15500.000kg Package Gross Weight Foton Dumper with Air Suspension and Used Dump Truck

Certification
China Jining Huahang International Trade Co., Ltd. certification
China Jining Huahang International Trade Co., Ltd. certification
I'm Online Chat Now

15500.000kg Package Gross Weight Foton Dumper with Air Suspension and Used Dump Truck

15500.000kg Package Gross Weight Foton Dumper with Air Suspension and Used Dump Truck
15500.000kg Package Gross Weight Foton Dumper with Air Suspension and Used Dump Truck 15500.000kg Package Gross Weight Foton Dumper with Air Suspension and Used Dump Truck 15500.000kg Package Gross Weight Foton Dumper with Air Suspension and Used Dump Truck 15500.000kg Package Gross Weight Foton Dumper with Air Suspension and Used Dump Truck 15500.000kg Package Gross Weight Foton Dumper with Air Suspension and Used Dump Truck 15500.000kg Package Gross Weight Foton Dumper with Air Suspension and Used Dump Truck

Large Image :  15500.000kg Package Gross Weight Foton Dumper with Air Suspension and Used Dump Truck

Product Details:
Certification: SGS
Payment & Shipping Terms:
Delivery Time: 7-15days

15500.000kg Package Gross Weight Foton Dumper with Air Suspension and Used Dump Truck

Description
Model NO.: BJ3319Y6GRL-01 Power: Diesel
Load Capacity: 31-40t Emission Standard: Euro 6
Drive Wheel: 8×4 Seats: ≤5
Horsepower: 351-450hp Engine Capacity: >8L
Tire Certification: ECE, GCC, ISO, DOT Tire Design: Tubeless
Condition: New Usage: Towing Semi Trailer
Fuel Tank: 400L, 600L, 1000L Driver Seat: Air Suspension Seat
Color: Customized Cargo Box Material: Carbon Steel
Steering System: Hydraulic Steering With Power Assistance Transport Package: Nude Packing
Specification: 8.76x2.55x3.65 Trademark: Futian
Origin: China Liangshan HS Code: 87019090
Supply Ability: 1000pieces/Year Package Size: 876.00cm * 255.00cm * 365.00cm
Package Gross Weight: 15500.000kg After-sales Service: 6 Months
Warranty: 6 Months Transmission Type: Manual
Customization: Available | Customized Request Shipping Cost : About Shipping Cost And Estimated Delivery Time.
 : Initial Payment Full Payment Currency: US$
Return&refunds: You Can Apply For A Refund Up To 30 Days After Receipt Of The Products.

New Foton Dumper with Air Suspension, Efficient Used Dump Truck

Product Use

1. Definition of Tractor
A tractor, the epitome of robust versatility and unrivaled power, is a meticulously engineered light truck designed explicitly for the demanding task of towing vehicles or heavy loads across expansive highways. Equipped with an impressive array of multiple wheels and axles, it stands as a cornerstone in transporting semi-trailers, luxurious yachts, and massive construction equipment. As a fundamental pillar of heavy transport logistics, the tractor is indispensable across numerous industries, delivering unmatched reliability and extraordinary performance.
2. The Structure of the Tractor
Composed of vital components such as a potent engine, a sophisticated transmission system, durable tires, and a sturdy frame, a tractor is a testament to engineering excellence. Augmented with auxiliary features like robust tow hooks, cutting-edge locking systems, and user-friendly remote controls, it ensures superior operational efficiency and precision control, guaranteeing optimal performance in every endeavor.
3. Tractor Application Fields
1. Transportation: In the realm of long-distance freight, tractors are irreplaceable for towing semi-trailers and large trucks, ensuring the safe and reliable delivery of goods to their intended destinations with unwavering performance.
2. Construction Field: Tractors serve as indispensable tools in towing diverse construction machinery, including excavators, bulldozers, and cranes, facilitating the seamless transportation of heavy equipment to job sites and significantly boosting the efficiency of construction operations.

Basic Info.

New Foton Dumper with Air Suspension, Efficient Used Dump Truck
New Foton Dumper with Air Suspension, Efficient Used Dump Truck
New Foton Dumper with Air Suspension, Efficient Used Dump Truck



New Foton Dumper with Air Suspension, Efficient Used Dump Truck
New Foton Dumper with Air Suspension, Efficient Used Dump Truck
New Foton Dumper with Air Suspension, Efficient Used Dump Truck
New Foton Dumper with Air Suspension, Efficient Used Dump Truck
New Foton Dumper with Air Suspension, Efficient Used Dump Truck
New Foton Dumper with Air Suspension, Efficient Used Dump Truck


New Foton Dumper with Air Suspension, Efficient Used Dump Truck
New Foton Dumper with Air Suspension, Efficient Used Dump Truck
New Foton Dumper with Air Suspension, Efficient Used Dump Truck
Basic Information
Driving license: A1,A2,B2 Announcement Model: BJ3319Y6GRL-01
Drive type: 8X4 Wheelbase: 2100+2300+1400mm
engine: Foton DaimlerX12NS6B410 Gearbox: Fast 12JSD240A
Rear axle ratio: 5.92 Body length: 8.76 m
Body width: 2.55 m Ride height: 3.65 m
Front track: 2020/2020mm Rear track: 1880/1880mm
Vehicle weight: 15.5 tons Rated load: 15.37 tons
Total mass: 31 tons Tonnage level: Heavy Truck
Approach Angle: 18 degrees Departure angle: 16 degrees
Origin: Beijing Huairou Market Segments: Urban construction waste
Department: 9 Series Version: Basic
Fuel Type: diesel fuel
Engine parameters
Engine Model: Foton Daimler engineX12NS6B410 Engine Brand: Foton Daimler
Number of cylinders: 6 cylinders Fuel Type: diesel fuel
Displacement: 11.8L Emission standards: National VI
Maximum horsepower: 410 hp Maximum output power: 301kW
Maximum Torque: 2100Nm Maximum torque speed: 1000-1300rpm
Rated speed: 1900rpm
Cargo box parameters
Length of cargo box: 5.6 m Cargo box width: 2.35 m
Cargo box height: 1.5 m Cargo box form: Rear dump type
Cab parameters
Cab width: 2490mm
Gearbox parameters
Gearbox Model: Fast 12JSD240A Gearbox brand: Fast
Forward gears: 12 gears Reverse gear number: 2
tank
Fuel tank material: Aluminum Alloy Fuel tank capacity: 300L
Chassis parameters
Front axle description: 7.5T Permissible load on front axle: 6500/6500kg
Rear Axle Description: 16T Mercedes Benz Permissible load on rear axle: 18000(two-axle group)kg
Speed €atio: 5.92 Number of springs: 2010/10/12
tire
Tire specifications: 12.00R20 18PR Number of tires: 12
New Foton Dumper with Air Suspension, Efficient Used Dump Truck


Shipment

Our expertise in the art of truck shipping is unmatched, utilizing state-of-the-art RO-RO vessels or bulk carriers to ensure the utmost safety and efficiency. Additionally, we offer specialized container shipping, meticulously addressing a wide range of logistical requirements with unparalleled convenience.
New Foton Dumper with Air Suspension, Efficient Used Dump Truck


Original Spare Parts
We are committed to providing genuine spare parts, supported by a stellar after-sales service system. Our dedicated After-Market Division ensures exemplary service and swift parts delivery through a highly efficient supply chain.
New Foton Dumper with Air Suspension, Efficient Used Dump Truck

Our Product
New Foton Dumper with Air Suspension, Efficient Used Dump Truck

Thank You for Choosing Us

Q: How about the delivery time?
A: We take immense pride in our swift delivery capabilities, with the majority of trucks and machinery ready within an impressive 7 days. For custom orders, our meticulous production process generally extends to 30 days, ensuring unparalleled quality and excellence in every detail.

Q: How many units of truck do you produce per year?
A: Our formidable manufacturing prowess is evident in our annual production capacity of approximately 30,000 units, with an impressive 5,000 units updated or manufactured monthly, maintaining a dynamic and highly efficient schedule.

Q: How do you control the quality of the product?
A: Quality is our utmost priority. Our facility is equipped with a state-of-the-art production workshop staffed by expertly trained professionals. Each product undergoes rigorous inspection to ensure top-tier quality. We also recondition trucks and machinery on specialized production lines to uphold superior standards.

Q: Do you accept custom orders? What is your MOQ?
A: Absolutely, we eagerly welcome custom orders to meet your unique requirements. Our minimum order quantity (MOQ) is just 1 unit, showcasing our flexibility and unwavering commitment to customer satisfaction.
