Model NO.: | ZZ1257N3647N1 | Power: | Diesel |
---|---|---|---|
Load Capacity: | 31-40t | Emission Standard: | Euro 5 |
Drive Wheel: | 6×4 | Engine Capacity: | >8L |
Seats: | ≤5 | Horsepower: | 351-450hp |
Tire Certification: | ECE, GCC, ISO, DOT | Tire Design: | Tubeless |
Dumping Type: | Front Lifting Style | Condition: | New |
Tyre: | New | Steering System: | Hydraulic Steering With Power Assistance |
Chassis Brand: | Sinotruk Chassis | Color: | Customized |
Cargo Box Material: | Carbon Steel | Transport Package: | Naked Packing |
Specification: | 11m*2.55m*3.45m | Trademark: | SANY |
Origin: | Shandong China | HS Code: | 8708991000 |
Supply Ability: | 1000pieces/Year | Package Size: | 700.00cm * 250.00cm * 345.00cm |
Package Gross Weight: | 7500.000kg | After-sales Service: | 6 Months |
Warranty: | 6 Months | Transmission Type: | Manual |
Customization: | Available | Customized Request | Shipping Cost : | About Shipping Cost And Estimated Delivery Time. |
: | Initial Payment Full Payment | Currency: | US$ |
Return&refunds: | You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
Overall dimensions | 6995,6965×2545×3700, 3840,3910,3950(mm) | Rated load capacity | |
Gross Vehicle Weight | 25000(Kg) | ABS | standard configuration |
Curb weight(kg) | 10500(Kg) | Front/rear suspension | 1510/735,1510/760(mm) |
Trailer weight(kg) | 38370(Kg) | Half-hung saddle | 16,005,160,701,675,500,000 |
Approach/departure angle | 18/37(°) | Front and rear Axle Load | 7000/18000 |
Wheelbase | 3300+1400(mm) | Number of axles | 3 |
Maximum speed | 89(km/h) | Number of spring pieces | 2/3,2/4,3/4,3/5,9/10,10/12 |
Number of tires | 10 | Tire Size | 12R22.5 18PR,12.00R2016PR |
Front track | 2078(mm) | Rear track | 1860/1860(mm) |
Engine | |||
Engine model | Displacement (ML) | Power (kw)/ horsepower (PS) | Fuel |
D13C6-480E0 | 12940 | 353/480 | 353/480 |
D13C6-500E0 | 12940 | 368/500 | 368/500 |
D13C6-520E0 | 12940 | 382/519 | 382/519 |
D13C6-560E0 | 12940 | 412/560 | 412/560 |
D13C6-520E3 | 12940 | 382/519 | 382/519 |
D13C6-560E3 | 12940 | 412/560 | 412/560 |
D13C6-480E3 | 12940 | 353/480 | 353/480 |
D13C6-500E3 | 12940 | 368/500 | 368/500 |
Main Specifications:(Configuration can be tailored to perfectly align with your unique requirements and preferences)
Wheelbase | 3225+1350 mm | |
Track | Track front | 2022 mm |
Track rear | 1830 mm | |
Cab | F3000 cab, 4-point full floating air suspension, adjustable steering wheel with various heights and angles, air suspension seat, central door lock, electric window lifter, power mirror | |
Clutch | 430 diaphragm spring clutch | |
Gear box | HW19710 | |
Front axle | HF9 drum, rated loading 90000KG | |
Rear axle | HC16 Double reduction driving axle | |
Tire | 12.00-20 bias tire | |
Brae system | With ABS system | |
Frame | High-strength single U-profile frame with a section of 300*90*8 | |
Electrical system | 24V, CAN bus intellectual electronic control system |
Jining Huahang International Trade Co., Ltd. stands as a beacon of excellence in the realm of exporting new and used trucks, construction machinery, and semitrailers. With a remarkable 15-year history in trailer manufacturing coupled with 8 years of expertise in marketing pre-owned trucks and machinery, our company has cemented its reputation as a symbol of trust and unwavering reliability.
At Jining Huahang International Trade Co., Ltd., our commitment to quality is uncompromising. Each vehicle undergoes a rigorous and comprehensive road test inspection by our highly experienced engineers prior to delivery. This ensures that only the highest standards of quality reach our valued customers.
Maintaining an impeccably serviced fleet, we guarantee the exceptional quality of our trucks and trailers. We confidently offer an extensive SIX-Month Warranty on all our products. Our core philosophy, 'Buy Easily, Service Assured,' reflects our unwavering dedication to customer satisfaction, which remains our paramount priority.
