BJ3319Y6GRL-01 Foton Hauler with Air Suspension Seat 6 Months After-sales Service

Certification
China Jining Huahang International Trade Co., Ltd. certification
China Jining Huahang International Trade Co., Ltd. certification
I'm Online Chat Now

BJ3319Y6GRL-01 Foton Hauler with Air Suspension Seat 6 Months After-sales Service

BJ3319Y6GRL-01 Foton Hauler with Air Suspension Seat 6 Months After-sales Service
BJ3319Y6GRL-01 Foton Hauler with Air Suspension Seat 6 Months After-sales Service BJ3319Y6GRL-01 Foton Hauler with Air Suspension Seat 6 Months After-sales Service BJ3319Y6GRL-01 Foton Hauler with Air Suspension Seat 6 Months After-sales Service BJ3319Y6GRL-01 Foton Hauler with Air Suspension Seat 6 Months After-sales Service BJ3319Y6GRL-01 Foton Hauler with Air Suspension Seat 6 Months After-sales Service BJ3319Y6GRL-01 Foton Hauler with Air Suspension Seat 6 Months After-sales Service

Large Image :  BJ3319Y6GRL-01 Foton Hauler with Air Suspension Seat 6 Months After-sales Service

Product Details:
Certification: SGS
Payment & Shipping Terms:
Delivery Time: 7-15days

BJ3319Y6GRL-01 Foton Hauler with Air Suspension Seat 6 Months After-sales Service

Description
Model NO.: BJ3319Y6GRL-01 Power: Diesel
Load Capacity: 31-40t Emission Standard: Euro 6
Drive Wheel: 8×4 Seats: ≤5
Horsepower: 351-450hp Engine Capacity: >8L
Tire Certification: ECE, GCC, ISO, DOT Tire Design: Tubeless
Condition: New Usage: Towing Semi Trailer
Fuel Tank: 400L, 600L, 1000L Driver Seat: Air Suspension Seat
Color: Customized Cargo Box Material: Carbon Steel
Steering System: Hydraulic Steering With Power Assistance Transport Package: Nude Packing
Specification: 8.76x2.55x3.65 Trademark: Futian
Origin: China Liangshan HS Code: 87019090
Supply Ability: 1000pieces/Year Package Size: 876.00cm * 255.00cm * 365.00cm
Package Gross Weight: 15500.000kg After-sales Service: 6 Months
Warranty: 6 Months Transmission Type: Manual
Customization: Available | Customized Request Shipping Cost : About Shipping Cost And Estimated Delivery Time.
 : Initial Payment Full Payment Currency: US$
Return&refunds: You Can Apply For A Refund Up To 30 Days After Receipt Of The Products.

Reliable Used Dump Truck, Foton Hauler with Air Suspension Seat

Product Use

1. Definition of Tractor
A tractor is a mighty machine symbolizing indomitable versatility and outstanding power, expertly crafted as a light truck precisely for towing vehicles or substantial loads across expansive highways. With its multitude of wheels and axles, it plays an essential role in transporting semi-trailers, luxury yachts, and hefty construction equipment. Standing as a cornerstone of heavy transport logistics, the tractor is vital to numerous industries, delivering unmatched reliability and superb performance.
2. The Structure of the Tractor
Engineered with vital components such as a potent engine, an intricate transmission system, resilient tires, and a strong frame, the tractor is an engineering marvel. Augmented with auxiliary enhancements like robust tow hooks, advanced locking systems, and intuitive remote controls, it ensures superior efficiency and precise control in operations, guaranteeing peak performance in every task it undertakes.
3. Tractor Application Fields
1. Transportation: In the world of long-haul freight, tractors are indispensable for towing semi-trailers and large trucks, ensuring goods reach their destinations safely and reliably with consistent high performance.
2. Construction Field: Tractors are crucial in towing various construction machinery, such as excavators, bulldozers, and cranes, facilitating the effortless transport of heavy equipment to job sites, thus greatly improving construction operation efficiency.

Basic Info.

Reliable Used Dump Truck, Foton Hauler with Air Suspension Seat
Reliable Used Dump Truck, Foton Hauler with Air Suspension Seat
Reliable Used Dump Truck, Foton Hauler with Air Suspension Seat



Reliable Used Dump Truck, Foton Hauler with Air Suspension Seat
Reliable Used Dump Truck, Foton Hauler with Air Suspension Seat
Reliable Used Dump Truck, Foton Hauler with Air Suspension Seat
Reliable Used Dump Truck, Foton Hauler with Air Suspension Seat
Reliable Used Dump Truck, Foton Hauler with Air Suspension Seat
Reliable Used Dump Truck, Foton Hauler with Air Suspension Seat


Reliable Used Dump Truck, Foton Hauler with Air Suspension Seat
Reliable Used Dump Truck, Foton Hauler with Air Suspension Seat
Reliable Used Dump Truck, Foton Hauler with Air Suspension Seat
Basic Information
Driving license: A1,A2,B2 Announcement Model: BJ3319Y6GRL-01
Drive type: 8X4 Wheelbase: 2100+2300+1400mm
engine: Foton DaimlerX12NS6B410 Gearbox: Fast 12JSD240A
Rear axle ratio: 5.92 Body length: 8.76 m
Body width: 2.55 m Ride height: 3.65 m
Front track: 2020/2020mm Rear track: 1880/1880mm
Vehicle weight: 15.5 tons Rated load: 15.37 tons
Total mass: 31 tons Tonnage level: Heavy Truck
Approach Angle: 18 degrees Departure angle: 16 degrees
Origin: Beijing Huairou Market Segments: Urban construction waste
Department: 9 Series Version: Basic
Fuel Type: diesel fuel
Engine parameters
Engine Model: Foton Daimler engineX12NS6B410 Engine Brand: Foton Daimler
Number of cylinders: 6 cylinders Fuel Type: diesel fuel
Displacement: 11.8L Emission standards: National VI
Maximum horsepower: 410 hp Maximum output power: 301kW
Maximum Torque: 2100Nm Maximum torque speed: 1000-1300rpm
Rated speed: 1900rpm
Cargo box parameters
Length of cargo box: 5.6 m Cargo box width: 2.35 m
Cargo box height: 1.5 m Cargo box form: Rear dump type
Cab parameters
Cab width: 2490mm
Gearbox parameters
Gearbox Model: Fast 12JSD240A Gearbox brand: Fast
Forward gears: 12 gears Reverse gear number: 2
tank
Fuel tank material: Aluminum Alloy Fuel tank capacity: 300L
Chassis parameters
Front axle description: 7.5T Permissible load on front axle: 6500/6500kg
Rear Axle Description: 16T Mercedes Benz Permissible load on rear axle: 18000(two-axle group)kg
Speed €atio: 5.92 Number of springs: 2010/10/12
tire
Tire specifications: 12.00R20 18PR Number of tires: 12
Reliable Used Dump Truck, Foton Hauler with Air Suspension Seat


Shipment

Our expertise in truck shipping is unrivaled, utilizing cutting-edge RO-RO or bulk vessels to guarantee maximum safety and efficiency. We also offer specialized container shipping, meticulously catering to a wide range of logistical needs with utmost convenience.
Reliable Used Dump Truck, Foton Hauler with Air Suspension Seat


Original Spare Parts
We are committed to providing genuine spare parts, bolstered by an exemplary after-sales service system. Our dedicated After-Market Division delivers outstanding service and prompt parts distribution through a highly efficient supply chain.
Reliable Used Dump Truck, Foton Hauler with Air Suspension Seat

Our Product
Reliable Used Dump Truck, Foton Hauler with Air Suspension Seat

Thank You for Choosing Us

Q: How about the delivery time?
A: We pride ourselves on swift delivery, with most trucks and machinery ready within just 7 days. For custom orders, our meticulous production process typically extends to 30 days, ensuring unmatched quality and excellence.

Q: How many units of truck do you produce per year?
A: Our impressive manufacturing prowess is highlighted by our annual production capacity of approximately 30,000 units, with around 5,000 units manufactured or updated monthly, maintaining a dynamic and highly efficient schedule.

Q: How do you control the quality of the product?
A: Quality is our top priority. Our facility boasts a state-of-the-art production workshop staffed by highly trained professionals. Each product undergoes rigorous inspection to ensure top-notch quality. We also recondition trucks and machinery on specialized production lines to uphold superior standards.

Q: Do you accept custom orders? What is your MOQ?
A: Absolutely, we warmly welcome custom orders to meet your specific needs. Our minimum order quantity (MOQ) is just 1 unit, demonstrating our adaptability and unwavering dedication to customer satisfaction.
