Model NO.: | DUMP TRUCK | Drive Wheel: | 6×4 |
---|---|---|---|
Engine Capacity: | 4-6L | Seats: | ≤5 |
Horsepower: | 351-450hp | Tire Certification: | ISO |
Tire Design: | Tubeless | Dumping Type: | Front Lifting Style |
Condition: | Used | Tyre: | New |
Steering System: | Hydraulic Steering With Power Assistance | Chassis Brand: | Sinotruk Chassis |
Color: | Customized | Cab: | Air Conditioner |
Cargo Box Material: | Carbon Steel | Electric System: | Battery:2X12V/165ah; Alternator:28V-1500 Kw; Sta |
Transport Package: | Naked Packing | Specification: | 8.5x2.6x3.6m |
Trademark: | FAW | Origin: | China |
HS Code: | 870423009 | Supply Ability: | 10000pieces/Year |
After-sales Service: | 6 Months | Warranty: | 6 Months |
Transmission Type: | Manual | Power: | Diesel |
Load Capacity: | 21-30t | Emission Standard: | Euro 3 |
Customization: | Available | Customized Request |
driver license: | A1,A2,B2 | Announcement Model: | ZZ3257W414HF1 |
Drive type: | 6X4 | Wheelbase: | 4100+1400mm |
engine: | Weichai WP13.510E62 | Gearbox: | Sinotruk HW25712XSJ |
Rear axle ratio: | 5.26 | Body length: | 8.915m |
Body width: | 2.55 m | Ride height: | 3.45 m |
Front track: | 2041mm | Rear track: | 1860/1860mm |
Vehicle weight: | 12.5 tons | Rated load: | 12.37 tons |
Total mass: | 25 tons | Tonnage level: | Heavy Truck |
Approach Angle: | 16 degrees | Departure angle: | 20 degrees |
Origin: | Shandong Jinan | Market segments: | Urban construction waste |
Remark: | Optional: 12.3-inch full HD central control screen, 360-degree surround view; | Overall speed ratio: | 5.26 |
Fuel Type: | diesel fuel | | |
engine model: | Weichai WP13.510E62 | Engine Brand: | Weichai |
Number of cylinders: | 6 cylinders | Fuel type: | diesel fuel |
Displacement: | 12.54L | Emission Standards: | National VI |
Maximum horsepower: | 510 hp | Maximum output power: | 375kW |
Maximum Torque: | 2400N·m | Maximum torque speed: | 950-1400rpm |
Rated speed: | 1900rpm | Engine Type: | CR+***+DPF+Hi_SCR |
Length of cargo box: | 6 meters | Cargo box width: | 2.35 m |
Cargo box height: | 1.5 m | Cargo box form: | Self-unloading |
Gearbox Model: | Sinotruk HW25712XSJ | Gearbox brand: | Sinotruk |
Forward gears: | 12 gears | Reverse gear number: | 2 |
Frame size: | 8+8mm | Permissible load on front axle: | 7000kg |
Rear Axle Description: | MCP16ZG | Permissible load on rear axle: | 18000(two-axle group)kg |
Speed ratio: | 5.26 | Number of springs: | 10/12 |
Tire specifications: | 12.00R20 | Number of tires: | 10 |
Our stellar accomplishments are a shining example of our steadfast commitment to excellence! Annually, we proudly dispatch over 1,000 Sinotruk Chassis Used Tipper Trucks across numerous African countries. This extraordinary milestone highlights our relentless pursuit of superior quality, unmatched reliability, and exceptional heavy-duty transportation solutions. Our outstanding performance not only meets but consistently exceeds industry benchmarks, ensuring that we cater to the varied demands of our international clients with exceptional service and top-tier products.
Contact Person: Mr. Liu
Tel: +86 13153796988
