| Model NO.: | ZZ4257N3247E1H | Power: | Diesel |
|---|---|---|---|
| Load Capacity: | 31-40t | Emission Standard: | Euro 5 |
| Drive Wheel: | 6×4 | Seats: | ≤5 |
| Horsepower: | >450hp | Engine Capacity: | >8L |
| Tire Certification: | ECE, GCC, ISO, DOT | Tire Design: | Tubeless |
| Condition: | New | Usage: | Towing Semi Trailer |
| Fuel Tank: | 400L, 600L, 1000L | Driver Seat: | Air Suspension Seat |
| Color: | Customized | Cargo Box Material: | Carbon Steel |
| Steering System: | Hydraulic Steering With Power Assistance | Transport Package: | Nude Packing |
| Specification: | 6.96x2.5x3.8m | Trademark: | Auman |
| Origin: | China | HS Code: | 8708991000 |
| Supply Ability: | 1000pieces/Year | Package Size: | 696.00cm * 260.00cm * 380.00cm |
| Package Gross Weight: | 8500.000kg | Lead Time: | 10 Days (1 - 5 Pieces) To Be Negotiated ( > 5 Pieces) |
| After-sales Service: | 6 Months | Warranty: | 6 Months |
| Transmission Type: | Manual | Customization: | Available | Customized Request |
| Shipping Cost : | About Shipping Cost And Estimated Delivery Time. | : | Initial Payment Full Payment |
| Currency: | US$ | Return&refunds: | You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
| driver license: | A2 | Announcement Model: | BJ4259Y6DHL-12 |
| Drive type: | 6X4 | Wheelbase: | 3300+1350mm |
| engine: | Foton Cummins X13NS6B520 | Gearbox: | ZF 12TX2621TD |
| Rear axle ratio: | 2.643 | Body length: | 6.965m |
| Body width: | 2.525 m | Ride height: | 3.73 m |
| Front track: | 2020mm | Rear track: | 1865/1865mm |
| Vehicle weight: | 8.5 tons | Total mass: | 25 tons |
| Total traction mass: | 40 tons | Maximum speed: | 89km/h |
| Origin: | Beijing Huairou | Tonnage level: | Heavy Truck |
| Version: | Supreme Edition | Fuel Type: | diesel fuel |
| engine model: | Foton Cummins X13NS6B520 | Engine Brand: | Foton Cummins |
| Number of cylinders: | 6 cylinders | Fuel type: | diesel fuel |
| Cylinder arrangement: | series | Displacement: | 12.9L |
| Emission Standards: | National VI | Maximum horsepower: | 520 hp |
| Maximum output power: | 382kW | Maximum torque speed: | 1000-1400rpm |
| Rated speed: | 1800rpm | | |
| Number of passengers allowed: | 2 people | Number of Seat Rows: | Half row |
| Cab width: | 2490mm | | |
| Gearbox Model: | ZF 12TX2621TD | Gearbox brand: | ZF |
| Shifting method: | AMT | Forward gears: | 12 gears |
| Number of downs: | 4 | | |
| Fuel tank/gas tank material: | Aluminum Alloy | Fuel tank capacity: | 760+300L |
| Fuel tank heating: | | | |
| Permissible load on front axle: | 7000kg | Permissible load on rear axle: | 18000(two-axle group)kg |
| Speed ratio: | 2.643 | Number of springs: | 2/3 |
| clutch: | Φ430 | Suspension type (front/rear): | Leaf spring suspension |
| Saddle: | 90# | | |
| Number of tires: | 10 | Tire specifications: | 12R22.5 18PR |
