Model NO.: | ZZ1257N3647N1 | Power: | Diesel |
---|---|---|---|
Load Capacity: | 31-40t | Emission Standard: | Euro 5 |
Drive Wheel: | 6×4 | Engine Capacity: | >8L |
Seats: | ≤5 | Horsepower: | 351-450hp |
Tire Certification: | ECE, GCC, ISO, DOT | Tire Design: | Tubeless |
Dumping Type: | Front Lifting Style | Condition: | New |
Tyre: | New | Steering System: | Hydraulic Steering With Power Assistance |
Chassis Brand: | Sinotruk Chassis | Color: | Customized |
Cargo Box Material: | Carbon Steel | Transport Package: | Naked Packing |
Specification: | 11m*2.55m*3.45m | Trademark: | Sinotruk |
Origin: | Shandong China | HS Code: | 8708991000 |
Supply Ability: | 1000pieces/Year | Package Size: | 700.00cm * 250.00cm * 345.00cm |
Package Gross Weight: | 7500.000kg | After-sales Service: | 6 Months |
Warranty: | 6 Months | Transmission Type: | Manual |
Customization: | Available | Customized Request | Shipping Cost : | About Shipping Cost And Estimated Delivery Time. |
: | Initial Payment Full Payment | Currency: | US$ |
Return&refunds: | You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
Product Description |
Model | ZZ3257N3447A1 GCW40000kgs | |
Engine | Engine model | WD615.69, Euro II emission standard, 4 stroke injection diesel engine, 6 cylinder in-line with water cooling, turbo-charging & inter cooling, mechanical high pressure oil pump system |
Maximum output | 336PS (247kW) at 2200 rpm | |
Maximum torque | 1350Nm at 1100-1600rpm | |
Bore | 126mm Stroke: 130mm | |
Displacement | 9.726L | |
Compression ratio | 17.5:1 | |
Specific fuel consumption | ≤198g/kWh | |
Engine oil filling quantity | 23L | |
Air compressors | WABCO Twin cylinders air compressors; | |
Cooling system filling quantity (long-term filling) | 40L | |
Clutch | SINOTRUK's 430C diaphragm spring clutch, hydraulically operating with air assistance | |
Transmission | Transmission, model HW19710, 10 forward and 2 reverse Ratio:14.28; 10.62; 7.87; 5.88; 4.38; 3.27; 2.43; 1.80; 1.34; 1.00; 13.91/3.18(R) | |
Propeller Shaft | Double universal joint propeller shaft with gear-shaped coupling flange | |
Front Axle | New HF9 series, with drum brake system Steering with double T-cross section beam | |
Rear Axle | HC16 pressed axle housing, single reduction and differential locks between axles; with drum brake system. Ratio: 5.73 | |
Chassis | Frame: | High-strength U-profile frame, all cold riveted cross members and reinforced subframe |
Front suspension: | semi-elliptic leaf springs with hydraulic telescopic double-action shock absorbers and stabilizer | |
Rear suspension: | semi-elliptic leaf springs and bogie springs | |
Spare wheel carrier: | with one spare wheel | |
Steering | ZF8098, hydraulic steering with power assistance Ratio: 22.2-26.2:1 | |
Braking System | Front and rear drum brake, four-circuit protection valve | |
Service brake | dual circuit compressed air brake | |
Parking Brake | spring energy, compressed air operating on rear wheels | |
Auxiliary brake | engine exhaust brake | |
Wheel & Types | Rims | 8.5-20,10 hole-steel |
Types | 12.00R20, 12.00R22.5, 315/80R22.5, 12.00-20 |
Jining Huahang International Trade Co., Ltd. stands as a distinguished titan in the realm of exporting both new and pre-owned trucks, construction machinery, and semitrailers. With a remarkable history spanning 15 years in trailer manufacturing and 8 years in the specialized marketing of used trucks and machinery, our name embodies trust and unparalleled reliability.
At Jining Huahang International Trade Co., Ltd., we pride ourselves on meticulous precision. Each vehicle undergoes an exhaustive road test inspection conducted by our expert engineers prior to delivery, guaranteeing that only the highest quality reaches our discerning clientele.
With an impeccably maintained fleet, we pledge exceptional quality in our trucks and trailers. We offer a comprehensive SIX-Month Warranty on all our products. Our guiding principle, 'Buy Easily, Service Assured,' epitomizes our unwavering commitment to customer satisfaction, which remains our highest priority.
