Air Suspension Seat and 600L Fuel Tank Foton 8X4 Tipper for Long Distance Travel

Certification
China Jining Huahang International Trade Co., Ltd. certification
China Jining Huahang International Trade Co., Ltd. certification
I'm Online Chat Now

Air Suspension Seat and 600L Fuel Tank Foton 8X4 Tipper for Long Distance Travel

Air Suspension Seat and 600L Fuel Tank Foton 8X4 Tipper for Long Distance Travel
Air Suspension Seat and 600L Fuel Tank Foton 8X4 Tipper for Long Distance Travel Air Suspension Seat and 600L Fuel Tank Foton 8X4 Tipper for Long Distance Travel Air Suspension Seat and 600L Fuel Tank Foton 8X4 Tipper for Long Distance Travel Air Suspension Seat and 600L Fuel Tank Foton 8X4 Tipper for Long Distance Travel Air Suspension Seat and 600L Fuel Tank Foton 8X4 Tipper for Long Distance Travel Air Suspension Seat and 600L Fuel Tank Foton 8X4 Tipper for Long Distance Travel

Large Image :  Air Suspension Seat and 600L Fuel Tank Foton 8X4 Tipper for Long Distance Travel

Product Details:
Certification: SGS
Payment & Shipping Terms:
Delivery Time: 7-15days

Air Suspension Seat and 600L Fuel Tank Foton 8X4 Tipper for Long Distance Travel

Description
Model NO.: BJ3319Y6GRL-01 Power: Diesel
Load Capacity: 31-40t Emission Standard: Euro 6
Drive Wheel: 8×4 Seats: ≤5
Horsepower: 351-450hp Engine Capacity: >8L
Tire Certification: ECE, GCC, ISO, DOT Tire Design: Tubeless
Condition: New Usage: Towing Semi Trailer
Fuel Tank: 400L, 600L, 1000L Driver Seat: Air Suspension Seat
Color: Customized Cargo Box Material: Carbon Steel
Steering System: Hydraulic Steering With Power Assistance Transport Package: Nude Packing
Specification: 8.76x2.55x3.65 Trademark: Futian
Origin: China Liangshan HS Code: 87019090
Supply Ability: 1000pieces/Year Package Size: 876.00cm * 255.00cm * 365.00cm
Package Gross Weight: 15500.000kg After-sales Service: 6 Months
Warranty: 6 Months Transmission Type: Manual
Customization: Available | Customized Request Shipping Cost : About Shipping Cost And Estimated Delivery Time.
 : Initial Payment Full Payment Currency: US$
Return&refunds: You Can Apply For A Refund Up To 30 Days After Receipt Of The Products.

Foton 8X4 Tipper with 600L Fuel Tank and Air Suspension Seat

Product Use

1. Definition of Tractor
A tractor, a beacon of versatility and strength, stands as a meticulously crafted marvel of light truck engineering, designed to tow vehicles or heavyweight cargo across highways with precision. Equipped with an array of wheels and axles, it is indispensable in the transportation of semi-trailers, luxury yachts, construction equipment, and more. As the lifeline of heavy transport logistics, it ensures the seamless operation of diverse industries, offering unwavering reliability and exceptional performance.
2. The Structure of the Tractor
Crafted with an intricate assembly of pivotal components such as the engine, transmission, tires, and frame, the tractor embodies engineering excellence. Augmented with auxiliary devices like tow hooks, locking mechanisms, and remote controls, it delivers heightened operational efficiency and unmatched control, guaranteeing optimal performance in every task it undertakes.
3. Tractor Application Fields
1. Transportation: In the arena of long-distance freight, tractors are vital for towing semi-trailers and large trucks. They ensure the secure and reliable delivery of goods to their ultimate destinations, maintaining consistency with their steadfast performance.
2. Construction Field: Tractors play a critical role in transporting a diverse range of construction machinery, such as excavators, bulldozers, and cranes. They facilitate the smooth and precise movement of heavy equipment to job sites, thereby enhancing the efficiency of construction operations.

Basic Info.

Foton 8X4 Tipper with 600L Fuel Tank and Air Suspension Seat
Foton 8X4 Tipper with 600L Fuel Tank and Air Suspension Seat
Foton 8X4 Tipper with 600L Fuel Tank and Air Suspension Seat



Foton 8X4 Tipper with 600L Fuel Tank and Air Suspension Seat
Foton 8X4 Tipper with 600L Fuel Tank and Air Suspension Seat
Foton 8X4 Tipper with 600L Fuel Tank and Air Suspension Seat
Foton 8X4 Tipper with 600L Fuel Tank and Air Suspension Seat
Foton 8X4 Tipper with 600L Fuel Tank and Air Suspension Seat
Foton 8X4 Tipper with 600L Fuel Tank and Air Suspension Seat
Foton 8X4 Tipper with 600L Fuel Tank and Air Suspension SeatFoton 8X4 Tipper with 600L Fuel Tank and Air Suspension Seat

Foton 8X4 Tipper with 600L Fuel Tank and Air Suspension Seat
Foton 8X4 Tipper with 600L Fuel Tank and Air Suspension Seat
Foton 8X4 Tipper with 600L Fuel Tank and Air Suspension SeatFoton 8X4 Tipper with 600L Fuel Tank and Air Suspension SeatFoton 8X4 Tipper with 600L Fuel Tank and Air Suspension SeatFoton 8X4 Tipper with 600L Fuel Tank and Air Suspension Seat
Basic Information
Driving license: A1,A2,B2 Announcement Model: BJ3319Y6GRL-01
Drive type: 8X4 Wheelbase: 2100+2300+1400mm
engine: Foton DaimlerX12NS6B410 Gearbox: Fast 12JSD240A
Rear axle ratio: 5.92 Body length: 8.76 m
Body width: 2.55 m Ride height: 3.65 m
Front track: 2020/2020mm Rear track: 1880/1880mm
Vehicle weight: 15.5 tons Rated load: 15.37 tons
Total mass: 31 tons Tonnage level: Heavy Truck
Approach Angle: 18 degrees Departure angle: 16 degrees
Origin: Beijing Huairou Market Segments: Urban construction waste
Department: 9 Series Version: Basic
Fuel Type: diesel fuel
Engine parameters
Engine Model: Foton Daimler engineX12NS6B410 Engine Brand: Foton Daimler
Number of cylinders: 6 cylinders Fuel Type: diesel fuel
Displacement: 11.8L Emission standards: National VI
Maximum horsepower: 410 hp Maximum output power: 301kW
Maximum Torque: 2100Nm Maximum torque speed: 1000-1300rpm
Rated speed: 1900rpm
Cargo box parameters
Length of cargo box: 5.6 m Cargo box width: 2.35 m
Cargo box height: 1.5 m Cargo box form: Rear dump type
Cab parameters
Cab width: 2490mm
Gearbox parameters
Gearbox Model: Fast 12JSD240A Gearbox brand: Fast
Forward gears: 12 gears Reverse gear number: 2
tank
Fuel tank material: Aluminum Alloy Fuel tank capacity: 300L
Chassis parameters
Front axle description: 7.5T Permissible load on front axle: 6500/6500kg
Rear Axle Description: 16T Mercedes Benz Permissible load on rear axle: 18000(two-axle group)kg
Speed €atio: 5.92 Number of springs: 2010/10/12
tire
Tire specifications: 12.00R20 18PR Number of tires: 12
Foton 8X4 Tipper with 600L Fuel Tank and Air Suspension Seat


Shipment

Our expertise in the shipping of trucks is unmatched, leveraging RO-RO vessels or bulk vessels to ensure maximum safety and efficiency. We also provide shipping through specialized containers, accommodating a wide range of logistical needs with utmost ease and convenience.
Foton 8X4 Tipper with 600L Fuel Tank and Air Suspension Seat


Original Spare Parts
We are committed to delivering genuine spare parts, bolstered by an exceptional after-sales service system. Our dedicated After-Market Division ensures exemplary service and prompt delivery of parts via a highly efficient supply chain.
Foton 8X4 Tipper with 600L Fuel Tank and Air Suspension Seat

Our Product
Foton 8X4 Tipper with 600L Fuel Tank and Air Suspension Seat

Thank You for Choosing Us

Q: How about the delivery time?
A: We are proud of our swift delivery efficiency, with most trucks and machines ready for dispatch within an impressive 7 days. For custom orders, our meticulous production process usually spans around 30 days, ensuring our commitment to quality and excellence is upheld.

Q: How many units of truck do you produce per year?
A: Our formidable manufacturing capability is reflected in our yearly production of approximately 30,000 units. We maintain a dynamic and efficient operation, updating or manufacturing around 5,000 units each month.

Q: How do you control the quality of the product?
A: Quality is our utmost priority. Our factory is outfitted with a cutting-edge production workshop and a team of expertly trained workers. Each product undergoes rigorous inspection processes to ensure only the finest quality. Additionally, we recondition our trucks and machines on specialized production lines to uphold superior standards.

Q: Do you accept custom orders? What is your MOQ?
A: Certainly, we embrace custom orders to cater to your distinct needs. Our minimum order quantity (MOQ) is just 1 unit, highlighting our flexibility and unwavering dedication to customer satisfaction.
