Model NO.: | Wd615.47/87/69 | Speed: | 2200/Min |
---|---|---|---|
Cooling Cylinder: | Water-Cooled | Intake Pressure Impulse: | Naturally Aspirated |
Piston Movement: | Reciprocating | Fuel: | Diesel |
Number Of Strokes: | Four-Stroke | Cylinder Arrangement Form: | Straight Six Cylinder, Water Cooled, Four Stroke |
Number Of Cylinders: | 6-Cylinder | Type: | Electric Motor |
Color: | Silver | Start: | Kick Start |
Weight: | 110kg | Certificate: | ISO9001 |
Transport Package: | Carton Box | Specification: | 230.00cm * 110.00cm * 130.00cm |
Trademark: | Sinotruk | Origin: | China |
Supply Ability: | 1000pieces/Year | Package Size: | 6.20cm * 2.50cm * 3.20cm |
Package Gross Weight: | 18000.000kg | After-sales Service: | 3months |
Warranty: | 3months | Ignition Mode: | Electric Ignition |
Customization: | Available | Customized Request | Shipping Cost : | About Shipping Cost And Estimated Delivery Time. |
: | Initial Payment Full Payment | Currency: | US$ |
Return&refunds: | You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
driver license: | A2 | Announcement Model: | ZZ4187N3517N1B |
Drive type: | 4X2 | Wheelbase: | 3500mm |
Body length: | 6.2 m | Body width: | 2.5 m |
Ride height: | 3.2 m | Front track: | 2022mm |
Rear track: | 1830mm | Vehicle weight: | 6.8 tons |
Total mass: | 18 tons | Total traction mass: | 35 tons |
Maximum speed: | 101km/h | Origin: | Shandong Jinan |
Tonnage level: | Heavy Truck | Remark: | The vehicle can be equipped with or without a deflector, and the vehicle height is 3745mm; the vehicle can also be equipped with an extended cab, and the vehicle height is 3560 mm, and the deflector can be equipped without a deflector, and the vehicle height is 3230mm. The number of passengers corresponds to the maximum allowable load parameter of the saddle. When the vehicle is equipped with the engine ***.34-31 and D12.34-30, the VIN code is LZZ5CCNC×××××××××, and the net power is 247kW and 245kW respectively; when the engine ***.38-30 and D12.38-30 are selected, the VIN code is LZZ5CCSC×××××××××, and the net power is 277kW and 275kW respectively. When the D12 series engine is selected, the fuel tank and other components are placed on the left side of the vehicle. |
Fuel Type: | diesel fuel | | |
engine model: | Sinotruk ***.34 | Engine Brand: | Sinotruk |
Number of cylinders: | 6 cylinders | Fuel type: | diesel fuel |
Cylinder arrangement: | series | Displacement: | 9.726L |
Emission Standards: | Kunisan | Maximum horsepower: | 340 hp |
Maximum output power: | 250kW | Maximum Torque: | 1490N·m |
Maximum torque speed: | 1200-1500rpm | Rated speed: | 1900rpm |
Cab: | Flat Top | Number of passengers allowed: | 2 people |
Number of Seat Rows: | Half row | | |
Gearbox Model: | Sinotruk HW18710 | Gearbox brand: | Sinotruk |
Shifting method: | Manual | Forward gears: | 10 levels |
Number of downs: | 2 | | |
Fuel tank/gas tank material: | Aluminum Alloy | Fuel tank capacity: | 400L |
Permissible load on rear axle: | 11500kg | Suspension type: | Leaf spring |
Number of springs: | 4/5 9/9+6 4/9+6 | | |
Number of tires: | 6 | Tire specifications: | 12.00-20 |
Our extraordinary success shines through with the impressive annual exportation of over 1,000 Heavy Duty HOWO 6X4 Dump Trucks to numerous African nations. This remarkable achievement underscores our steadfast commitment to excellence and our extensive global presence. Jining Huahang International Trade Co., Ltd. stands as a pillar of reliability and superior quality, revolutionizing the heavy-duty truck industry with our top-tier products and unparalleled service. Our unwavering dedication to customer satisfaction and relentless innovation guarantees that we consistently exceed the expectations of our valued clients worldwide.
