Model NO.: | ZZ4257N3247E1H | Power: | Diesel |
---|---|---|---|
Load Capacity: | 31-40t | Emission Standard: | Euro6 |
Drive Wheel: | 4×2 | Seats: | ≤5 |
Horsepower: | 351-450hp | Engine Capacity: | >8L |
Tire Certification: | ECE, GCC, ISO, DOT | Tire Design: | Tubeless |
Condition: | New | Usage: | Towing Semi Trailer |
Fuel Tank: | 400L, 600L, 1000L | Driver Seat: | Air Suspension Seat |
Color: | Customized | Cargo Box Material: | Carbon Steel |
Steering System: | Hydraulic Steering With Power Assistance | Transport Package: | Nude Packing |
Specification: | 6.21x2.55x3.45m | Trademark: | Sinotruk |
Origin: | China Shandong | HS Code: | 8708991000 |
Supply Ability: | 1000pieces/Year | Package Size: | 621.00cm * 255.00cm * 345.00cm |
Package Gross Weight: | 6880.000kg | After-sales Service: | 6 Months |
Warranty: | 6 Months | Transmission Type: | Manual |
Customization: | Available | Customized Request | Shipping Cost : | About Shipping Cost And Estimated Delivery Time. |
: | Initial Payment Full Payment | Currency: | US$ |
Return&refunds: | You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
Basic Information | |||
driver license: | A2 | Announcement Model: | ZZ4187V361GF1 |
Drive type: | 4X2 | Wheelbase: | 3600mm |
engine: | Weichai WP10H400E62 | Gearbox: | Sinotruk 12-speed gearbox |
Body length: | 6.21 m | Body width: | 2.55 m |
Ride height: | 3.455m | Front track: | 2030mm |
Rear track: | 1816mm | Vehicle weight: | 6.8 tons |
Total mass: | 18 tons | Total traction mass: | 35 tons |
Maximum speed: | 89km/h | Origin: | Shandong |
Tonnage level: | Heavy Truck | Fuel Type: | diesel fuel |
Engine parameters | |||
engine model: | Weichai WP10H400E62 | Engine Brand: | Weichai |
Number of cylinders: | 6 cylinders | Fuel type: | diesel fuel |
Cylinder arrangement: | In-line | Displacement: | 9.5L |
Emission Standards: | Euro 5 | Maximum horsepower: | 400 hp |
Cab parameters | |||
Number of passengers allowed: | 2 people | Number of Seat Rows: | Half row |
Cab lift: | electric | Driver's seat type: | Airbag shock absorbing seat |
Gearbox parameters | |||
Gearbox Model: | Sinotruk 12-speed gearbox | Gearbox brand: | Sinotruk |
Shifting method: | Manual | Forward gears: | 12 gears |
Reverse gear number: | 2 | ||
Chassis parameters | |||
Rear Axle Description: | MCY13JGS self-adjusting arm single rear axle (drum) | Permissible load on front axle: | 6500kg |
Permissible load on rear axle: | 11500kg | Number of springs: | 3.5 |
tire | |||
Number of tires: | 6 | Tire specifications: | 12R22.5 18PR |
