Fuel Type | |||
| Number of cylinders | 6 | ||
| Emission Standards | |||
| Displacement(L) | 12.419L | ||
| Horsepower (ps) | 540 hp | ||
| Output power(kw) | 397kW | ||
| Torque(N·m) | 2500N·m | ||
| Maximum power speed (rpm) | |||
| Maximum torque speed (rpm) | 1050-1350rpm | ||
| Gearbox parameters | |||
| Gearbox | ZF ZF16S2530TO | ||
| Output torque | |||
| Gear shifting method | Manual | ||
| Reverse gear number | 2 | ||
| Cab parameters | |||
| Cab | |||
| Number of passengers allowed | 3 people | ||
| Number of Seat Rows | Half row | ||
| Interior | |||
| tank | |||
| Fuel tank/gas tank material | Aluminum Alloy | ||
| Fuel tank/gas tank capacity (L) | 860L | ||
| Chassis | |||
| Chassis model | |||
| Frame | TGAmm | ||
| Braking System | |||
| Front axle description | |||
| Front axle allowable load (T) | 6500kg | ||
| Rear Axle Description | MCY13JES | ||
| Rear axle allowable load (T) | 18500(two-axle group)kg | ||
| Rear axle ratio | |||
| Suspension form | |||
| Number of springs | 3/-/- | ||
| Remark | |||
| tire | |||
| Number of tires | 10 | ||
| Tire specifications | 295/80R22.5,12R22.5 | ||
Contact Person: Mr. Liu
Tel: +86 13153796988
