Customizable 2024 Ouman 6X4 8X4 Dump Truck 12 Wheel Dump Truck with Customized Request

Certification
China Jining Huahang International Trade Co., Ltd. certification
China Jining Huahang International Trade Co., Ltd. certification
I'm Online Chat Now

Customizable 2024 Ouman 6X4 8X4 Dump Truck 12 Wheel Dump Truck with Customized Request

Customizable 2024 Ouman 6X4 8X4 Dump Truck 12 Wheel Dump Truck with Customized Request
Customizable 2024 Ouman 6X4 8X4 Dump Truck 12 Wheel Dump Truck with Customized Request Customizable 2024 Ouman 6X4 8X4 Dump Truck 12 Wheel Dump Truck with Customized Request Customizable 2024 Ouman 6X4 8X4 Dump Truck 12 Wheel Dump Truck with Customized Request Customizable 2024 Ouman 6X4 8X4 Dump Truck 12 Wheel Dump Truck with Customized Request Customizable 2024 Ouman 6X4 8X4 Dump Truck 12 Wheel Dump Truck with Customized Request Customizable 2024 Ouman 6X4 8X4 Dump Truck 12 Wheel Dump Truck with Customized Request

Large Image :  Customizable 2024 Ouman 6X4 8X4 Dump Truck 12 Wheel Dump Truck with Customized Request

Product Details:
Certification: SGS
Payment & Shipping Terms:
Delivery Time: 7-15days

Customizable 2024 Ouman 6X4 8X4 Dump Truck 12 Wheel Dump Truck with Customized Request

Description
Model NO.: BJ3319Y6GRL-01 Power: Diesel
Load Capacity: 31-40t Emission Standard: Euro 6
Drive Wheel: 8×4 Seats: ≤5
Horsepower: 351-450hp Engine Capacity: >8L
Tire Certification: ECE, GCC, ISO, DOT Tire Design: Tubeless
Condition: New Usage: Towing Semi Trailer
Fuel Tank: 400L, 600L, 1000L Driver Seat: Air Suspension Seat
Color: Customized Cargo Box Material: Carbon Steel
Steering System: Hydraulic Steering With Power Assistance Transport Package: Nude Packing
Specification: 8.76x2.55x3.65 Trademark: Futian
Origin: China Liangshan HS Code: 87019090
Supply Ability: 1000pieces/Year Package Size: 876.00cm * 255.00cm * 365.00cm
Package Gross Weight: 15500.000kg After-sales Service: 6 Months
Warranty: 6 Months Transmission Type: Manual
Customization: Available | Customized Request Shipping Cost : About Shipping Cost And Estimated Delivery Time.
 : Initial Payment Full Payment Currency: US$
Return&refunds: You Can Apply For A Refund Up To 30 Days After Receipt Of The Products.

2024 New Ouman 6X4, 8X4 Dump Truck 12 Wheel Dump Truck

Product Use

1. Definition of Tractor
A tractor is a highly versatile and robust light truck, meticulously crafted for towing vehicles or heavyweight loads along highways. Equipped with multiple pairs of wheels and axles, it stands as an indispensable asset for transporting semi-trailers, luxury yachts, construction equipment, and much more. As a cornerstone of heavy transport logistics, it plays an integral role across a myriad of industries.
2. The Structure of the Tractor
A tractor consists of several vital components, including the engine, transmission, tires, and frame. It may also be enhanced with auxiliary devices such as tow hooks, locking systems, and remote controls, all of which increase its operational efficiency and ensure optimal control for superior performance.
3. Tractor Application Fields
1. Transportation: In the domain of long-distance freight, tractors are essential for towing semi-trailers and large trucks, providing the safe and reliable delivery of goods to their final destinations with unwavering dependability.
2. Construction Field: Tractors play a crucial role in towing a diverse array of construction machinery, such as excavators, bulldozers, and cranes, seamlessly facilitating the transportation of heavy equipment to job sites with effortless precision.

Basic Info.

2024 New Ouman 6X4, 8X4 Dump Truck 12 Wheel Dump Truck
2024 New Ouman 6X4, 8X4 Dump Truck 12 Wheel Dump Truck
2024 New Ouman 6X4, 8X4 Dump Truck 12 Wheel Dump Truck



2024 New Ouman 6X4, 8X4 Dump Truck 12 Wheel Dump Truck
2024 New Ouman 6X4, 8X4 Dump Truck 12 Wheel Dump Truck
2024 New Ouman 6X4, 8X4 Dump Truck 12 Wheel Dump Truck
2024 New Ouman 6X4, 8X4 Dump Truck 12 Wheel Dump Truck
2024 New Ouman 6X4, 8X4 Dump Truck 12 Wheel Dump Truck
2024 New Ouman 6X4, 8X4 Dump Truck 12 Wheel Dump Truck


2024 New Ouman 6X4, 8X4 Dump Truck 12 Wheel Dump Truck2024 New Ouman 6X4, 8X4 Dump Truck 12 Wheel Dump Truck

2024 New Ouman 6X4, 8X4 Dump Truck 12 Wheel Dump Truck
2024 New Ouman 6X4, 8X4 Dump Truck 12 Wheel Dump Truck
2024 New Ouman 6X4, 8X4 Dump Truck 12 Wheel Dump Truck2024 New Ouman 6X4, 8X4 Dump Truck 12 Wheel Dump Truck2024 New Ouman 6X4, 8X4 Dump Truck 12 Wheel Dump Truck2024 New Ouman 6X4, 8X4 Dump Truck 12 Wheel Dump Truck
Basic Information
Driving license: A1,A2,B2 Announcement Model: BJ3319Y6GRL-01
Drive type: 8X4 Wheelbase: 2100+2300+1400mm
engine: Foton DaimlerX12NS6B410 Gearbox: Fast 12JSD240A
Rear axle ratio: 5.92 Body length: 8.76 m
Body width: 2.55 m Ride height: 3.65 m
Front track: 2020/2020mm Rear track: 1880/1880mm
Vehicle weight: 15.5 tons Rated load: 15.37 tons
Total mass: 31 tons Tonnage level: Heavy Truck
Approach Angle: 18 degrees Departure angle: 16 degrees
Origin: Beijing Huairou Market Segments: Urban construction waste
Department: 9 Series Version: Basic
Fuel Type: diesel fuel
Engine parameters
Engine Model: Foton Daimler engineX12NS6B410 Engine Brand: Foton Daimler
Number of cylinders: 6 cylinders Fuel Type: diesel fuel
Displacement: 11.8L Emission standards: National VI
Maximum horsepower: 410 hp Maximum output power: 301kW
Maximum Torque: 2100Nm Maximum torque speed: 1000-1300rpm
Rated speed: 1900rpm
Cargo box parameters
Length of cargo box: 5.6 m Cargo box width: 2.35 m
Cargo box height: 1.5 m Cargo box form: Rear dump type
Cab parameters
Cab width: 2490mm
Gearbox parameters
Gearbox Model: Fast 12JSD240A Gearbox brand: Fast
Forward gears: 12 gears Reverse gear number: 2
tank
Fuel tank material: Aluminum Alloy Fuel tank capacity: 300L
Chassis parameters
Front axle description: 7.5T Permissible load on front axle: 6500/6500kg
Rear Axle Description: 16T Mercedes Benz Permissible load on rear axle: 18000(two-axle group)kg
Speed €atio: 5.92 Number of springs: 2010/10/12
tire
Tire specifications: 12.00R20 18PR Number of tires: 12
2024 New Ouman 6X4, 8X4 Dump Truck 12 Wheel Dump Truck


Shipment

We specialize in shipping trucks primarily via RO-RO vessel or bulk vessel, ensuring both safety and efficiency. Furthermore, we provide shipping through special containers that serve a wide range of logistical needs with utmost convenience and ease.
2024 New Ouman 6X4, 8X4 Dump Truck 12 Wheel Dump Truck


Original Spare Parts
We are committed to delivering genuine spare parts complemented by an unmatched after-sales service system. Our dedicated After-Market Division ensures exemplary service and swift delivery of parts through an efficient and streamlined supply chain.
2024 New Ouman 6X4, 8X4 Dump Truck 12 Wheel Dump Truck

Our Product
2024 New Ouman 6X4, 8X4 Dump Truck 12 Wheel Dump Truck

Thank You for Choosing Us

Q: How about the delivery time?
A: We pride ourselves on the availability of most of our trucks and machines, which can be delivered with remarkable speed in just 7 days. For specially ordered items, our meticulous production process generally requires about 30 days, ensuring quality and excellence are never compromised.

Q: How many units of truck do you produce per year?
A: Demonstrating our strong manufacturing capabilities, we produce approximately 30,000 units annually. With around 5,000 units either updated or manufactured each month, we maintain a dynamic and efficient production schedule.

Q: How do you control the quality of the product?
A: Quality is our utmost priority. Our factory is equipped with a standard production workshop and a team of highly-trained workers. Every product undergoes a thorough inspection process, ensuring top-notch quality. Additionally, we recondition our trucks and machines on a specialized production line to uphold superior standards.

Q: Do you accept custom orders? What is your MOQ?
A: Certainly, we embrace custom orders to meet your distinct requirements. Our minimum order quantity (MOQ) is just 1 unit, emphasizing our flexibility and commitment to customer satisfaction.
