| Model NO.: | 4x2 Dump Truck | Power: | Diesel |
|---|---|---|---|
| Load Capacity: | 21-30t | Emission Standard: | Euro 3 |
| Drive Wheel: | 4×2 | Engine Capacity: | 4-6L |
| Seats: | ≤5 | Horsepower: | 351-450hp |
| Tire Certification: | ISO | Tire Design: | Tubeless |
| Dumping Type: | Front Lifting Style | Condition: | Used |
| Tyre: | New | Steering System: | Hydraulic Steering With Power Assistance |
| Chassis Brand: | Sinotruk Chassis | Color: | Blue |
| Cab: | Air Conditioner | Cargo Box Material: | Carbon Steel |
| Electric System: | Battery:2X12V/165ah; Alternator:28V-1500 Kw; Sta | Transport Package: | Naked Packing |
| Specification: | 5.995x2.6x2.57m | Trademark: | Fukuda |
| Origin: | China Liangshan | HS Code: | 870423009 |
| Supply Ability: | 10000pieces/Year | Package Size: | 599.00cm * 260.00cm * 257.00cm |
| Package Gross Weight: | 4500.000kg | After-sales Service: | 6 Months |
| Warranty: | 6 Months | Transmission Type: | Manual |
| Customization: | Available | Customized Request | Shipping Cost : | About Shipping Cost And Estimated Delivery Time. |
| : | Initial Payment Full Payment | Currency: | US$ |
| Return&refunds: | You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
| driver license: | A1,A2,B2 | Announcement Model: | BJ3103DGJEA-FB |
| Drive type: | 4X2 | Wheelbase: | 3460mm |
| engine: | Yuchai YC4S160-50 | Gearbox: | Fast 8JS75TE |
| Body length: | 5.995m | Body width: | 2.55 m |
| Ride height: | 2.57 m | Front track: | 1795mm |
| Rear track: | 1800mm | Vehicle weight: | 5.3 tons |
| Rated load: | 4.505 tons | Total mass: | 10 tons |
| Tonnage level: | Light Truck | Approach Angle: | 20 degrees |
| Departure angle: | 19 degrees | Origin: | Zhucheng, Shandong |
| Market segments: | Engineering transportation | Remark: | Power steering, clutch assist, optional air conditioning, metallic paint, electric doors and windows |
| Fuel Type: | diesel fuel | | |
| engine model: | Yuchai YC4S160-50 | Engine Brand: | Yuchai |
| Number of cylinders: | 4 cylinders | Fuel type: | diesel fuel |
| Displacement: | 3.767L | Emission Standards: | National Five |
| Maximum horsepower: | 160 hp | Maximum output power: | 118kW |
| Maximum Torque: | 550N·m | Maximum torque speed: | 1300-1800rpm |
| Rated speed: | 2600rpm | Engine Type: | Vertical, in-line, water-cooled, four-stroke |
| Length of cargo box: | 4.15 m | Cargo box width: | 2.35 m |
| Cargo box height: | 0.8m | Cargo box form: | Self-unloading |
| Cab: | ES3 | Cab width: | 2060mm |
| Gearbox Model: | Fast 8JS75TE | Gearbox brand: | Fast |
| Forward gears: | 8 gears | Number of downs: | 2 |
| Permissible load on front axle: | 1700kg | Rear Axle Description: | 1093Z |
| Permissible load on rear axle: | 2590kg | Number of springs: | 10/12+9,10/10+9,10/11+8,8/10+6 |
| Tire specifications: | 8.25-16 6PR,8.25R16 6PR | Number of tires: | 6 |
