6X4 8X4 10/12 Wheel Options Diesel Mining Dump Truck with ≤5 Seats from Foton Ouman

Certification
China Jining Huahang International Trade Co., Ltd. certification
China Jining Huahang International Trade Co., Ltd. certification
I'm Online Chat Now

6X4 8X4 10/12 Wheel Options Diesel Mining Dump Truck with ≤5 Seats from Foton Ouman

6X4 8X4 10/12 Wheel Options Diesel Mining Dump Truck with ≤5 Seats from Foton Ouman
6X4 8X4 10/12 Wheel Options Diesel Mining Dump Truck with ≤5 Seats from Foton Ouman 6X4 8X4 10/12 Wheel Options Diesel Mining Dump Truck with ≤5 Seats from Foton Ouman 6X4 8X4 10/12 Wheel Options Diesel Mining Dump Truck with ≤5 Seats from Foton Ouman 6X4 8X4 10/12 Wheel Options Diesel Mining Dump Truck with ≤5 Seats from Foton Ouman 6X4 8X4 10/12 Wheel Options Diesel Mining Dump Truck with ≤5 Seats from Foton Ouman 6X4 8X4 10/12 Wheel Options Diesel Mining Dump Truck with ≤5 Seats from Foton Ouman

Large Image :  6X4 8X4 10/12 Wheel Options Diesel Mining Dump Truck with ≤5 Seats from Foton Ouman

Product Details:
Certification: SGS
Payment & Shipping Terms:
Delivery Time: 7-15days

6X4 8X4 10/12 Wheel Options Diesel Mining Dump Truck with ≤5 Seats from Foton Ouman

Description
Model NO.: BJ3319Y6GRL-01 Power: Diesel
Load Capacity: 31-40t Emission Standard: Euro 6
Drive Wheel: 8×4 Seats: ≤5
Horsepower: 351-450hp Engine Capacity: >8L
Tire Certification: ECE, GCC, ISO, DOT Tire Design: Tubeless
Condition: New Usage: Towing Semi Trailer
Fuel Tank: 400L, 600L, 1000L Driver Seat: Air Suspension Seat
Color: Customized Cargo Box Material: Carbon Steel
Steering System: Hydraulic Steering With Power Assistance Transport Package: Nude Packing
Specification: 8.76x2.55x3.65 Trademark: Futian
Origin: China Liangshan HS Code: 87019090
Supply Ability: 1000pieces/Year Package Size: 876.00cm * 255.00cm * 365.00cm
Package Gross Weight: 15500.000kg After-sales Service: 6 Months
Warranty: 6 Months Transmission Type: Manual
Customization: Available | Customized Request Shipping Cost : About Shipping Cost And Estimated Delivery Time.
 : Initial Payment Full Payment Currency: US$
Return&refunds: You Can Apply For A Refund Up To 30 Days After Receipt Of The Products.

Foton Ouman Mining Dump Truck with 6X4 8X4 10/12 Wheel Options

Product Use

1. Definition of Tractor
A tractor stands as a beacon of versatility and power-a meticulously crafted light truck engineered for towing vehicles or heavy loads on highways. Equipped with multiple pairs of wheels and axles, it is indispensable in transporting semi-trailers, luxury yachts, and construction machinery. As a cornerstone of heavy transport logistics, it is essential to the triumph of various industries, delivering unmatched reliability and stellar performance.
2. The Structure of the Tractor
A tractor, a marvel of engineering, consists of key components such as the engine, transmission, tires, and frame. Equipped with auxiliary devices like tow hooks, locking mechanisms, and remote controls, it guarantees enhanced operational efficiency and superior command, ensuring peak performance in every task.
3. Tractor Application Fields
1. Transportation: In long-distance freight, tractors are vital for towing semi-trailers and large trucks, ensuring the safe and reliable delivery of goods to their destinations with unwavering performance.
2. Construction Field: Tractors are crucial in towing a variety of construction machinery like excavators, bulldozers, and cranes. They enable seamless transport of heavy equipment to job sites with precision, enhancing construction operations' efficiency.

Basic Info.

Foton Ouman Mining Dump Truck with 6X4 8X4 10/12 Wheel Options
Foton Ouman Mining Dump Truck with 6X4 8X4 10/12 Wheel Options
Foton Ouman Mining Dump Truck with 6X4 8X4 10/12 Wheel Options



Foton Ouman Mining Dump Truck with 6X4 8X4 10/12 Wheel Options
Foton Ouman Mining Dump Truck with 6X4 8X4 10/12 Wheel Options
Foton Ouman Mining Dump Truck with 6X4 8X4 10/12 Wheel Options
Foton Ouman Mining Dump Truck with 6X4 8X4 10/12 Wheel Options
Foton Ouman Mining Dump Truck with 6X4 8X4 10/12 Wheel Options
Foton Ouman Mining Dump Truck with 6X4 8X4 10/12 Wheel Options
Foton Ouman Mining Dump Truck with 6X4 8X4 10/12 Wheel OptionsFoton Ouman Mining Dump Truck with 6X4 8X4 10/12 Wheel Options

Foton Ouman Mining Dump Truck with 6X4 8X4 10/12 Wheel Options
Foton Ouman Mining Dump Truck with 6X4 8X4 10/12 Wheel Options
Foton Ouman Mining Dump Truck with 6X4 8X4 10/12 Wheel OptionsFoton Ouman Mining Dump Truck with 6X4 8X4 10/12 Wheel OptionsFoton Ouman Mining Dump Truck with 6X4 8X4 10/12 Wheel OptionsFoton Ouman Mining Dump Truck with 6X4 8X4 10/12 Wheel Options
Basic Information
Driving license: A1,A2,B2 Announcement Model: BJ3319Y6GRL-01
Drive type: 8X4 Wheelbase: 2100+2300+1400mm
engine: Foton DaimlerX12NS6B410 Gearbox: Fast 12JSD240A
Rear axle ratio: 5.92 Body length: 8.76 m
Body width: 2.55 m Ride height: 3.65 m
Front track: 2020/2020mm Rear track: 1880/1880mm
Vehicle weight: 15.5 tons Rated load: 15.37 tons
Total mass: 31 tons Tonnage level: Heavy Truck
Approach Angle: 18 degrees Departure angle: 16 degrees
Origin: Beijing Huairou Market Segments: Urban construction waste
Department: 9 Series Version: Basic
Fuel Type: diesel fuel
Engine parameters
Engine Model: Foton Daimler engineX12NS6B410 Engine Brand: Foton Daimler
Number of cylinders: 6 cylinders Fuel Type: diesel fuel
Displacement: 11.8L Emission standards: National VI
Maximum horsepower: 410 hp Maximum output power: 301kW
Maximum Torque: 2100Nm Maximum torque speed: 1000-1300rpm
Rated speed: 1900rpm
Cargo box parameters
Length of cargo box: 5.6 m Cargo box width: 2.35 m
Cargo box height: 1.5 m Cargo box form: Rear dump type
Cab parameters
Cab width: 2490mm
Gearbox parameters
Gearbox Model: Fast 12JSD240A Gearbox brand: Fast
Forward gears: 12 gears Reverse gear number: 2
tank
Fuel tank material: Aluminum Alloy Fuel tank capacity: 300L
Chassis parameters
Front axle description: 7.5T Permissible load on front axle: 6500/6500kg
Rear Axle Description: 16T Mercedes Benz Permissible load on rear axle: 18000(two-axle group)kg
Speed €atio: 5.92 Number of springs: 2010/10/12
tire
Tire specifications: 12.00R20 18PR Number of tires: 12
Foton Ouman Mining Dump Truck with 6X4 8X4 10/12 Wheel Options


Shipment

Our expertise in shipping trucks is unmatched, leveraging RO-RO vessels or bulk vessels for optimal safety and efficiency. We also offer shipping in special containers, meeting a wide range of logistical needs with ultimate convenience and ease.
Foton Ouman Mining Dump Truck with 6X4 8X4 10/12 Wheel Options


Original Spare Parts
We are committed to supplying genuine spare parts, backed by an outstanding after-sales service system. Our dedicated After-Market Division ensures exceptional service and quick delivery of parts through an efficient supply chain.
Foton Ouman Mining Dump Truck with 6X4 8X4 10/12 Wheel Options

Our Product
Foton Ouman Mining Dump Truck with 6X4 8X4 10/12 Wheel Options

Thank You for Choosing Us

Q: How about the delivery time?
A: We pride ourselves on rapid delivery, with most trucks and machines ready in just 7 days. For specially ordered items, our detailed production process typically spans around 30 days, ensuring our commitment to quality and excellence.

Q: How many units of truck do you produce per year?
A: Our robust manufacturing capability is reflected in our annual production of approximately 30,000 units. Maintaining a dynamic schedule, we update or manufacture around 5,000 units each month.

Q: How do you control the quality of the product?
A: Quality is our top priority. Our factory boasts a state-of-the-art production workshop and a team of expertly trained workers. Every product undergoes rigorous inspections, ensuring top-tier quality. We also recondition trucks and machines on specialized production lines to maintain superior standards.

Q: Do you accept custom orders? What is your MOQ?
A: Certainly, we welcome custom orders to cater to your specific needs. Our minimum order quantity (MOQ) is just 1 unit, showcasing our flexibility and commitment to customer satisfaction.
