2024 Foton Ouman 8X4 Dump Truck 12 Wheel Dump Truck with 6 Months After-sales Service

Certification
China Jining Huahang International Trade Co., Ltd. certification
China Jining Huahang International Trade Co., Ltd. certification
I'm Online Chat Now

2024 Foton Ouman 8X4 Dump Truck 12 Wheel Dump Truck with 6 Months After-sales Service

2024 Foton Ouman 8X4 Dump Truck 12 Wheel Dump Truck with 6 Months After-sales Service
2024 Foton Ouman 8X4 Dump Truck 12 Wheel Dump Truck with 6 Months After-sales Service 2024 Foton Ouman 8X4 Dump Truck 12 Wheel Dump Truck with 6 Months After-sales Service 2024 Foton Ouman 8X4 Dump Truck 12 Wheel Dump Truck with 6 Months After-sales Service 2024 Foton Ouman 8X4 Dump Truck 12 Wheel Dump Truck with 6 Months After-sales Service 2024 Foton Ouman 8X4 Dump Truck 12 Wheel Dump Truck with 6 Months After-sales Service 2024 Foton Ouman 8X4 Dump Truck 12 Wheel Dump Truck with 6 Months After-sales Service

Large Image :  2024 Foton Ouman 8X4 Dump Truck 12 Wheel Dump Truck with 6 Months After-sales Service

Product Details:
Certification: SGS
Payment & Shipping Terms:
Delivery Time: 7-15days

2024 Foton Ouman 8X4 Dump Truck 12 Wheel Dump Truck with 6 Months After-sales Service

Description
Model NO.: BJ3319Y6GRL-01 Power: Diesel
Load Capacity: 31-40t Emission Standard: Euro 6
Drive Wheel: 8×4 Seats: ≤5
Horsepower: 351-450hp Engine Capacity: >8L
Tire Certification: ECE, GCC, ISO, DOT Tire Design: Tubeless
Condition: New Usage: Towing Semi Trailer
Fuel Tank: 400L, 600L, 1000L Driver Seat: Air Suspension Seat
Color: Customized Cargo Box Material: Carbon Steel
Steering System: Hydraulic Steering With Power Assistance Transport Package: Nude Packing
Specification: 8.76x2.55x3.65 Trademark: Futian
Origin: China Liangshan HS Code: 87019090
Supply Ability: 1000pieces/Year Package Size: 876.00cm * 255.00cm * 365.00cm
Package Gross Weight: 15500.000kg After-sales Service: 6 Months
Warranty: 6 Months Transmission Type: Manual
Customization: Available | Customized Request Shipping Cost : About Shipping Cost And Estimated Delivery Time.
 : Initial Payment Full Payment Currency: US$
Return&refunds: You Can Apply For A Refund Up To 30 Days After Receipt Of The Products.

2024 Foton Ouman 8X4 Dump Truck 12 Wheel Dump Truck

Product Use

1. Definition of Tractor
A tractor is an incredibly versatile and robust light truck, masterfully designed for towing vehicles or heavy loads along highways. Equipped with multiple pairs of wheels and axles, it is indispensable for the transportation of semi-trailers, luxury yachts, construction equipment, and more. As a pivotal element in heavy transport, it is crucial across numerous industries.
2. The Structure of the Tractor
A tractor is constructed with several essential components, including the engine, transmission, tires, and frame. It may also feature auxiliary devices such as tow hooks, locking systems, and remote controls that enhance its operational efficiency and control, ensuring superior performance at all times.
3. Tractor Application Fields
1. Transportation: In the domain of long-distance freight, tractors are vital for towing semi-trailers and large trucks, ensuring the secure and efficient delivery of goods to their destinations.
2. Construction Field: Tractors play a crucial role in towing a diverse array of construction machinery, including excavators, bulldozers, and cranes, seamlessly facilitating the transport of heavy equipment to construction sites.

Basic Info.

2024 Foton Ouman 8X4 Dump Truck 12 Wheel Dump Truck
2024 Foton Ouman 8X4 Dump Truck 12 Wheel Dump Truck
2024 Foton Ouman 8X4 Dump Truck 12 Wheel Dump Truck



2024 Foton Ouman 8X4 Dump Truck 12 Wheel Dump Truck
2024 Foton Ouman 8X4 Dump Truck 12 Wheel Dump Truck
2024 Foton Ouman 8X4 Dump Truck 12 Wheel Dump Truck
2024 Foton Ouman 8X4 Dump Truck 12 Wheel Dump Truck
2024 Foton Ouman 8X4 Dump Truck 12 Wheel Dump Truck
2024 Foton Ouman 8X4 Dump Truck 12 Wheel Dump Truck


2024 Foton Ouman 8X4 Dump Truck 12 Wheel Dump Truck2024 Foton Ouman 8X4 Dump Truck 12 Wheel Dump Truck

2024 Foton Ouman 8X4 Dump Truck 12 Wheel Dump Truck
2024 Foton Ouman 8X4 Dump Truck 12 Wheel Dump Truck
2024 Foton Ouman 8X4 Dump Truck 12 Wheel Dump Truck2024 Foton Ouman 8X4 Dump Truck 12 Wheel Dump Truck2024 Foton Ouman 8X4 Dump Truck 12 Wheel Dump Truck2024 Foton Ouman 8X4 Dump Truck 12 Wheel Dump Truck
Basic Information
Driving license: A1,A2,B2 Announcement Model: BJ3319Y6GRL-01
Drive type: 8X4 Wheelbase: 2100+2300+1400mm
engine: Foton DaimlerX12NS6B410 Gearbox: Fast 12JSD240A
Rear axle ratio: 5.92 Body length: 8.76 m
Body width: 2.55 m Ride height: 3.65 m
Front track: 2020/2020mm Rear track: 1880/1880mm
Vehicle weight: 15.5 tons Rated load: 15.37 tons
Total mass: 31 tons Tonnage level: Heavy Truck
Approach Angle: 18 degrees Departure angle: 16 degrees
Origin: Beijing Huairou Market Segments: Urban construction waste
Department: 9 Series Version: Basic
Fuel Type: diesel fuel
Engine parameters
Engine Model: Foton Daimler engineX12NS6B410 Engine Brand: Foton Daimler
Number of cylinders: 6 cylinders Fuel Type: diesel fuel
Displacement: 11.8L Emission standards: National VI
Maximum horsepower: 410 hp Maximum output power: 301kW
Maximum Torque: 2100Nm Maximum torque speed: 1000-1300rpm
Rated speed: 1900rpm
Cargo box parameters
Length of cargo box: 5.6 m Cargo box width: 2.35 m
Cargo box height: 1.5 m Cargo box form: Rear dump type
Cab parameters
Cab width: 2490mm
Gearbox parameters
Gearbox Model: Fast 12JSD240A Gearbox brand: Fast
Forward gears: 12 gears Reverse gear number: 2
tank
Fuel tank material: Aluminum Alloy Fuel tank capacity: 300L
Chassis parameters
Front axle description: 7.5T Permissible load on front axle: 6500/6500kg
Rear Axle Description: 16T Mercedes Benz Permissible load on rear axle: 18000(two-axle group)kg
Speed €atio: 5.92 Number of springs: 2010/10/12
tire
Tire specifications: 12.00R20 18PR Number of tires: 12
2024 Foton Ouman 8X4 Dump Truck 12 Wheel Dump Truck


Shipment

We specialize in shipping trucks primarily via RO-RO vessels or bulk vessels, ensuring both safety and efficiency. Additionally, we provide shipping through special containers, catering to a wide array of logistical demands with the utmost convenience and simplicity.
2024 Foton Ouman 8X4 Dump Truck 12 Wheel Dump Truck


Original Spare Parts
We are committed to providing genuine spare parts alongside a comprehensive and unparalleled after-sales service system. Our dedicated After-Market Division guarantees exceptional service and swift delivery of parts through an efficient and streamlined supply chain.
2024 Foton Ouman 8X4 Dump Truck 12 Wheel Dump Truck

Our Product
2024 Foton Ouman 8X4 Dump Truck 12 Wheel Dump Truck

Thank You for Choosing Us

Q: How about the delivery time?
A: We pride ourselves on the availability of most of our trucks and machines, which can be dispatched with remarkable speed in just 7 days. For special orders, our meticulous production process generally requires around 30 days, ensuring quality and excellence are consistently upheld.

Q: How many units of truck do you produce per year?
A: Demonstrating our robust manufacturing capacities, we produce nearly 30,000 units annually. With approximately 5,000 units either updated or manufactured each month, we maintain a dynamic and efficient production schedule.

Q: How do you control the quality of the product?
A: Quality is our utmost priority. Our factory is equipped with a state-of-the-art production workshop and a team of highly-skilled workers. Each product undergoes a rigorous inspection process, ensuring top-tier quality. We also recondition our trucks and machines on a specialized production line to uphold superior standards.

Q: Do you accept custom orders? What is your MOQ?
A: Absolutely, we welcome custom orders to meet your specific needs. Our minimum order quantity (MOQ) is just 1 unit, reflecting our flexibility and commitment to customer satisfaction.
