Model NO.: | ZZ4257N3247E1H | Drive Wheel: | 6×4 |
---|---|---|---|
Seats: | ≤5 | Horsepower: | >450hp |
Engine Capacity: | >8L | Tire Certification: | ECE, GCC, ISO, DOT |
Tire Design: | Tubeless | Condition: | Used |
Usage: | Towing Semi Trailer | Fuel Tank: | 400L, 600L, 1000L |
Driver Seat: | Air Suspension Seat | Color: | Customized |
Cargo Box Material: | Carbon Steel | Steering System: | Hydraulic Steering With Power Assistance |
Transport Package: | Nude Packing | Specification: | 6.9x2.55x3.57m |
Trademark: | Auman | Origin: | China |
HS Code: | 8708991000 | Supply Ability: | 1000pieces/Year |
After-sales Service: | 6 Months | Warranty: | 6 Months |
Transmission Type: | Manual | Power: | Diesel |
Load Capacity: | 31-40t | Emission Standard: | Euro 5 |
Customization: | Available | Customized Request |
driver license: | A2 | Announcement Model: | BJ4259SNFKB-AJ |
Drive type: | 6X4 | Wheelbase: | 3300+1350mm |
engine: | Weichai WP13.550E501 | Gearbox: | Fast 12JSD180TA |
Body length: | 6.95 m | Body width: | 2.55 m |
Ride height: | 3.57 m | Front track: | 2005,2010,2020mm |
Rear track: | 1804/1804,1800/1800mm | Vehicle weight: | 8.2 tons |
Total mass: | 25 tons | Total traction mass: | 40 tons |
Maximum speed: | 95km/h | Market segments: | Logistics distribution, coal transportation, express delivery |
Origin: | Beijing | Tonnage level: | Heavy Truck |
Version: | Crossing Super Edition | Fuel Type: | diesel fuel |
engine model: | Weichai WP13.550E501 | Engine Brand: | Weichai |
Number of cylinders: | 6 cylinders | Fuel type: | diesel fuel |
Cylinder arrangement: | In-line | Displacement: | 12.54L |
Emission Standards: | National Five | Maximum horsepower: | 550 hp |
Maximum output power: | 405kW | Maximum Torque: | 2550N·m |
Maximum torque speed: | 1000-1400rpm | Rated speed: | 1900rpm |
Technical route: | Common Rail SCR | | |
Cab: | High Top | Number of passengers allowed: | 2 people |
Number of Seat Rows: | Half row | Cab lift: | electric |
Driver's seat type: | Airbag shock absorbing seat | Skylight: | Manual sunroof |
Gearbox Model: | Fast 12JSD180TA | Gearbox brand: | Fast |
Shifting method: | Manual | Forward gears: | 12 gears |
Reverse gear number: | 2 | | |
Permissible load on front axle: | 7000kg | Permissible load on rear axle: | 18000(two-axle group)kg |
Suspension type: | Leaf spring | Number of springs: | 2/4 |
Suspension type (front/rear): | Leaf spring suspension | | |
Number of tires: | 10 | Tire specifications: | 12R22.5 |
