Model NO.: | ZZ4257N3247E1H | Power: | Diesel |
---|---|---|---|
Load Capacity: | 31-40t | Emission Standard: | Euro 5 |
Drive Wheel: | 6×4 | Seats: | ≤5 |
Horsepower: | 351-450hp | Engine Capacity: | >8L |
Tire Certification: | ECE, GCC, ISO, DOT | Tire Design: | Tubeless |
Condition: | New | Usage: | Towing Semi Trailer |
Fuel Tank: | 400L, 600L, 1000L | Driver Seat: | Air Suspension Seat |
Color: | Red | Cargo Box Material: | Carbon Steel |
Steering System: | Hydraulic Steering With Power Assistance | Transport Package: | Nude Packing |
Specification: | 6.8x2.5x3.6m | Trademark: | Sinotruk |
Origin: | China Shandong | HS Code: | 8708991000 |
Supply Ability: | 1000pieces/Year | Package Size: | 680.00cm * 250.00cm * 360.00cm |
Package Gross Weight: | 25000.000kg | After-sales Service: | 6 Months |
Warranty: | 6 Months | Transmission Type: | Manual |
Customization: | Available | Customized Request | Shipping Cost : | About Shipping Cost And Estimated Delivery Time. |
: | Initial Payment Full Payment | Currency: | US$ |
Return&refunds: | You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
driver license: | A2 | Announcement Model: | ZZ4256V384HF1LB |
Drive type: | 6X4 | Wheelbase: | 3800+1400mm |
engine: | Weichai WP15NG530E61 | Gearbox: | Sinotruk HW25716XAL |
Rear axle ratio: | 2.85 | Body length: | 7.525 m |
Body width: | 2.52 m | Ride height: | 3.98 m |
Front track: | 2022mm | Rear track: | 1830/1830mm |
Vehicle weight: | 8.8 tons | Total mass: | 25 tons |
Total traction mass: | 40 tons | Maximum speed: | 89km/h |
Origin: | Shandong Jinan | Tonnage level: | Heavy Truck |
Fuel Type: | Liquefied Natural Gas (LNG) | | |
engine model: | Weichai WP15NG530E61 | Engine Brand: | Weichai |
Number of cylinders: | 6 cylinders | Fuel type: | Liquefied Natural Gas (LNG) |
Cylinder arrangement: | series | Displacement: | 14.6L |
Emission Standards: | National VI | Maximum horsepower: | 530 hp |
Maximum output power: | 390kW | Maximum Torque: | 2500N·m |
Maximum torque speed: | 950-1350rpm | Rated speed: | 1700rpm |
Number of passengers allowed: | 2 people | Number of Seat Rows: | Half row |
Gearbox Model: | Sinotruk HW25716XAL | Gearbox brand: | Sinotruk |
Shifting method: | *** | Forward gears: | 16 levels |
Number of downs: | 2 | | |
Gas tank capacity: | 1500L | | |
Rear Axle Description: | MCY12BGS self-adjusting double rear axle (maintenance-free) | Permissible load on front axle: | 7000kg |
Permissible load on rear axle: | 18000(two-axle group)kg | Speed ratio: | 2.85 |
Number of springs: | 2/3 | | |
Number of tires: | 10 | Tire specifications: | 12R22.5 18PR |
