8X4 Foton Ouman Dump Truck for Mining Transportation Hyva Front Lift Installed

Certification
China Jining Huahang International Trade Co., Ltd. certification
China Jining Huahang International Trade Co., Ltd. certification
I'm Online Chat Now

8X4 Foton Ouman Dump Truck for Mining Transportation Hyva Front Lift Installed

8X4 Foton Ouman Dump Truck for Mining Transportation Hyva Front Lift Installed
8X4 Foton Ouman Dump Truck for Mining Transportation Hyva Front Lift Installed 8X4 Foton Ouman Dump Truck for Mining Transportation Hyva Front Lift Installed 8X4 Foton Ouman Dump Truck for Mining Transportation Hyva Front Lift Installed 8X4 Foton Ouman Dump Truck for Mining Transportation Hyva Front Lift Installed 8X4 Foton Ouman Dump Truck for Mining Transportation Hyva Front Lift Installed 8X4 Foton Ouman Dump Truck for Mining Transportation Hyva Front Lift Installed

Large Image :  8X4 Foton Ouman Dump Truck for Mining Transportation Hyva Front Lift Installed

Product Details:
Certification: SGS
Payment & Shipping Terms:
Delivery Time: 7-15days

8X4 Foton Ouman Dump Truck for Mining Transportation Hyva Front Lift Installed

Description
Model NO.: BJ3319Y6GRL-01 Power: Diesel
Load Capacity: 31-40t Emission Standard: Euro 6
Drive Wheel: 8×4 Seats: ≤5
Horsepower: 351-450hp Engine Capacity: >8L
Tire Certification: ECE, GCC, ISO, DOT Tire Design: Tubeless
Condition: New Usage: Towing Semi Trailer
Fuel Tank: 400L, 600L, 1000L Driver Seat: Air Suspension Seat
Color: Customized Cargo Box Material: Carbon Steel
Steering System: Hydraulic Steering With Power Assistance Transport Package: Nude Packing
Specification: 8.76x2.55x3.65 Trademark: Futian
Origin: China Liangshan HS Code: 87019090
Supply Ability: 1000pieces/Year Package Size: 876.00cm * 255.00cm * 365.00cm
Package Gross Weight: 15500.000kg After-sales Service: 6 Months
Warranty: 6 Months Transmission Type: Manual
Customization: Available | Customized Request Shipping Cost : About Shipping Cost And Estimated Delivery Time.
 : Initial Payment Full Payment Currency: US$
Return&refunds: You Can Apply For A Refund Up To 30 Days After Receipt Of The Products.

Foton Ouman 6X4 8X4 10/12 Wheel Dump Truck for Mining Transportation, Equipped with Hyva Front Lift

Product Use

1. Definition of Tractor
A tractor, a paragon of versatility and strength, is a meticulously engineered light truck designed explicitly for towing vehicles or heavyweight loads along highways. Outfitted with numerous pairs of wheels and axles, it serves as an essential component in the transport of semi-trailers, luxury yachts, construction equipment, and more. As a cornerstone of heavy transport logistics, it is crucial to the success of a myriad of industries, providing unmatched reliability and performance.
2. The Structure of the Tractor
Comprising several key components such as the engine, transmission, tires, and frame, a tractor is a marvel of engineering. Enhanced with auxiliary devices like tow hooks, locking systems, and remote controls, it guarantees heightened operational efficiency and superior control, ensuring peak performance in every task it undertakes.
3. Tractor Application Fields
1. Transportation: In the realm of long-distance freight, tractors are indispensable for towing semi-trailers and large trucks. They assure the safe and dependable delivery of goods to their destinations, upholding reliability with their unwavering performance.
2. Construction Field: Tractors are pivotal in towing a wide variety of construction machinery, including excavators, bulldozers, and cranes. They enable the seamless transportation of heavy equipment to job sites with precision and ease, thereby boosting the efficiency of construction operations.

Basic Info.

Foton Ouman 6X4 8X4 10/12 Wheel Dump Truck for Mining Transportation, Equipped with Hyva Front Lift
Foton Ouman 6X4 8X4 10/12 Wheel Dump Truck for Mining Transportation, Equipped with Hyva Front Lift
Foton Ouman 6X4 8X4 10/12 Wheel Dump Truck for Mining Transportation, Equipped with Hyva Front Lift



Foton Ouman 6X4 8X4 10/12 Wheel Dump Truck for Mining Transportation, Equipped with Hyva Front Lift
Foton Ouman 6X4 8X4 10/12 Wheel Dump Truck for Mining Transportation, Equipped with Hyva Front Lift
Foton Ouman 6X4 8X4 10/12 Wheel Dump Truck for Mining Transportation, Equipped with Hyva Front Lift
Foton Ouman 6X4 8X4 10/12 Wheel Dump Truck for Mining Transportation, Equipped with Hyva Front Lift
Foton Ouman 6X4 8X4 10/12 Wheel Dump Truck for Mining Transportation, Equipped with Hyva Front Lift
Foton Ouman 6X4 8X4 10/12 Wheel Dump Truck for Mining Transportation, Equipped with Hyva Front Lift
Foton Ouman 6X4 8X4 10/12 Wheel Dump Truck for Mining Transportation, Equipped with Hyva Front LiftFoton Ouman 6X4 8X4 10/12 Wheel Dump Truck for Mining Transportation, Equipped with Hyva Front Lift

Foton Ouman 6X4 8X4 10/12 Wheel Dump Truck for Mining Transportation, Equipped with Hyva Front Lift
Foton Ouman 6X4 8X4 10/12 Wheel Dump Truck for Mining Transportation, Equipped with Hyva Front Lift
Foton Ouman 6X4 8X4 10/12 Wheel Dump Truck for Mining Transportation, Equipped with Hyva Front LiftFoton Ouman 6X4 8X4 10/12 Wheel Dump Truck for Mining Transportation, Equipped with Hyva Front LiftFoton Ouman 6X4 8X4 10/12 Wheel Dump Truck for Mining Transportation, Equipped with Hyva Front LiftFoton Ouman 6X4 8X4 10/12 Wheel Dump Truck for Mining Transportation, Equipped with Hyva Front Lift
Basic Information
Driving license: A1,A2,B2 Announcement Model: BJ3319Y6GRL-01
Drive type: 8X4 Wheelbase: 2100+2300+1400mm
engine: Foton DaimlerX12NS6B410 Gearbox: Fast 12JSD240A
Rear axle ratio: 5.92 Body length: 8.76 m
Body width: 2.55 m Ride height: 3.65 m
Front track: 2020/2020mm Rear track: 1880/1880mm
Vehicle weight: 15.5 tons Rated load: 15.37 tons
Total mass: 31 tons Tonnage level: Heavy Truck
Approach Angle: 18 degrees Departure angle: 16 degrees
Origin: Beijing Huairou Market Segments: Urban construction waste
Department: 9 Series Version: Basic
Fuel Type: diesel fuel
Engine parameters
Engine Model: Foton Daimler engineX12NS6B410 Engine Brand: Foton Daimler
Number of cylinders: 6 cylinders Fuel Type: diesel fuel
Displacement: 11.8L Emission standards: National VI
Maximum horsepower: 410 hp Maximum output power: 301kW
Maximum Torque: 2100Nm Maximum torque speed: 1000-1300rpm
Rated speed: 1900rpm
Cargo box parameters
Length of cargo box: 5.6 m Cargo box width: 2.35 m
Cargo box height: 1.5 m Cargo box form: Rear dump type
Cab parameters
Cab width: 2490mm
Gearbox parameters
Gearbox Model: Fast 12JSD240A Gearbox brand: Fast
Forward gears: 12 gears Reverse gear number: 2
tank
Fuel tank material: Aluminum Alloy Fuel tank capacity: 300L
Chassis parameters
Front axle description: 7.5T Permissible load on front axle: 6500/6500kg
Rear Axle Description: 16T Mercedes Benz Permissible load on rear axle: 18000(two-axle group)kg
Speed €atio: 5.92 Number of springs: 2010/10/12
tire
Tire specifications: 12.00R20 18PR Number of tires: 12
Foton Ouman 6X4 8X4 10/12 Wheel Dump Truck for Mining Transportation, Equipped with Hyva Front Lift


Shipment

Our specialization in shipping trucks is unparalleled, utilizing RO-RO vessels or bulk vessels for optimal safety and efficiency. Additionally, we offer shipping through special containers, catering to a broad spectrum of logistical needs with utmost convenience and ease.
Foton Ouman 6X4 8X4 10/12 Wheel Dump Truck for Mining Transportation, Equipped with Hyva Front Lift


Original Spare Parts
We are dedicated to providing authentic spare parts, supported by a superior after-sales service system. Our committed After-Market Division ensures outstanding service and swift delivery of parts through a highly efficient supply chain.
Foton Ouman 6X4 8X4 10/12 Wheel Dump Truck for Mining Transportation, Equipped with Hyva Front Lift

Our Product
Foton Ouman 6X4 8X4 10/12 Wheel Dump Truck for Mining Transportation, Equipped with Hyva Front Lift

Thank You for Choosing Us

Q: How about the delivery time?
A: We take pride in our swift delivery capabilities, with most trucks and machines available for delivery in an impressive 7 days. For specially ordered items, our detailed production process typically takes around 30 days, ensuring we uphold quality and excellence.

Q: How many units of truck do you produce per year?
A: Our robust manufacturing prowess is evident in our annual production of approximately 30,000 units. Maintaining a dynamic and efficient schedule, we update or manufacture around 5,000 units each month.

Q: How do you control the quality of the product?
A: Quality is paramount. Our factory is equipped with a state-of-the-art production workshop and a team of expertly trained workers. Every product is subjected to rigorous inspection processes, ensuring only top-tier quality. We also recondition our trucks and machines on specialized production lines to maintain superior standards.

Q: Do you accept custom orders? What is your MOQ?
A: Absolutely, we welcome custom orders to fulfill your unique needs. Our minimum order quantity (MOQ) is a mere 1 unit, demonstrating our flexibility and unwavering commitment to customer satisfaction.
