| Model NO.: | ZZ4257N3247E1H | Drive Wheel: | 6×4 |
|---|---|---|---|
| Seats: | ≤5 | Engine Capacity: | ＞8L |
| Tire Certification: | ECE, GCC, ISO, DOT | Tire Design: | Tubeless |
| Condition: | Used | Usage: | Towing Semi Trailer |
| Fuel Tank: | 400L, 600L, 1000L | Driver Seat: | Air Suspension Seat |
| Color: | Customized | Cargo Box Material: | Carbon Steel |
| Steering System: | Hydraulic Steering With Power Assistance | Transport Package: | Nude Packing |
| Specification: | 6.5x2.5x4m | Trademark: | Sinotruk |
| Origin: | China Shandong | HS Code: | 8708991000 |
| Supply Ability: | 1000pieces/Year | After-sales Service: | 6 Months |
| Warranty: | 6 Months | Transmission Type: | Manual |
| Power: | Diesel | Load Capacity: | 31-40t |
| Emission Standard: | Euro 5 | Customization: | Available | Customized Request |
| driver license: | A2 | Announcement Model: | ZZ4256V324HE1W |
| Drive type: | 6X4 | Wheelbase: | 3200+1400mm |
| engine: | Sinotruk MC13.48-50 | Gearbox: | Sinotruk HW25716XSTCL |
| Rear axle ratio: | 3.7 | Body length: | 6.895 m |
| Body width: | 2.496 m | Ride height: | 3.98 m |
| Front track: | 2022mm | Rear track: | 1830/1830mm |
| Vehicle weight: | 8.8 tons | Total mass: | 25 tons |
| Total traction mass: | 40 tons | Maximum speed: | 101km/h |
| Market segments: | Dangerous Goods Transport | Origin: | Zhangqiu, Shandong |
| Tonnage level: | Heavy Truck | Version: | Hazardous Chemicals |
| Fuel Type: | diesel fuel | | |
| engine model: | Sinotruk MC13.48-50 | Engine Brand: | Sinotruk |
| Number of cylinders: | 6 cylinders | Fuel type: | diesel fuel |
| Cylinder arrangement: | series | Displacement: | 12.419L |
| Emission Standards: | Country Five | Maximum horsepower: | 480 hp |
| Maximum output power: | 353kW | Maximum Torque: | 2300N·m |
| Maximum torque speed: | 1050-1400rpm | Rated speed: | 1900rpm |
| Technical route: | Common Rail SCR | | |
| Cab: | High Top | Lower berth width: | 800mm |
| Number of passengers allowed: | 3 people | Number of Seat Rows: | Half row |
| Driver's seat type: | Airbag shock absorbing seat | | |
| Gearbox Model: | Sinotruk HW25716XSTCL | Gearbox brand: | Sinotruk |
| Shifting method: | Manual | Forward gears: | 16 levels |
| Number of downs: | 2 | Shell Material: | Aluminum Alloy |
| Fuel tank/gas tank material: | Aluminum Alloy | Fuel tank capacity: | 400L |
| Frame size: | TGA-Bmm | Front axle description: | VPD75ES |
| Rear Axle Description: | MCY11BES | Permissible load on front axle: | 7000kg |
| Permissible load on rear axle: | 18000(two-axle group)kg | Speed ratio: | 3.7 |
| Number of springs: | 2/-/- | Suspension type (front/rear): | Front three back empty |
| Aluminum Alloy Wheels: | ○ | | |
| Number of tires: | 10 | Tire specifications: | 295/80R22.5,12R22.5 |
