Foton 8X4 Dump Truck with Comfortable Air Suspension and Euro 6 Emission Standard

Certification
China Jining Huahang International Trade Co., Ltd. certification
China Jining Huahang International Trade Co., Ltd. certification
I'm Online Chat Now

Foton 8X4 Dump Truck with Comfortable Air Suspension and Euro 6 Emission Standard

Foton 8X4 Dump Truck with Comfortable Air Suspension and Euro 6 Emission Standard
Foton 8X4 Dump Truck with Comfortable Air Suspension and Euro 6 Emission Standard Foton 8X4 Dump Truck with Comfortable Air Suspension and Euro 6 Emission Standard Foton 8X4 Dump Truck with Comfortable Air Suspension and Euro 6 Emission Standard Foton 8X4 Dump Truck with Comfortable Air Suspension and Euro 6 Emission Standard Foton 8X4 Dump Truck with Comfortable Air Suspension and Euro 6 Emission Standard Foton 8X4 Dump Truck with Comfortable Air Suspension and Euro 6 Emission Standard

Large Image :  Foton 8X4 Dump Truck with Comfortable Air Suspension and Euro 6 Emission Standard

Product Details:
Certification: SGS
Payment & Shipping Terms:
Delivery Time: 7-15days

Foton 8X4 Dump Truck with Comfortable Air Suspension and Euro 6 Emission Standard

Description
Model NO.: BJ3319Y6GRL-01 Power: Diesel
Load Capacity: 31-40t Emission Standard: Euro 6
Drive Wheel: 8×4 Seats: ≤5
Horsepower: 351-450hp Engine Capacity: >8L
Tire Certification: ECE, GCC, ISO, DOT Tire Design: Tubeless
Condition: New Usage: Towing Semi Trailer
Fuel Tank: 400L, 600L, 1000L Driver Seat: Air Suspension Seat
Color: Customized Cargo Box Material: Carbon Steel
Steering System: Hydraulic Steering With Power Assistance Transport Package: Nude Packing
Specification: 8.76x2.55x3.65 Trademark: Futian
Origin: China Liangshan HS Code: 87019090
Supply Ability: 1000pieces/Year Package Size: 876.00cm * 255.00cm * 365.00cm
Package Gross Weight: 15500.000kg After-sales Service: 6 Months
Warranty: 6 Months Transmission Type: Manual
Customization: Available | Customized Request Shipping Cost : About Shipping Cost And Estimated Delivery Time.
 : Initial Payment Full Payment Currency: US$
Return&refunds: You Can Apply For A Refund Up To 30 Days After Receipt Of The Products.

Foton 8X4 Dump Truck and Air Suspension Comfort Dump Truck

Product Use

1. Definition of Tractor
A tractor is a dynamic, high-performance light truck, masterfully designed for towing vehicles or substantial loads on highways. Equipped with multiple pairs of wheels and axles, it stands as a pivotal tool for transporting semi-trailers, luxury yachts, and construction equipment. As a cornerstone of heavy transport, its significance spans diverse industries, making it indispensable.
2. The Structure of the Tractor
A tractor is constructed with essential components: the engine, transmission, tires, and frame. It may also feature advanced auxiliary devices like tow hooks, locking systems, and remote controls, enhancing efficiency and control for guaranteed superior performance.
3. Tractor Application Fields
1. Transportation: In the realm of long-distance freight, tractors are essential for towing semi-trailers and large trucks, ensuring goods are delivered safely and reliably to their final destinations.
2. Construction Field: Tractors are vital for towing a wide array of construction machinery, such as excavators, bulldozers, and cranes, seamlessly transporting heavy equipment to job sites.

Basic Info.

Foton 8X4 Dump Truck and Air Suspension Comfort Dump Truck
Foton 8X4 Dump Truck and Air Suspension Comfort Dump Truck
Foton 8X4 Dump Truck and Air Suspension Comfort Dump Truck



Foton 8X4 Dump Truck and Air Suspension Comfort Dump Truck
Foton 8X4 Dump Truck and Air Suspension Comfort Dump Truck
Foton 8X4 Dump Truck and Air Suspension Comfort Dump Truck
Foton 8X4 Dump Truck and Air Suspension Comfort Dump Truck
Foton 8X4 Dump Truck and Air Suspension Comfort Dump Truck
Foton 8X4 Dump Truck and Air Suspension Comfort Dump Truck


Foton 8X4 Dump Truck and Air Suspension Comfort Dump TruckFoton 8X4 Dump Truck and Air Suspension Comfort Dump Truck

Foton 8X4 Dump Truck and Air Suspension Comfort Dump Truck
Foton 8X4 Dump Truck and Air Suspension Comfort Dump Truck
Foton 8X4 Dump Truck and Air Suspension Comfort Dump TruckFoton 8X4 Dump Truck and Air Suspension Comfort Dump TruckFoton 8X4 Dump Truck and Air Suspension Comfort Dump TruckFoton 8X4 Dump Truck and Air Suspension Comfort Dump Truck
Basic Information
Driving license: A1,A2,B2 Announcement Model: BJ3319Y6GRL-01
Drive type: 8X4 Wheelbase: 2100+2300+1400mm
engine: Foton DaimlerX12NS6B410 Gearbox: Fast 12JSD240A
Rear axle ratio: 5.92 Body length: 8.76 m
Body width: 2.55 m Ride height: 3.65 m
Front track: 2020/2020mm Rear track: 1880/1880mm
Vehicle weight: 15.5 tons Rated load: 15.37 tons
Total mass: 31 tons Tonnage level: Heavy Truck
Approach Angle: 18 degrees Departure angle: 16 degrees
Origin: Beijing Huairou Market Segments: Urban construction waste
Department: 9 Series Version: Basic
Fuel Type: diesel fuel
Engine parameters
Engine Model: Foton Daimler engineX12NS6B410 Engine Brand: Foton Daimler
Number of cylinders: 6 cylinders Fuel Type: diesel fuel
Displacement: 11.8L Emission standards: National VI
Maximum horsepower: 410 hp Maximum output power: 301kW
Maximum Torque: 2100Nm Maximum torque speed: 1000-1300rpm
Rated speed: 1900rpm
Cargo box parameters
Length of cargo box: 5.6 m Cargo box width: 2.35 m
Cargo box height: 1.5 m Cargo box form: Rear dump type
Cab parameters
Cab width: 2490mm
Gearbox parameters
Gearbox Model: Fast 12JSD240A Gearbox brand: Fast
Forward gears: 12 gears Reverse gear number: 2
tank
Fuel tank material: Aluminum Alloy Fuel tank capacity: 300L
Chassis parameters
Front axle description: 7.5T Permissible load on front axle: 6500/6500kg
Rear Axle Description: 16T Mercedes Benz Permissible load on rear axle: 18000(two-axle group)kg
Speed €atio: 5.92 Number of springs: 2010/10/12
tire
Tire specifications: 12.00R20 18PR Number of tires: 12
Foton 8X4 Dump Truck and Air Suspension Comfort Dump Truck


Shipment

Our expertise in shipping trucks comes primarily through RO-RO vessel or bulk vessel, assuring safety and efficiency. We also offer special container shipping, catering to diverse logistical needs with utmost convenience and simplicity.
Foton 8X4 Dump Truck and Air Suspension Comfort Dump Truck


Original Spare Parts
We are committed to providing authentic spare parts backed by an unparalleled after-sales service system. Our devoted After-Market Division ensures excellent service and rapid delivery of parts through a highly efficient supply chain.
Foton 8X4 Dump Truck and Air Suspension Comfort Dump Truck

Our Product
Foton 8X4 Dump Truck and Air Suspension Comfort Dump Truck

Thank You for Choosing Us

Q: How about the delivery time?
A: We take pride in our swift delivery capabilities, with most trucks and machines available in just 7 days. For specially ordered items, our meticulous production process generally requires about 30 days, ensuring quality and excellence are never compromised.

Q: How many units of truck do you produce per year?
A: Our robust manufacturing capabilities see us producing nearly 30,000 units annually. With around 5,000 units either updated or manufactured each month, we sustain a dynamic and efficient production schedule.

Q: How do you control the quality of the product?
A: Quality is our utmost priority. Our factory boasts a standard production workshop and a team of highly-trained workers. Every product undergoes a rigorous inspection process, ensuring top-notch quality. We also recondition trucks and machines on a specialized production line to maintain superior standards.

Q: Do you accept custom orders? What is your MOQ?
A: Absolutely, we welcome custom orders to meet your specific needs. Our minimum order quantity (MOQ) is just 1 unit, demonstrating our flexibility and commitment to customer satisfaction.
