2024 Ouman 8X4 Dump Truck 12 Wheel Tipping Bucket Transport Truck with 30 Days Return

Certification
China Jining Huahang International Trade Co., Ltd. certification
China Jining Huahang International Trade Co., Ltd. certification
I'm Online Chat Now

2024 Ouman 8X4 Dump Truck 12 Wheel Tipping Bucket Transport Truck with 30 Days Return

2024 Ouman 8X4 Dump Truck 12 Wheel Tipping Bucket Transport Truck with 30 Days Return
2024 Ouman 8X4 Dump Truck 12 Wheel Tipping Bucket Transport Truck with 30 Days Return 2024 Ouman 8X4 Dump Truck 12 Wheel Tipping Bucket Transport Truck with 30 Days Return 2024 Ouman 8X4 Dump Truck 12 Wheel Tipping Bucket Transport Truck with 30 Days Return 2024 Ouman 8X4 Dump Truck 12 Wheel Tipping Bucket Transport Truck with 30 Days Return 2024 Ouman 8X4 Dump Truck 12 Wheel Tipping Bucket Transport Truck with 30 Days Return 2024 Ouman 8X4 Dump Truck 12 Wheel Tipping Bucket Transport Truck with 30 Days Return

Large Image :  2024 Ouman 8X4 Dump Truck 12 Wheel Tipping Bucket Transport Truck with 30 Days Return

Product Details:
Certification: SGS
Payment & Shipping Terms:
Delivery Time: 7-15days

2024 Ouman 8X4 Dump Truck 12 Wheel Tipping Bucket Transport Truck with 30 Days Return

Description
Model NO.: BJ3319Y6GRL-01 Power: Diesel
Load Capacity: 31-40t Emission Standard: Euro 6
Drive Wheel: 8×4 Seats: ≤5
Horsepower: 351-450hp Engine Capacity: >8L
Tire Certification: ECE, GCC, ISO, DOT Tire Design: Tubeless
Condition: New Usage: Towing Semi Trailer
Fuel Tank: 400L, 600L, 1000L Driver Seat: Air Suspension Seat
Color: Customized Cargo Box Material: Carbon Steel
Steering System: Hydraulic Steering With Power Assistance Transport Package: Nude Packing
Specification: 8.76x2.55x3.65 Trademark: Futian
Origin: China Liangshan HS Code: 87019090
Supply Ability: 1000pieces/Year Package Size: 876.00cm * 255.00cm * 365.00cm
Package Gross Weight: 15500.000kg After-sales Service: 6 Months
Warranty: 6 Months Transmission Type: Manual
Customization: Available | Customized Request Shipping Cost : About Shipping Cost And Estimated Delivery Time.
 : Initial Payment Full Payment Currency: US$
Return&refunds: You Can Apply For A Refund Up To 30 Days After Receipt Of The Products.

2024, 30 Ton Ouman 8X4 Dump Truck, 12 Wheel Tipping Bucket Transport Truck

Usage of Our Product

1. Comprehensive Definition of a Tractor
A tractor represents the pinnacle of engineering as a versatile and robust light truck, meticulously designed for towing vehicles or substantial loads across highways. Equipped with multiple pairs of wheels and axles, it is an indispensable asset for transporting semi-trailers, luxury yachts, construction equipment, and beyond. As a cornerstone in the realm of heavy transport, it is integral to a multitude of industries.
2. Detailed Structure of the Tractor
A tractor is an assembly of vital components such as the engine, transmission, tires, and frame. It may also feature auxiliary devices including tow hooks, locking systems, and remote controls. These elements collectively enhance its efficiency and control, ensuring superior and dependable performance.
3. Diverse Application Fields of Tractors
1. Transportation Sector: In the domain of long-distance freight, tractors are crucial for towing semi-trailers and large trucks, ensuring goods are delivered safely and reliably to their destinations.
2. Construction Sector: Tractors play a pivotal role in towing a vast array of construction machinery, such as excavators, bulldozers, and cranes, making the transport of heavy equipment to job sites seamless and efficient.

Basic Information.

2024, 30 Ton Ouman 8X4 Dump Truck, 12 Wheel Tipping Bucket Transport Truck
2024, 30 Ton Ouman 8X4 Dump Truck, 12 Wheel Tipping Bucket Transport Truck
2024, 30 Ton Ouman 8X4 Dump Truck, 12 Wheel Tipping Bucket Transport Truck



2024, 30 Ton Ouman 8X4 Dump Truck, 12 Wheel Tipping Bucket Transport Truck
2024, 30 Ton Ouman 8X4 Dump Truck, 12 Wheel Tipping Bucket Transport Truck
2024, 30 Ton Ouman 8X4 Dump Truck, 12 Wheel Tipping Bucket Transport Truck
2024, 30 Ton Ouman 8X4 Dump Truck, 12 Wheel Tipping Bucket Transport Truck
2024, 30 Ton Ouman 8X4 Dump Truck, 12 Wheel Tipping Bucket Transport Truck
2024, 30 Ton Ouman 8X4 Dump Truck, 12 Wheel Tipping Bucket Transport Truck


2024, 30 Ton Ouman 8X4 Dump Truck, 12 Wheel Tipping Bucket Transport Truck2024, 30 Ton Ouman 8X4 Dump Truck, 12 Wheel Tipping Bucket Transport Truck

2024, 30 Ton Ouman 8X4 Dump Truck, 12 Wheel Tipping Bucket Transport Truck
2024, 30 Ton Ouman 8X4 Dump Truck, 12 Wheel Tipping Bucket Transport Truck
2024, 30 Ton Ouman 8X4 Dump Truck, 12 Wheel Tipping Bucket Transport Truck2024, 30 Ton Ouman 8X4 Dump Truck, 12 Wheel Tipping Bucket Transport Truck2024, 30 Ton Ouman 8X4 Dump Truck, 12 Wheel Tipping Bucket Transport Truck2024, 30 Ton Ouman 8X4 Dump Truck, 12 Wheel Tipping Bucket Transport Truck
Basic Information
Driving license: A1,A2,B2 Announcement Model: BJ3319Y6GRL-01
Drive type: 8X4 Wheelbase: 2100+2300+1400mm
engine: Foton DaimlerX12NS6B410 Gearbox: Fast 12JSD240A
Rear axle ratio: 5.92 Body length: 8.76 m
Body width: 2.55 m Ride height: 3.65 m
Front track: 2020/2020mm Rear track: 1880/1880mm
Vehicle weight: 15.5 tons Rated load: 15.37 tons
Total mass: 31 tons Tonnage level: Heavy Truck
Approach Angle: 18 degrees Departure angle: 16 degrees
Origin: Beijing Huairou Market Segments: Urban construction waste
Department: 9 Series Version: Basic
Fuel Type: diesel fuel
Engine parameters
Engine Model: Foton Daimler engineX12NS6B410 Engine Brand: Foton Daimler
Number of cylinders: 6 cylinders Fuel Type: diesel fuel
Displacement: 11.8L Emission standards: National VI
Maximum horsepower: 410 hp Maximum output power: 301kW
Maximum Torque: 2100Nm Maximum torque speed: 1000-1300rpm
Rated speed: 1900rpm
Cargo box parameters
Length of cargo box: 5.6 m Cargo box width: 2.35 m
Cargo box height: 1.5 m Cargo box form: Rear dump type
Cab parameters
Cab width: 2490mm
Gearbox parameters
Gearbox Model: Fast 12JSD240A Gearbox brand: Fast
Forward gears: 12 gears Reverse gear number: 2
tank
Fuel tank material: Aluminum Alloy Fuel tank capacity: 300L
Chassis parameters
Front axle description: 7.5T Permissible load on front axle: 6500/6500kg
Rear Axle Description: 16T Mercedes Benz Permissible load on rear axle: 18000(two-axle group)kg
Speed €atio: 5.92 Number of springs: 2010/10/12
tire
Tire specifications: 12.00R20 18PR Number of tires: 12
2024, 30 Ton Ouman 8X4 Dump Truck, 12 Wheel Tipping Bucket Transport Truck


Shipment Details

We specialize in shipping trucks primarily via RO-RO vessel or bulk vessel, prioritizing safety and efficiency. Moreover, we offer shipping through special containers to meet a broad spectrum of logistical requirements with utmost convenience and ease.
2024, 30 Ton Ouman 8X4 Dump Truck, 12 Wheel Tipping Bucket Transport Truck


Authentic Spare Parts
We are committed to providing genuine spare parts with a comprehensive and unparalleled after-sales service system. Our dedicated After-Market Division ensures exceptional service and prompt delivery of parts through an efficient and streamlined supply chain.
2024, 30 Ton Ouman 8X4 Dump Truck, 12 Wheel Tipping Bucket Transport Truck

About Our Product
2024, 30 Ton Ouman 8X4 Dump Truck, 12 Wheel Tipping Bucket Transport Truck

Thank You for Your Trust in Us

Q: What is the delivery time frame?
A: We are proud to offer most of our trucks and machines for delivery in an impressively swift 7 days. For specially ordered items, our meticulous production process usually takes about 30 days, ensuring quality and excellence are consistently prioritized.

Q: What is your annual production capacity for trucks?
A: Demonstrating our robust manufacturing capabilities, we produce approximately 30,000 units per year. With around 5,000 units either being updated or manufactured each month, we maintain a dynamic and efficient production schedule.

Q: How is the quality of your products managed?
A: Quality is our utmost priority. Our factory boasts a standard production workshop and a team of highly-skilled workers. Each product undergoes a stringent inspection process to ensure top-notch quality. Additionally, we recondition our trucks and machines on a specialized production line to uphold superior standards.

Q: Do you accept custom orders? What is the minimum order quantity (MOQ)?
A: Absolutely, we enthusiastically welcome custom orders to meet your unique needs. Our minimum order quantity (MOQ) is just 1 unit, showcasing our flexibility and commitment to customer satisfaction.
