Heavy Duty Foton Truck with Air Suspension and 1000L Fuel Tank Used Dump Truck Type

Certification
China Jining Huahang International Trade Co., Ltd. certification
China Jining Huahang International Trade Co., Ltd. certification
I'm Online Chat Now

Heavy Duty Foton Truck with Air Suspension and 1000L Fuel Tank Used Dump Truck Type

Heavy Duty Foton Truck with Air Suspension and 1000L Fuel Tank Used Dump Truck Type
Heavy Duty Foton Truck with Air Suspension and 1000L Fuel Tank Used Dump Truck Type Heavy Duty Foton Truck with Air Suspension and 1000L Fuel Tank Used Dump Truck Type Heavy Duty Foton Truck with Air Suspension and 1000L Fuel Tank Used Dump Truck Type Heavy Duty Foton Truck with Air Suspension and 1000L Fuel Tank Used Dump Truck Type Heavy Duty Foton Truck with Air Suspension and 1000L Fuel Tank Used Dump Truck Type Heavy Duty Foton Truck with Air Suspension and 1000L Fuel Tank Used Dump Truck Type

Large Image :  Heavy Duty Foton Truck with Air Suspension and 1000L Fuel Tank Used Dump Truck Type

Product Details:
Certification: SGS
Payment & Shipping Terms:
Delivery Time: 7-15days

Heavy Duty Foton Truck with Air Suspension and 1000L Fuel Tank Used Dump Truck Type

Description
Model NO.: BJ3319Y6GRL-01 Power: Diesel
Load Capacity: 31-40t Emission Standard: Euro 6
Drive Wheel: 8×4 Seats: ≤5
Horsepower: 351-450hp Engine Capacity: >8L
Tire Certification: ECE, GCC, ISO, DOT Tire Design: Tubeless
Condition: New Usage: Towing Semi Trailer
Fuel Tank: 400L, 600L, 1000L Driver Seat: Air Suspension Seat
Color: Customized Cargo Box Material: Carbon Steel
Steering System: Hydraulic Steering With Power Assistance Transport Package: Nude Packing
Specification: 8.76x2.55x3.65 Trademark: Futian
Origin: China Liangshan HS Code: 87019090
Supply Ability: 1000pieces/Year Package Size: 876.00cm * 255.00cm * 365.00cm
Package Gross Weight: 15500.000kg After-sales Service: 6 Months
Warranty: 6 Months Transmission Type: Manual
Customization: Available | Customized Request Shipping Cost : About Shipping Cost And Estimated Delivery Time.
 : Initial Payment Full Payment Currency: US$
Return&refunds: You Can Apply For A Refund Up To 30 Days After Receipt Of The Products.

Heavy Duty Foton Truck with Air Suspension, Used Dump Truck Type

Discover the Versatility of Our Products

1. Understanding the Tractor
A tractor epitomizes resilient adaptability and immense power. This expertly engineered light truck is tailored for the demanding role of towing vehicles or hefty loads along extensive highways. With its multitude of wheels and axles, it is pivotal in transporting semi-trailers, luxury yachts, and massive construction equipment. As a cornerstone in heavy transport logistics, it is essential across numerous sectors, delivering outstanding dependability and superior performance.
2. Anatomy of the Tractor
Built with integral elements such as a formidable engine, advanced transmission system, robust tires, and a solid frame, a tractor exemplifies engineering excellence. Augmented with additional features like strong tow hooks, cutting-edge locking systems, and user-friendly remote controls, it ensures top-tier operational efficiency and precision, guaranteeing peak performance in every activity it engages in.
3. Applications of Tractors
1. Freight Transportation: In the domain of long-haul transport, tractors are crucial for towing semi-trailers and large trucks. They ensure the dependable and secure delivery of cargo to their destinations with unmatched performance.
2. Construction Sector: Tractors play a crucial role in towing diverse construction machinery such as excavators, bulldozers, and cranes, facilitating the smooth movement of heavy equipment to work sites and greatly boosting construction efficiency.

Essential Information

Heavy Duty Foton Truck with Air Suspension, Used Dump Truck Type
Heavy Duty Foton Truck with Air Suspension, Used Dump Truck Type
Heavy Duty Foton Truck with Air Suspension, Used Dump Truck Type



Heavy Duty Foton Truck with Air Suspension, Used Dump Truck Type
Heavy Duty Foton Truck with Air Suspension, Used Dump Truck Type
Heavy Duty Foton Truck with Air Suspension, Used Dump Truck Type
Heavy Duty Foton Truck with Air Suspension, Used Dump Truck Type
Heavy Duty Foton Truck with Air Suspension, Used Dump Truck Type
Heavy Duty Foton Truck with Air Suspension, Used Dump Truck Type


Heavy Duty Foton Truck with Air Suspension, Used Dump Truck Type
Heavy Duty Foton Truck with Air Suspension, Used Dump Truck Type
Heavy Duty Foton Truck with Air Suspension, Used Dump Truck Type
Basic Information
Driving license: A1,A2,B2 Announcement Model: BJ3319Y6GRL-01
Drive type: 8X4 Wheelbase: 2100+2300+1400mm
engine: Foton DaimlerX12NS6B410 Gearbox: Fast 12JSD240A
Rear axle ratio: 5.92 Body length: 8.76 m
Body width: 2.55 m Ride height: 3.65 m
Front track: 2020/2020mm Rear track: 1880/1880mm
Vehicle weight: 15.5 tons Rated load: 15.37 tons
Total mass: 31 tons Tonnage level: Heavy Truck
Approach Angle: 18 degrees Departure angle: 16 degrees
Origin: Beijing Huairou Market Segments: Urban construction waste
Department: 9 Series Version: Basic
Fuel Type: diesel fuel
Engine parameters
Engine Model: Foton Daimler engineX12NS6B410 Engine Brand: Foton Daimler
Number of cylinders: 6 cylinders Fuel Type: diesel fuel
Displacement: 11.8L Emission standards: National VI
Maximum horsepower: 410 hp Maximum output power: 301kW
Maximum Torque: 2100Nm Maximum torque speed: 1000-1300rpm
Rated speed: 1900rpm
Cargo box parameters
Length of cargo box: 5.6 m Cargo box width: 2.35 m
Cargo box height: 1.5 m Cargo box form: Rear dump type
Cab parameters
Cab width: 2490mm
Gearbox parameters
Gearbox Model: Fast 12JSD240A Gearbox brand: Fast
Forward gears: 12 gears Reverse gear number: 2
tank
Fuel tank material: Aluminum Alloy Fuel tank capacity: 300L
Chassis parameters
Front axle description: 7.5T Permissible load on front axle: 6500/6500kg
Rear Axle Description: 16T Mercedes Benz Permissible load on rear axle: 18000(two-axle group)kg
Speed €atio: 5.92 Number of springs: 2010/10/12
tire
Tire specifications: 12.00R20 18PR Number of tires: 12
Heavy Duty Foton Truck with Air Suspension, Used Dump Truck Type


Shipping Solutions

Our exceptional expertise in truck shipping is unmatched, utilizing advanced RO-RO vessels or bulk vessels to guarantee maximum safety and efficiency. We also provide specialized container shipping, meticulously catering to an extensive array of logistical needs with utmost convenience.
Heavy Duty Foton Truck with Air Suspension, Used Dump Truck Type


Genuine Spare Parts
We are committed to offering authentic spare parts, supported by an outstanding after-sales service system. Our dedicated After-Market Division ensures exceptional service and swift parts delivery through a cutting-edge supply chain.
Heavy Duty Foton Truck with Air Suspension, Used Dump Truck Type

Our Product Line
Heavy Duty Foton Truck with Air Suspension, Used Dump Truck Type

Gratitude for Choosing Our Company

Q: What is the delivery timeline?
A: We are proud of our rapid delivery capabilities, with most trucks and machinery accessible within just 7 days. Custom orders undergo a meticulous production process spanning 30 days, ensuring unmatched quality and excellence.

Q: How many trucks are produced annually?
A: Our impressive manufacturing capability is evident in our yearly production capacity of about 30,000 units, with around 5,000 units updated or produced monthly, maintaining a dynamic and highly efficient schedule.

Q: How is product quality controlled?
A: Quality is our top priority. Our facility is equipped with a state-of-the-art production workshop, staffed by highly trained professionals. Each product undergoes comprehensive inspection to guarantee top-tier quality. We also refurbish trucks and machinery on specialized production lines to maintain superior standards.

Q: Are custom orders accepted? What is the MOQ?
A: Certainly, we eagerly welcome custom orders to meet your specific needs. Our minimum order quantity (MOQ) is just 1 unit, reflecting our flexibility and unwavering commitment to customer satisfaction.
