Model NO.: | ZZ4257N3247E1H | Power: | Diesel |
---|---|---|---|
Load Capacity: | 31-40t | Emission Standard: | Euro 5 |
Drive Wheel: | 8×4 | Seats: | ≤5 |
Horsepower: | >450hp | Engine Capacity: | >8L |
Tire Certification: | ECE, GCC, ISO, DOT | Tire Design: | Tubeless |
Condition: | New | Usage: | Towing Semi Trailer |
Fuel Tank: | 400L, 600L, 1000L | Driver Seat: | Air Suspension Seat |
Color: | Customized | Cargo Box Material: | Carbon Steel |
Steering System: | Hydraulic Steering With Power Assistance | Transport Package: | Nude Packing |
Specification: | 6.8x2.5x3.8m | Trademark: | Sinotruk |
Origin: | China Shandong | HS Code: | 8708991000 |
Supply Ability: | 1000pieces/Year | Package Size: | 120.00cm * 255.00cm * 398.00cm |
Package Gross Weight: | 15500.000kg | Lead Time: | 15 Days (1 - 5 Pieces) To Be Negotiated ( > 5 Pieces) |
After-sales Service: | 6 Months | Warranty: | 6 Months |
Transmission Type: | Manual | Customization: | Available | Customized Request |
Shipping Cost : | About Shipping Cost And Estimated Delivery Time. | : | Initial Payment Full Payment |
Currency: | US$ | Return&refunds: | You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
Announcement Model: | ZZ5316CCYV466HF1B | type: | Saddle Truck |
Drive type: | 8X4 | Wheelbase: | 1950+4600+1400mm |
Box length level: | 9.5 m | engine: | Sinotruk MC11.46-61 |
Gearbox: | Sinotruk HW25712XSTCL | Rear axle ratio: | 3.7 |
Body length: | 11.99 m | Body width: | 2.55 m |
Ride height: | 3.98 m | Front track: | 2022/2022mm |
Rear track: | 1830/1830mm | Vehicle weight: | 15.5 tons |
Rated load: | 15.37 tons | Total mass: | 31 tons |
Maximum speed: | 89KM/h | Origin: | Zhangqiu, Shandong |
Tonnage level: | Heavy trucks | driver license: | A1,A2,B2 |
Approach Angle: | 19 degrees | Departure angle: | 18 degrees |
Front overhang/rear overhang: | 1.492/2.548m | Fuel Type: | diesel fuel |
engine model: | Sinotruk MC11.46-61 | Engine Brand: | Sinotruk |
Engine common name: | Sinotruk MC11 | Number of cylinders: | 6 cylinders |
Fuel type: | diesel fuel | Cylinder arrangement: | series |
Displacement: | 10.518L | Emission Standards: | National VI |
Maximum output power: | 338kw | Maximum horsepower: | 460 hp |
Maximum Torque: | 2200N·m | Maximum torque speed: | 1000-1400RPM |
Rated speed: | 1900RPM | Engine Type: | Inline six-cylinder, water-cooled, four-stroke, supercharged, intercooled, high-pressure common rail |
Cargo box form: | Barn type | Length of cargo box: | 9.52 m |
Cargo box width: | 2.45 m | | |
Cab width: | 2440mm | Number of passengers allowed: | 3 people |
Number of Seat Rows: | Half row | | |
Gearbox Model: | Sinotruk HW25712XSTCL | Gearbox brand: | Sinotruk |
Shifting method: | Manual | Forward gears: | 12 gears |
Number of downs: | 2 | | |
Fuel tank capacity: | 1000L | | |
Permissible load on front axle: | 6500/7000KG | Permissible load on rear axle: | 17500(two-axis group)KG |
Speed ratio: | 3.7 | Number of springs: | 3/3/4 |
Tire specifications: | 12R22.5 18PR | Number of tires: | 12 |
ABS anti-lock braking system: | | | |
