Upgrade Your Heavy Duty Towing with Shandeka 480HP CNG Tractor and Air Suspension Seat

Certification
China Jining Huahang International Trade Co., Ltd. certification
China Jining Huahang International Trade Co., Ltd. certification
I'm Online Chat Now

Upgrade Your Heavy Duty Towing with Shandeka 480HP CNG Tractor and Air Suspension Seat

Upgrade Your Heavy Duty Towing with Shandeka 480HP CNG Tractor and Air Suspension Seat
Upgrade Your Heavy Duty Towing with Shandeka 480HP CNG Tractor and Air Suspension Seat Upgrade Your Heavy Duty Towing with Shandeka 480HP CNG Tractor and Air Suspension Seat Upgrade Your Heavy Duty Towing with Shandeka 480HP CNG Tractor and Air Suspension Seat Upgrade Your Heavy Duty Towing with Shandeka 480HP CNG Tractor and Air Suspension Seat Upgrade Your Heavy Duty Towing with Shandeka 480HP CNG Tractor and Air Suspension Seat Upgrade Your Heavy Duty Towing with Shandeka 480HP CNG Tractor and Air Suspension Seat

Large Image :  Upgrade Your Heavy Duty Towing with Shandeka 480HP CNG Tractor and Air Suspension Seat

Product Details:
Certification: SGS
Payment & Shipping Terms:
Delivery Time: 7-15days

Upgrade Your Heavy Duty Towing with Shandeka 480HP CNG Tractor and Air Suspension Seat

Description
Model NO.: ZZ4257N3247E1H Power: Diesel
Load Capacity: 31-40t Emission Standard: Euro 5
Drive Wheel: 4×2 Seats: ≤5
Horsepower: 351-450hp Engine Capacity: >8L
Tire Certification: ECE, GCC, ISO, DOT Tire Design: Tubeless
Condition: New Usage: Towing Semi Trailer
Fuel Tank: 400L, 600L, 1000L Driver Seat: Air Suspension Seat
Color: Customized Cargo Box Material: Carbon Steel
Steering System: Hydraulic Steering With Power Assistance Transport Package: Nude Packing
Specification: 6.8x2.5x3.8m Trademark: Sinotruk
Origin: China Shandong HS Code: 8708991000
Supply Ability: 1000pieces/Year Package Size: 717.00cm * 249.00cm * 398.00cm
Package Gross Weight: 9860.000kg After-sales Service: 6 Months
Warranty: 6 Months Transmission Type: Manual
Customization: Available | Customized Request Shipping Cost : About Shipping Cost And Estimated Delivery Time.
 : Initial Payment Full Payment Currency: US$
Return&refunds: You Can Apply For A Refund Up To 30 Days After Receipt Of The Products.

Shandeka 480HP CNG Tractor with Air Suspension Seat for Heavy Duty Towing

Product use

1. Definition of tractor
A tractor is a versatile light truck that excels in towing other vehicles or objects. Typically equipped with one or more pairs of wheels and axles, it is known for its reliability. Tractors effortlessly pull heavy-duty vehicles like semi-trailers, luxury yachts, and construction equipment, making them indispensable in the realm of heavy transport.
2. The structure of the tractor
A tractor is meticulously engineered with essential components such as the engine, transmission, tires, and frame. Enhanced functionality is achieved with optional features like tow hooks, advanced locking systems, and remote controls, ensuring superior operation and precise control.
3. Tractor application field
1. Transportation: Tractors are vital in the long-distance freight industry. They are adept at towing semi-trailers and large trucks, ensuring the safe and efficient delivery of goods to their destinations.
2. Construction field: Tractors are crucial for towing various construction machinery, including excavators, bulldozers, and cranes. They facilitate the movement and placement of heavy equipment, greatly enhancing productivity and efficiency in construction projects.

Shandeka 480HP CNG Tractor with Air Suspension Seat for Heavy Duty Towing
Shandeka 480HP CNG Tractor with Air Suspension Seat for Heavy Duty Towing

Shandeka 480HP CNG Tractor with Air Suspension Seat for Heavy Duty Towing
Shandeka 480HP CNG Tractor with Air Suspension Seat for Heavy Duty Towing

Shandeka 480HP CNG Tractor with Air Suspension Seat for Heavy Duty Towing
Shandeka 480HP CNG Tractor with Air Suspension Seat for Heavy Duty Towing
Shandeka 480HP CNG Tractor with Air Suspension Seat for Heavy Duty Towing
Shandeka 480HP CNG Tractor with Air Suspension Seat for Heavy Duty TowingShandeka 480HP CNG Tractor with Air Suspension Seat for Heavy Duty Towing
Shandeka 480HP CNG Tractor with Air Suspension Seat for Heavy Duty TowingShandeka 480HP CNG Tractor with Air Suspension Seat for Heavy Duty TowingShandeka 480HP CNG Tractor with Air Suspension Seat for Heavy Duty Towing

Basic Information

driver license:
A2
Announcement Model:
ZZ4186V501HF1LH
Drive type:
4X2
Wheelbase:
5200mm
engine:
Weichai WP15NG530E61
Gearbox:
Sinotruk HW25716XAL
Rear axle ratio:
2.85
Body length:
7.717 m
Body width:
2.496 m
Ride height:
3.98 m
Front track:
2041mm
Rear track:
1816mm
Vehicle weight:
9.86 tons
Total mass:
18 tons
Total traction mass:
31.94 tons
Maximum speed:
89km/h
Origin:
Zhangqiu, Shandong
Tonnage level:
Heavy Truck
Fuel Type:
Liquefied Natural Gas (LNG)



Engine parameters

engine model:
Weichai WP15NG530E61
Engine Brand:
Weichai
Number of cylinders:
6 cylinders
Fuel type:
Liquefied Natural Gas (LNG)
Cylinder arrangement:
In-line
Displacement:
14.6L
Emission Standards:
National VI
Maximum horsepower:
540 hp
Maximum output power:
390kW
Maximum Torque:
2500N·m
Maximum torque speed:
950-1350rpm
Rated speed:
1700rpm

Cab parameters

Number of passengers allowed:
2 people
Number of Seat Rows:
Half row

Gearbox parameters

Gearbox Model:
Sinotruk HW25716XAL
Gearbox brand:
Sinotruk
Shifting method:
AMT
Forward gears:
16 levels
Reverse gear number:
2



tank

Gas tank capacity:
2x1500+600L



Chassis parameters

Rear Axle Description:
MCY13JGS
Permissible load on front axle:
6500kg
Permissible load on rear axle:
11500kg
Speed ratio:
2.85
Number of springs:
3/-



tire

Number of tires:
6
Tire specifications:
12R22.5 18PR
Shipment
We usually ship the truck by RO-RO vessel or bulk vessel. Alternatively, we can ship the truck by special container, ensuring flexibility and safety in transportation.
Shandeka 480HP CNG Tractor with Air Suspension Seat for Heavy Duty Towing


Original Spare Parts
We provide authentic Spare Parts and boast a comprehensive after-sales service system. Our After-market Division is dedicated to delivering exceptional service with a streamlined supply chain that ensures rapid parts delivery.
Shandeka 480HP CNG Tractor with Air Suspension Seat for Heavy Duty Towing

Our Product
Shandeka 480HP CNG Tractor with Air Suspension Seat for Heavy Duty Towing

Thanks to Choose us

Q: How about the delivery time?
A: Most of our trucks and machinery are in stock, enabling delivery within 7 days. For specially ordered items, the typical production time is around 30 days.

Q: How many units of truck do you produce per year?
A: We produce nearly 30,000 units annually, with approximately 5,000 units updated each month.

Q: How do you control the quality of the product?
A: Our factory features a standardized production workshop with highly trained workers. Each product undergoes a meticulous inspection process. We ensure our trucks and machinery are reconditioned to professional standards.

Q: Do you accept custom orders? What's is your MOQ order?
A: Yes, we accept custom orders with a minimum order quantity (MOQ) of just 1 unit.
