Heavy Duty Sinotruck Tractor with Air Suspension Seat and Carbon Steel Cargo Box

Heavy Duty Sinotruck Tractor with Air Suspension Seat and Carbon Steel Cargo Box
Heavy Duty Sinotruck Tractor with Air Suspension Seat and Carbon Steel Cargo Box Heavy Duty Sinotruck Tractor with Air Suspension Seat and Carbon Steel Cargo Box Heavy Duty Sinotruck Tractor with Air Suspension Seat and Carbon Steel Cargo Box Heavy Duty Sinotruck Tractor with Air Suspension Seat and Carbon Steel Cargo Box Heavy Duty Sinotruck Tractor with Air Suspension Seat and Carbon Steel Cargo Box Heavy Duty Sinotruck Tractor with Air Suspension Seat and Carbon Steel Cargo Box

Large Image :  Heavy Duty Sinotruck Tractor with Air Suspension Seat and Carbon Steel Cargo Box

Product Details:
Certification: SGS
Payment & Shipping Terms:
Delivery Time: 7-15days
Contact Now

Heavy Duty Sinotruck Tractor with Air Suspension Seat and Carbon Steel Cargo Box

Description
Model NO.: ZZ4257N3247E1H Power: Diesel
Load Capacity: 31-40t Emission Standard: Euro 2
Drive Wheel: 8×4 Seats: ≤5
Horsepower: 351-450hp Engine Capacity: ＞8L
Tire Certification: ECE, GCC, ISO, DOT Tire Design: Tubeless
Condition: New Usage: Towing Semi Trailer
Fuel Tank: 400L, 600L, 1000L Driver Seat: Air Suspension Seat
Color: Customized Cargo Box Material: Carbon Steel
Steering System: Hydraulic Steering With Power Assistance Transport Package: Nude Packing
Specification: 6.8x2.5x3.8m Trademark: Sinotruk
Origin: China Liangshan HS Code: 87019090
Supply Ability: 1000pieces/Year Package Size: 680.00cm * 250.00cm * 380.00cm
Package Gross Weight: 25500.000kg After-sales Service: 6 Months
Warranty: 6 Months Transmission Type: Manual
Customization: Available | Customized Request Shipping Cost : About Shipping Cost And Estimated Delivery Time.
 : Initial Payment Full Payment Currency: US$
Return&refunds: You Can Apply For A Refund Up To 30 Days After Receipt Of The Products.

Heavy Duty Sinotruck Tractor with Air Suspension Seat and Carbon Steel Cargo Box 0

Product Use

1. Definition of Tractor
A tractor is a highly versatile light truck engineered to tow various vehicles or objects on the road. Characterized by its multiple pairs of wheels and robust axles, this powerful machine is indispensable for transporting semi-trailers, luxury yachts, construction equipment, and more. Its reliability and capacity make it a cornerstone in the heavy transport industry.
2. The Structure of the Tractor
A tractor is composed of several crucial components including the engine, transmission, tires, and frame. Additionally, it can be equipped with a variety of auxiliary devices such as tow hooks, locking systems, and remote controls, all designed to enhance operational efficiency and control, ensuring optimal performance in demanding conditions.
3. Tractor Application Fields
1. Transportation: In the realm of long-distance freight, the tractor is an essential vehicle for towing semi-trailers and large trucks. It guarantees the safe and efficient delivery of goods across vast distances, making it a vital tool in logistics and distribution.
2. Construction Field: Tractors are a cornerstone in the construction industry, utilized for towing a wide array of heavy equipment such as excavators, bulldozers, and cranes to construction sites. Their strength and reliability ensure that large-scale projects run smoothly.

Basic Info.

Heavy Duty Sinotruck Tractor with Air Suspension Seat and Carbon Steel Cargo Box 1
Heavy Duty Sinotruck Tractor with Air Suspension Seat and Carbon Steel Cargo Box 2
Heavy Duty Sinotruck Tractor with Air Suspension Seat and Carbon Steel Cargo Box 3


Heavy Duty Sinotruck Tractor with Air Suspension Seat and Carbon Steel Cargo Box 4
Heavy Duty Sinotruck Tractor with Air Suspension Seat and Carbon Steel Cargo Box 5
Heavy Duty Sinotruck Tractor with Air Suspension Seat and Carbon Steel Cargo Box 6

Heavy Duty Sinotruck Tractor with Air Suspension Seat and Carbon Steel Cargo Box 7
Heavy Duty Sinotruck Tractor with Air Suspension Seat and Carbon Steel Cargo Box 8
Heavy Duty Sinotruck Tractor with Air Suspension Seat and Carbon Steel Cargo Box 9


Main Specifications:

Driver's Cab(One sleeper with A/C)
Model HW76 Cab, with one sleeper beds, two seats, with A/C
Type Forward control cab, hydraulically tiltable by 60o
Construction Current standard all steel construction
Instrument panel Clearly visible,indicators of compressed air pressure,
coolant temperature, engine oil pressure and battery
charging
Seats 4-point support fully floating suspension + shock
absorbers driver adjustable & passenger fixed
Seat belts For driver & passenger
Glass Tempered safety glass
Sun visors Dual, adjustable
Mirrors Large, truck type convex
Wind screen wiper 3 arm wind screen wiper system with 3 speeds
Entertainment system FM/AM/SW, 4 band radio with cassette player, two speaker and antenna
Steering wheel Adjustable steering wheel
Horn Air horn
Panel LCD Panel with LED light


Engine
Engine brand SINOTRUK
Engine model WD615.47, 380hp
Emission Standard EURO II
Engine type Diesel 4-stroke direct injection engine,
6-cylinder in-line
with water cooling, turbo-charging &
Inter-cooling
Displacement 9.726 liters
Max. Output 371hp@2200rpm
Max. torque 1250Nm @1100-1600 rpm
Bore/Stroke 126/130mm
Compression ratio 17:1
Specific fuel consumption ≤193g/kW.h


Cooling System
Medium Water
Radiator heavy duty type
Cooling fan Visco static fan tropical type
Thermostat Opening at 70-80ºC
Warning device Audible & visual


Clutch
Type Φ430 Diaphragm type, Single dry frictional disc, Hydraulic boosting hydraulically operating with air assistance


Transmission
  Type Heavy duty, manual fuller type
  Model HW19710
  No of speeds 10 forward + 2 reverse

Model Torque(Nm) Gear Ratios Oiling
(L)
1 2 3 4 5 6 7 8 9 10 R1 R2
HW19710 1900 14.28 10.62 7.87 5.88 4.38 3.27 2.43 1.80 1.34 1.00 13.91 3.18 12



Front Axle
Type HF7 tons steering with double T-cross section beam
Capacity 7000kg


Rear Axle
Type HC16(16 ton, punching-welding axle housing, double reduction driving axle, inter-wheel differential and differential lock)
Capacity 16T


Chassis
Frame Heavy duty, reinforced sub frame,
300mmx80mmx8mm
(inner: 280mmx70mmx7mm)
Front suspension semi-elliptic leaf springs with hydraulic telescopic double-action
shock absorbers and stabilizer, 1500mm
Rear suspension semi-elliptic springs ,and bogie springs, and stabilizer
, 1739mm


Air Intake System
Air cleaner type Heavy duty type
Pre filter Cyclone


Exhaust System
Capable of maintaining the sound level as low as possible.


Steering
Location Left hand
Model ZF 8098 (Made in Germany) hydraulic steering with power assistance
Variable ratios 22.2-26.2, 17.0-20.0
Max. pressure 170+10 bar
Max. output torque 7618 Nm
Weight 42 kg


Bumper
Installed heavy duty front and rear steel bumpers


Brake System
Service brake Dual circuit compressed air brake.
Parking brake Spring energy, compressed air operating on rear wheels
Assistant brake Engine exhaust valve brake


Wheels & Tyres
Wheels Single front and dual rear
Tyres Double Coin brand,12.00R20
Quantity 13


Air Supply System
Warning device Audible & visual
Air line Heavy duty steel pipes


Electrical System
Operating Voltage 24V, Negative grounded; Starter 24V, 7.5KW
Battery type 2x12V, 165Ah/180Ah
Alternator 28V, 1500W
Cigar Lighter, horn, head lamps, fog lights, brake lights, indicators and reverse lamp


Dimensions
Wheel base 4600mm+1350
Overall length 6875mm
Overall width 2496mm
Overall height 3730mm


Our Factory
Heavy Duty Sinotruck Tractor with Air Suspension Seat and Carbon Steel Cargo Box 10
Heavy Duty Sinotruck Tractor with Air Suspension Seat and Carbon Steel Cargo Box 11
Heavy Duty Sinotruck Tractor with Air Suspension Seat and Carbon Steel Cargo Box 12


Shipment

We typically ship trucks by RO-RO or bulk vessels. Should the need arise, we also have the capability to use specially-designed containers to ensure the secure and efficient transport of your vehicles.
Heavy Duty Sinotruck Tractor with Air Suspension Seat and Carbon Steel Cargo Box 13


Original Spare Parts

We provide genuine original spare parts along with a comprehensive after-sales service system. Our After-market Division is dedicated to delivering outstanding service, backed by a streamlined supply chain for expedited parts delivery.
Heavy Duty Sinotruck Tractor with Air Suspension Seat and Carbon Steel Cargo Box 14
