Model NO.: | ZZ4257N3247E1H | Power: | Diesel |
---|---|---|---|
Load Capacity: | 31-40t | Emission Standard: | Euro 5 |
Drive Wheel: | 6×4 | Seats: | ≤5 |
Horsepower: | >450hp | Engine Capacity: | >8L |
Tire Certification: | ECE, GCC, ISO, DOT | Tire Design: | Tubeless |
Condition: | New | Usage: | Towing Semi Trailer |
Fuel Tank: | 400L, 600L, 1000L | Driver Seat: | Air Suspension Seat |
Color: | Customized | Cargo Box Material: | Carbon Steel |
Steering System: | Hydraulic Steering With Power Assistance | Transport Package: | Nude Packing |
Specification: | 6.8x2.5x3.8m | Trademark: | Sinotruk |
Origin: | China Shandong | HS Code: | 8708991000 |
Supply Ability: | 1000pieces/Year | Package Size: | 641.00cm * 249.00cm * 396.00cm |
Package Gross Weight: | 6500.000kg | After-sales Service: | 6 Months |
Warranty: | 6 Months | Transmission Type: | Manual |
Customization: | Available | Customized Request | Shipping Cost : | About Shipping Cost And Estimated Delivery Time. |
: | Initial Payment Full Payment | Currency: | US$ |
Return&refunds: | You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
Basic Information | ||||||
Body length: | 6417mm | Body width | 2496mm | |||
Ride height: | 3980mm | Announcement Model | ZZ4186V361HF1B | |||
Drive type | 4 x 2 | Wheelbase | 3800mm | |||
Vehicle weight | 7400kg | Maximum total mass | 18000kg | |||
Maximum speed | 110km/h | Maximum horsepower | 440 hp | |||
Total traction mass | 34400kg | Tonnage level | Heavy Truck | |||
Front track/rear track | 2041mm/1816mm | |||||
Cab parameters | ||||||
Number of passengers allowed | 3 people | Number of Seat Rows: | ||||
Cab | High Top | |||||
tire | ||||||
Tire specifications: | 12R22.50 18PR | Number of tires: | 12 | |||
tank | ||||||
Fuel tank capacity: | 995L | |||||
engine | ||||||
engine: | Sinotruk MT13.44-60 | Number of cylinders: | 6 | |||
Fuel type: | Natural gas (LNG/CNG) | Displacement: | 12.4L | |||
Emission Standards: | National VI | Maximum output power: | 327kW | |||
Maximum Torque: | 2100Nm | Maximum torque speed: | 1000-1400r/min | |||
Rated speed: | 1800r/min | Cylinder arrangement: | In-line | |||
Gearbox | ||||||
Gearbox: | Sinotruk HW25712XSTCL | Forward gears: | 12 gears | |||
Number of reverse gears: | 2 | Shifting method: | Manual/MT | |||
Chassis | ||||||
Number of springs: | 3/- | Permissible load on rear axle: | 11500kg | |||
Permissible load on front axle: | 6500kg |
