Home ProductsUsed Tractor Truck

Tipper Trailer Truck with ECE Tire Certification 480HP Engine and Air Ride Seat Fuel Tank 400L

Certification
China Jining Huahang International Trade Co., Ltd. certification
China Jining Huahang International Trade Co., Ltd. certification
I'm Online Chat Now

Tipper Trailer Truck with ECE Tire Certification 480HP Engine and Air Ride Seat Fuel Tank 400L

Tipper Trailer Truck with ECE Tire Certification 480HP Engine and Air Ride Seat Fuel Tank 400L
Tipper Trailer Truck with ECE Tire Certification 480HP Engine and Air Ride Seat Fuel Tank 400L Tipper Trailer Truck with ECE Tire Certification 480HP Engine and Air Ride Seat Fuel Tank 400L Tipper Trailer Truck with ECE Tire Certification 480HP Engine and Air Ride Seat Fuel Tank 400L Tipper Trailer Truck with ECE Tire Certification 480HP Engine and Air Ride Seat Fuel Tank 400L Tipper Trailer Truck with ECE Tire Certification 480HP Engine and Air Ride Seat Fuel Tank 400L Tipper Trailer Truck with ECE Tire Certification 480HP Engine and Air Ride Seat Fuel Tank 400L

Large Image :  Tipper Trailer Truck with ECE Tire Certification 480HP Engine and Air Ride Seat Fuel Tank 400L

Product Details:
Certification: SGS
Payment & Shipping Terms:
Delivery Time: 7-15days

Tipper Trailer Truck with ECE Tire Certification 480HP Engine and Air Ride Seat Fuel Tank 400L

Description
Model NO.: ZZ4257N3247E1H Drive Wheel: 6×4
Seats: ≤5 Horsepower: >450hp
Engine Capacity: >8L Tire Certification: ECE, GCC, ISO, DOT
Tire Design: Tubeless Condition: New
Usage: Towing Semi Trailer Fuel Tank: 400L, 600L, 1000L
Driver Seat: Air Suspension Seat Color: Customized
Cargo Box Material: Carbon Steel Steering System: Hydraulic Steering With Power Assistance
Transport Package: Nude Packing Specification: 6.8x2.5x3.8m
Trademark: Sinotruk Origin: China Shandong
HS Code: 8708991000 Supply Ability: 1000pieces/Year
After-sales Service: 6 Months Warranty: 6 Months
Transmission Type: Manual Power: Diesel
Load Capacity: 31-40t Emission Standard: Euro 5
Customization: Available | Customized Request

High Performance Tipper Trailer Truck with 480HP Engine and Air Ride Seat

Product Use

1. Definition of Tractor
A tractor is a versatile light truck designed for towing vehicles or heavy objects. Typically equipped with multiple pairs of wheels and axles, it is renowned for its reliability and ease of handling. It effortlessly pulls heavy-duty vehicles like semi-trailers, luxury yachts, and construction equipment, making it a crucial asset in heavy transportation.
2. The Structure of the Tractor
A tractor is meticulously engineered with essential components such as the engine, transmission, tires, and frame. Enhanced functionality is achieved through optional features like tow hooks, advanced locking systems, and remote controls, ensuring superior performance and precise control.
3. Tractor Application Field
1. Transportation: Tractors play a vital role in long-distance freight, adept at towing semi-trailers and large trucks. They ensure the safe and efficient delivery of goods over extensive distances.
2. Construction: Tractors are indispensable in the construction industry for towing various machinery, including excavators, bulldozers, and cranes. This facilitates the efficient transport of heavy equipment to construction sites, enhancing operational productivity.

Basic Info.

High Performance Tipper Trailer Truck with 480HP Engine and Air Ride Seat

High Performance Tipper Trailer Truck with 480HP Engine and Air Ride Seat
High Performance Tipper Trailer Truck with 480HP Engine and Air Ride Seat

High Performance Tipper Trailer Truck with 480HP Engine and Air Ride Seat
High Performance Tipper Trailer Truck with 480HP Engine and Air Ride Seat


Basic Information

driver license:
A2
Announcement Model:
ZZ4256V384HF1CB
Drive type:
6X4
Wheelbase:
3800+1400mm
engine:
Sinotruk MT13.46-60
Gearbox:
Sinotruk HW25716XSTCL
Rear axle ratio:
2.71
Body length:
7.525 m
Body width:
2.52 m
Ride height:
3.29 m
Front track:
2022mm
Rear track:
1830/1830mm
Vehicle weight:
10.6 tons
Total mass:
25 tons
Total traction mass:
38.2 tons
Maximum speed:
89km/h
Origin:
Zhangqiu, Shandong
Tonnage level:
Heavy Truck
Remark:
The speed ratio can be selected as 2.85/3.08/3.36/3.7/4.11.
Fuel Type:
Compressed Natural Gas (CNG)


Engine parameters

engine model:
Sinotruk MT13.46-60
Engine Brand:
Sinotruk
Number of cylinders:
6 cylinders
Fuel type:
Compressed Natural Gas (CNG)
Cylinder arrangement:
In-line
Displacement:
12.419L
Emission Standards:
National V
Maximum horsepower:
540 hp
Maximum output power:
341kW




Cab parameters

Cab:
High Top
Number of passengers allowed:
2 people
Number of Seat Rows:
Half row




Gearbox parameters

Gearbox Model:
Sinotruk HW25716XSTCL
Gearbox brand:
Sinotruk
Shifting method:
Manual
Forward gears:
16 levels
Reverse gear number:
2




tank

Fuel tank capacity:
8*280L




Chassis parameters

Front axle description:
7.1 ton disc front axle
Rear Axle Description:
MAN 12 ton drum/disc rear axle
Permissible load on front axle:
7000kg
Permissible load on rear axle:
18000(two-axle group)kg
Speed ratio:
2.71
Number of springs:
2/4
Saddle:
50#




tire

Number of tires:
10
Tire specifications:
12.00R20 16PR
Tire type:
Low rolling resistance





Shipment

We usually ship the truck by RO-RO vessel or bulk vessel. Additionally, we can ship the truck using special containers, ensuring flexible delivery options to meet diverse shipping needs.
High Performance Tipper Trailer Truck with 480HP Engine and Air Ride Seat


Original Spare Parts
We provide authentic spare parts accompanied by a comprehensive after-sales service system. Our After-market Division is dedicated to delivering exceptional service with a streamlined supply chain, ensuring rapid parts delivery and customer satisfaction.
High Performance Tipper Trailer Truck with 480HP Engine and Air Ride Seat

Our Product
High Performance Tipper Trailer Truck with 480HP Engine and Air Ride Seat

Thanks for Choosing Us

Q: How about the delivery time?
A: Most of our trucks and machinery are in stock, allowing for delivery within 7 days. For specially ordered items, the typical production time is around 30 days, ensuring timely fulfillment of custom requirements.

Q: How many units of trucks do you produce per year?
A: We proudly produce nearly 30,000 units annually, maintaining our production prowess with approximately 5,000 units updated each month.

Q: How do you control the quality of the product?
A: Our factory features a standardized production workshop staffed by highly trained workers. Each product undergoes a meticulous inspection process, ensuring our trucks and machinery meet professional reconditioning standards.

Q: Do you accept custom orders? What is your MOQ?
A: Yes, we accept custom orders with a minimum order quantity (MOQ) of just 1 unit, offering flexibility to meet diverse customer needs.
