| Model NO.: | ZZ4257N3247E1H | Power: | Diesel |
|---|---|---|---|
| Load Capacity: | 31-40t | Emission Standard: | Euro 3 |
| Drive Wheel: | 6×4 | Seats: | ≤5 |
| Horsepower: | 351-450hp | Engine Capacity: | ＞8L |
| Tire Certification: | ECE, GCC, ISO, DOT | Tire Design: | Tubeless |
| Condition: | Used | Usage: | Towing Semi Trailer |
| Fuel Tank: | 400L, 600L, 1000L | Driver Seat: | Air Suspension Seat |
| Color: | Black | Cargo Box Material: | Carbon Steel |
| Steering System: | Hydraulic Steering With Power Assistance | Transport Package: | Nude Packing |
| Specification: | 6.8x2.5x3.8m | Trademark: | Sinotruk |
| Origin: | China Liangshan | HS Code: | 87019090 |
| Supply Ability: | 1000pieces/Year | Package Size: | 680.00cm * 250.00cm * 380.00cm |
| Package Gross Weight: | 9200.000kg | After-sales Service: | 6 Months |
| Warranty: | 6 Months | Transmission Type: | Manual |
| Customization: | Available | Customized Request | Shipping Cost : | About Shipping Cost And Estimated Delivery Time. |
| : | Initial Payment Full Payment | Currency: | US$ |
| Return&refunds: | You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
| driver license: | A2 | Announcement Model: | ZZ4257V3247N1H |
| Drive type: | 6X4 | Wheelbase: | 3225+1350mm |
| Body length: | 6.985m | Body width: | 2.496 m |
| Ride height: | 3.23 m | Front track: | 2022mm |
| Rear track: | 1830/1830mm | Vehicle weight: | 9.2 tons |
| Total mass: | 25 tons | Total traction mass: | 39.6 tons |
| Maximum speed: | 91km/h | Origin: | Shandong Jinan |
| Tonnage level: | Heavy Truck | Remark: | The vehicle can be equipped with or without a deflector, and the vehicle height is 3745mm; the vehicle can also be equipped with an extended cab, and the vehicle height is 3560 mm, and the deflector can be equipped without an optional deflector, and the vehicle height is 3230mm. The number of passengers corresponds to the maximum allowable load parameter of the saddle; the wheelbase corresponds to the rear overhang parameter. When the vehicle is equipped with the optional engine D12.42-30, the VIN code is LZZ5CLVB×××××××××, and the net power is 305kW; when the engine D12.46-30 is selected, the VIN code is LZZ5CLWB×××××××××, and the net power is 335kW |
| Fuel Type: | diesel fuel | | |
| engine model: | Sinotruk D12.42-30 | Engine Brand: | Sinotruk |
| Number of cylinders: | 6 cylinders | Fuel type: | diesel fuel |
| Cylinder arrangement: | series | Displacement: | 11.596L |
| Emission Standards: | Kunisan | Maximum horsepower: | 420 hp |
| Maximum output power: | 309kW | Maximum Torque: | 1820N·m |
| Maximum torque speed: | 1100-1400rpm | Rated speed: | 2000rpm |
| Cab: | Flat Top | Number of passengers allowed: | 3 people |
| Number of Seat Rows: | Half row | | |
| Gearbox Model: | Sinotruk HW18710 | Gearbox brand: | Sinotruk |
| Shifting method: | AMT | Forward gears: | 10 levels |
| Number of downs: | 2 | | |
| Fuel tank/gas tank material: | Aluminum Alloy | Fuel tank capacity: | 400L |
| Rear Axle Description: | Double shaft | Permissible load on rear axle: | 18000kg |
| Suspension type: | Leaf spring | Number of springs: | 9/12 |
| Number of tires: | 10 | Tire specifications: | 12.00R20 |
