31-40t Load Capacity Foton Dump Truck with 12 Wheels and Air Suspension Driver Seat

Description
Model NO.: BJ3319Y6GRL-01 Power: Diesel
Load Capacity: 31-40t Emission Standard: Euro 6
Drive Wheel: 8×4 Seats: ≤5
Horsepower: 351-450hp Engine Capacity: >8L
Tire Certification: ECE, GCC, ISO, DOT Tire Design: Tubeless
Condition: New Usage: Towing Semi Trailer
Fuel Tank: 400L, 600L, 1000L Driver Seat: Air Suspension Seat
Color: Customized Cargo Box Material: Carbon Steel
Steering System: Hydraulic Steering With Power Assistance Transport Package: Nude Packing
Specification: 8.76x2.55x3.65 Trademark: Futian
Origin: China Liangshan HS Code: 87019090
Supply Ability: 1000pieces/Year Package Size: 876.00cm * 255.00cm * 365.00cm
Package Gross Weight: 15500.000kg After-sales Service: 6 Months
Warranty: 6 Months Transmission Type: Manual
Customization: Available | Customized Request Shipping Cost : About Shipping Cost And Estimated Delivery Time.
 : Initial Payment Full Payment Currency: US$
Return&refunds: You Can Apply For A Refund Up To 30 Days After Receipt Of The Products.

Vehicle Foton Dump Truck 12 Wheels with Air Suspension Driver Seat

Product Use

1. Definition of Tractor
A tractor is a highly versatile and robust light truck that has been meticulously designed to excel in towing vehicles or heavy loads along highways. With its multiple pairs of wheels and axles, it becomes an indispensable asset, making it essential for transporting semi-trailers, luxury yachts, construction equipment, and more. As a cornerstone of heavy transport logistics, this vehicle is vital to numerous industries, ensuring seamless and efficient transportation solutions.
2. The Structure of the Tractor
A tractor comprises several vital components, including the engine, transmission, tires, and frame, all working in harmony for peak performance. It can be enhanced with auxiliary devices such as tow hooks, locking systems, and remote controls, which significantly boost its operational efficiency and ensure optimal control, resulting in superior performance.
3. Tractor Application Fields
1. Transportation: Within the realm of long-distance freight, tractors prove indispensable for towing semi-trailers and large trucks. They provide safe, reliable, and dependable delivery of goods to their final destinations, ensuring unwavering dependability and seamless logistics.
2. Construction Field: Tractors are crucial for towing a diverse range of construction machinery, including excavators, bulldozers, and cranes. They facilitate the effortless and precise transportation of heavy equipment to job sites, ensuring efficiency and productivity in the construction field.

Basic Info.

Vehicle Foton Dump Truck 12 Wheels with Air Suspension Driver Seat
Vehicle Foton Dump Truck 12 Wheels with Air Suspension Driver Seat
Vehicle Foton Dump Truck 12 Wheels with Air Suspension Driver Seat



Vehicle Foton Dump Truck 12 Wheels with Air Suspension Driver Seat
Vehicle Foton Dump Truck 12 Wheels with Air Suspension Driver Seat
Vehicle Foton Dump Truck 12 Wheels with Air Suspension Driver Seat
Vehicle Foton Dump Truck 12 Wheels with Air Suspension Driver Seat
Vehicle Foton Dump Truck 12 Wheels with Air Suspension Driver Seat
Vehicle Foton Dump Truck 12 Wheels with Air Suspension Driver Seat
Vehicle Foton Dump Truck 12 Wheels with Air Suspension Driver SeatVehicle Foton Dump Truck 12 Wheels with Air Suspension Driver Seat

Vehicle Foton Dump Truck 12 Wheels with Air Suspension Driver Seat
Vehicle Foton Dump Truck 12 Wheels with Air Suspension Driver Seat
Vehicle Foton Dump Truck 12 Wheels with Air Suspension Driver SeatVehicle Foton Dump Truck 12 Wheels with Air Suspension Driver SeatVehicle Foton Dump Truck 12 Wheels with Air Suspension Driver SeatVehicle Foton Dump Truck 12 Wheels with Air Suspension Driver Seat
Basic Information
Driving license: A1,A2,B2 Announcement Model: BJ3319Y6GRL-01
Drive type: 8X4 Wheelbase: 2100+2300+1400mm
engine: Foton DaimlerX12NS6B410 Gearbox: Fast 12JSD240A
Rear axle ratio: 5.92 Body length: 8.76 m
Body width: 2.55 m Ride height: 3.65 m
Front track: 2020/2020mm Rear track: 1880/1880mm
Vehicle weight: 15.5 tons Rated load: 15.37 tons
Total mass: 31 tons Tonnage level: Heavy Truck
Approach Angle: 18 degrees Departure angle: 16 degrees
Origin: Beijing Huairou Market Segments: Urban construction waste
Department: 9 Series Version: Basic
Fuel Type: diesel fuel
Engine parameters
Engine Model: Foton Daimler engineX12NS6B410 Engine Brand: Foton Daimler
Number of cylinders: 6 cylinders Fuel Type: diesel fuel
Displacement: 11.8L Emission standards: National VI
Maximum horsepower: 410 hp Maximum output power: 301kW
Maximum Torque: 2100Nm Maximum torque speed: 1000-1300rpm
Rated speed: 1900rpm
Cargo box parameters
Length of cargo box: 5.6 m Cargo box width: 2.35 m
Cargo box height: 1.5 m Cargo box form: Rear dump type
Cab parameters
Cab width: 2490mm
Gearbox parameters
Gearbox Model: Fast 12JSD240A Gearbox brand: Fast
Forward gears: 12 gears Reverse gear number: 2
tank
Fuel tank material: Aluminum Alloy Fuel tank capacity: 300L
Chassis parameters
Front axle description: 7.5T Permissible load on front axle: 6500/6500kg
Rear Axle Description: 16T Mercedes Benz Permissible load on rear axle: 18000(two-axle group)kg
Speed €atio: 5.92 Number of springs: 2010/10/12
tire
Tire specifications: 12.00R20 18PR Number of tires: 12
