Product Details:
Certification: SGS
Payment & Shipping Terms:
Delivery Time: 7-15days

Foton Ouman 8X4 12 Wheel Dump Truck for Mining Transportation and Self Dumping Truck

Description
Model NO.: BJ3319Y6GRL-01 Power: Diesel
Load Capacity: 31-40t Emission Standard: Euro 6
Drive Wheel: 8×4 Seats: ≤5
Horsepower: 351-450hp Engine Capacity: >8L
Tire Certification: ECE, GCC, ISO, DOT Tire Design: Tubeless
Condition: New Usage: Towing Semi Trailer
Fuel Tank: 400L, 600L, 1000L Driver Seat: Air Suspension Seat
Color: Customized Cargo Box Material: Carbon Steel
Steering System: Hydraulic Steering With Power Assistance Transport Package: Nude Packing
Specification: 8.76x2.55x3.65 Trademark: Futian
Origin: China Liangshan HS Code: 87019090
Supply Ability: 1000pieces/Year Package Size: 876.00cm * 255.00cm * 365.00cm
Package Gross Weight: 15500.000kg After-sales Service: 6 Months
Warranty: 6 Months Transmission Type: Manual
Customization: Available | Customized Request Shipping Cost : About Shipping Cost And Estimated Delivery Time.
 : Initial Payment Full Payment Currency: US$
Return&refunds: You Can Apply For A Refund Up To 30 Days After Receipt Of The Products.

Foton Ouman 8X4 12 Wheel Dump Truck for Mining Transportation and Self Dumping Truck

Product Use

1. Definition of Tractor
A tractor is an exceptionally versatile and powerful light truck, expertly engineered for towing vehicles or handling heavyweight loads with utmost precision along highways. Outfitted with numerous wheels and axles, it emerges as an invaluable asset for transporting semi-trailers, luxury yachts, and construction equipment. As a pivotal element in heavy transport logistics, it serves a crucial role in a wide array of industries.
2. The Structure of the Tractor
A tractor is composed of essential components, including the engine, transmission, tires, and frame. It can be further enhanced with auxiliary devices such as tow hooks, locking systems, and remote controls, all designed to elevate its operational efficiency and ensure superior control for optimal performance.
3. Tractor Application Fields
1. Transportation: In long-distance freight, tractors are indispensable for towing semi-trailers and large trucks, ensuring the safe and reliable delivery of goods to their final destinations with unparalleled dependability.
2. Construction Field: Tractors are vital in towing a diverse range of construction machinery, such as excavators, bulldozers, and cranes, facilitating the seamless transportation of heavy equipment to job sites with impeccable precision.

Basic Info.

Foton Ouman 8X4 12 Wheel Dump Truck for Mining Transportation and Self Dumping Truck
Foton Ouman 8X4 12 Wheel Dump Truck for Mining Transportation and Self Dumping Truck
Foton Ouman 8X4 12 Wheel Dump Truck for Mining Transportation and Self Dumping Truck



Foton Ouman 8X4 12 Wheel Dump Truck for Mining Transportation and Self Dumping Truck
Foton Ouman 8X4 12 Wheel Dump Truck for Mining Transportation and Self Dumping Truck
Foton Ouman 8X4 12 Wheel Dump Truck for Mining Transportation and Self Dumping Truck
Foton Ouman 8X4 12 Wheel Dump Truck for Mining Transportation and Self Dumping Truck
Foton Ouman 8X4 12 Wheel Dump Truck for Mining Transportation and Self Dumping Truck
Foton Ouman 8X4 12 Wheel Dump Truck for Mining Transportation and Self Dumping Truck
Foton Ouman 8X4 12 Wheel Dump Truck for Mining Transportation and Self Dumping TruckFoton Ouman 8X4 12 Wheel Dump Truck for Mining Transportation and Self Dumping Truck

Foton Ouman 8X4 12 Wheel Dump Truck for Mining Transportation and Self Dumping Truck
Foton Ouman 8X4 12 Wheel Dump Truck for Mining Transportation and Self Dumping Truck
Foton Ouman 8X4 12 Wheel Dump Truck for Mining Transportation and Self Dumping TruckFoton Ouman 8X4 12 Wheel Dump Truck for Mining Transportation and Self Dumping TruckFoton Ouman 8X4 12 Wheel Dump Truck for Mining Transportation and Self Dumping TruckFoton Ouman 8X4 12 Wheel Dump Truck for Mining Transportation and Self Dumping Truck
Basic Information
Driving license: A1,A2,B2 Announcement Model: BJ3319Y6GRL-01
Drive type: 8X4 Wheelbase: 2100+2300+1400mm
engine: Foton DaimlerX12NS6B410 Gearbox: Fast 12JSD240A
Rear axle ratio: 5.92 Body length: 8.76 m
Body width: 2.55 m Ride height: 3.65 m
Front track: 2020/2020mm Rear track: 1880/1880mm
Vehicle weight: 15.5 tons Rated load: 15.37 tons
Total mass: 31 tons Tonnage level: Heavy Truck
Approach Angle: 18 degrees Departure angle: 16 degrees
Origin: Beijing Huairou Market Segments: Urban construction waste
Department: 9 Series Version: Basic
Fuel Type: diesel fuel
Engine parameters
Engine Model: Foton Daimler engineX12NS6B410 Engine Brand: Foton Daimler
Number of cylinders: 6 cylinders Fuel Type: diesel fuel
Displacement: 11.8L Emission standards: National VI
Maximum horsepower: 410 hp Maximum output power: 301kW
Maximum Torque: 2100Nm Maximum torque speed: 1000-1300rpm
Rated speed: 1900rpm
Cargo box parameters
Length of cargo box: 5.6 m Cargo box width: 2.35 m
Cargo box height: 1.5 m Cargo box form: Rear dump type
Cab parameters
Cab width: 2490mm
Gearbox parameters
Gearbox Model: Fast 12JSD240A Gearbox brand: Fast
Forward gears: 12 gears Reverse gear number: 2
tank
Fuel tank material: Aluminum Alloy Fuel tank capacity: 300L
Chassis parameters
Front axle description: 7.5T Permissible load on front axle: 6500/6500kg
Rear Axle Description: 16T Mercedes Benz Permissible load on rear axle: 18000(two-axle group)kg
Speed €atio: 5.92 Number of springs: 2010/10/12
tire
Tire specifications: 12.00R20 18PR Number of tires: 12
Foton Ouman 8X4 12 Wheel Dump Truck for Mining Transportation and Self Dumping Truck


Shipment

Our expertise lies in shipping trucks primarily via RO-RO or bulk vessels, guaranteeing both safety and efficiency. Additionally, we offer shipping through special containers, catering to an extensive range of logistical needs with utmost convenience and simplicity.
Foton Ouman 8X4 12 Wheel Dump Truck for Mining Transportation and Self Dumping Truck


Original Spare Parts
We are dedicated to providing genuine spare parts backed by an unparalleled after-sales service system. Our dedicated After-Market Division ensures remarkable service and prompt delivery of parts through a streamlined and efficient supply chain.
Foton Ouman 8X4 12 Wheel Dump Truck for Mining Transportation and Self Dumping Truck

Our Product
Foton Ouman 8X4 12 Wheel Dump Truck for Mining Transportation and Self Dumping Truck

Thank You for Choosing Us

Q: How about the delivery time?
A: We take pride in the rapid availability of most of our trucks and machines, delivering them with remarkable speed in just 7 days. For specially ordered items, our meticulous production process typically requires about 30 days, ensuring that quality and excellence remain uncompromised.

Q: How many units of truck do you produce per year?
A: Showcasing our robust manufacturing capabilities, we produce around 30,000 units annually. With approximately 5,000 units either updated or manufactured each month, we uphold a dynamic and efficient production schedule.

Q: How do you control the quality of the product?
A: Quality is of paramount importance to us. Our factory is equipped with a standard production workshop and a team of highly-skilled workers. Each product undergoes an exhaustive inspection process to ensure top-notch quality. Furthermore, we recondition our trucks and machines on a specialized production line to maintain superior standards.

Q: Do you accept custom orders? What is your MOQ?
A: Absolutely, we welcome custom orders to meet your unique requirements. Our minimum order quantity (MOQ) is just 1 unit, underscoring our flexibility and dedication to customer satisfaction.
