| Model NO.: | Dongfeng Tianlong | Power: | Diesel |
|---|---|---|---|
| Load Capacity: | 31-40t | Emission Standard: | Euro 5 |
| Drive Wheel: | 4×2 | Seats: | ≤5 |
| Horsepower: | 150-250hp | Engine Capacity: | >8L |
| Tire Certification: | ECE, GCC, ISO, DOT | Tire Design: | Tubeless |
| Condition: | New | Usage: | Towing Semi Trailer |
| Fuel Tank: | 400L, 600L, 1000L | Driver Seat: | Air Suspension Seat |
| Color: | White | Cargo Box Material: | Carbon Steel |
| Steering System: | Hydraulic Steering With Power Assistance | Transport Package: | Nude Packing |
| Specification: | 11.99x2.55x3.99m | Trademark: | Dongfeng Tianlong |
| Origin: | China Liangshan | HS Code: | 8708991000 |
| Supply Ability: | 1000pieces/Year | Package Size: | 119.00cm * 255.00cm * 399.00cm |
| Package Gross Weight: | 10200.000kg | After-sales Service: | 6 Months |
| Warranty: | 6 Months | Transmission Type: | Automatic |
| Customization: | Available | Customized Request | Shipping Cost : | About Shipping Cost And Estimated Delivery Time. |
| : | Initial Payment Full Payment | Currency: | US$ |
| Return&refunds: | You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
| Announcement Model: | DFH5180XXYB1 | type: | Box truck |
| Drive type: | 4X2 | Wheelbase: | 7100mm |
| Box length level: | 9.6 m | engine: | Dongfeng Cummins ISB180 50 |
| Gearbox: | Fast 8JS85E | Rear axle ratio: | 4.56 |
| Body length: | 11.99 m | Body width: | 2.55 m |
| Ride height: | 3.99 m | Front track: | 1960mm |
| Rear track: | 1840mm | Vehicle weight: | 9.2 tons |
| Rated load: | 9.005 tons | Total mass: | 18 tons |
| Maximum speed: | 110KM/h | Origin: | Hubei Shiyan |
| Tonnage level: | Heavy trucks | driver license: | A1,A2,B2 |
| Approach Angle: | 15 degrees | Departure angle: | 5 degrees |
| Market segments: | Express delivery, LTL transportation | Remark: | High-end cab |
| Front overhang/rear overhang: | 1.43/3.46m | Fuel Type: | diesel fuel |
| engine model: | Dongfeng Cummins ISB180 50 | Engine Brand: | Dongfeng Cummins |
| Engine common name: | Dongkang 6 cylinder | Number of cylinders: | 6 cylinders |
| Fuel type: | diesel fuel | Cylinder arrangement: | series |
| Displacement: | 5.9L | Emission Standards: | National Five |
| Maximum output power: | 132kw | Maximum horsepower: | 180 hp |
| Maximum Torque: | 700N·m | Maximum torque speed: | 1200-1700RPM |
| Rated speed: | 2500RPM | Engine Type: | SCR |
| Cargo box form: | Box | Length of cargo box: | 9.6 m |
| Cargo box width: | 2.45 m | Cargo box height: | 2.6 m |
| Number of passengers allowed: | 3 people | Number of Seat Rows: | Half row |
| Driver's seat type: | Airbag shock absorbing seat | | |
| Gearbox Model: | Fast 8JS85E | Gearbox brand: | Fast |
| Shifting method: | Manual | Forward gears: | 8 gears |
| Number of downs: | 2 | | |
| Fuel tank material: | Aluminum Alloy | Fuel tank capacity: | 200L |
| Front axle description: | 5T | Permissible load on front axle: | 6500KG |
| Frame size: | 250×80×[7+4]mm | Rear Axle Description: | 9T rear axle |
| Permissible load on rear axle: | 11500KG | Speed ratio: | 4.56 |
| Number of springs: | 8/10+8 | clutch: | F395 |
| Tire specifications: | 295/80R22.5 | Number of tires: | 6 |
