Foton Heavy Duty 8X4 Used Dump Truck with Air Suspension Seat Daimler Foton Tipper

Foton Heavy Duty 8X4 Used Dump Truck with Air Suspension Seat Daimler Foton Tipper
Foton Heavy Duty 8X4 Used Dump Truck with Air Suspension Seat Daimler Foton Tipper Foton Heavy Duty 8X4 Used Dump Truck with Air Suspension Seat Daimler Foton Tipper Foton Heavy Duty 8X4 Used Dump Truck with Air Suspension Seat Daimler Foton Tipper Foton Heavy Duty 8X4 Used Dump Truck with Air Suspension Seat Daimler Foton Tipper Foton Heavy Duty 8X4 Used Dump Truck with Air Suspension Seat Daimler Foton Tipper Foton Heavy Duty 8X4 Used Dump Truck with Air Suspension Seat Daimler Foton Tipper

Large Image :  Foton Heavy Duty 8X4 Used Dump Truck with Air Suspension Seat Daimler Foton Tipper

Product Details:
Certification: SGS
Payment & Shipping Terms:
Delivery Time: 7-15days

Foton Heavy Duty 8X4 Used Dump Truck with Air Suspension Seat Daimler Foton Tipper

Description
Model NO.: BJ3319Y6GRL-01 Power: Diesel
Load Capacity: 31-40t Emission Standard: Euro 6
Drive Wheel: 8×4 Seats: ≤5
Horsepower: 351-450hp Engine Capacity: >8L
Tire Certification: ECE, GCC, ISO, DOT Tire Design: Tubeless
Condition: New Usage: Towing Semi Trailer
Fuel Tank: 400L, 600L, 1000L Driver Seat: Air Suspension Seat
Color: Customized Cargo Box Material: Carbon Steel
Steering System: Hydraulic Steering With Power Assistance Transport Package: Nude Packing
Specification: 8.76x2.55x3.65 Trademark: Futian
Origin: China Liangshan HS Code: 87019090
Supply Ability: 1000pieces/Year Package Size: 876.00cm * 255.00cm * 365.00cm
Package Gross Weight: 15500.000kg After-sales Service: 6 Months
Warranty: 6 Months Transmission Type: Manual
Customization: Available | Customized Request Shipping Cost : About Shipping Cost And Estimated Delivery Time.
 : Initial Payment Full Payment Currency: US$
Return&refunds: You Can Apply For A Refund Up To 30 Days After Receipt Of The Products.

Foton Heavy Duty 8X4 Used Dump Truck with Air Suspension Seat Daimler Foton Tipper

Product Use

1. Definition of Tractor
A tractor, the epitome of robust versatility and unmatched power, is meticulously designed as a light truck to tow vehicles or heavy loads across vast highways. With an intricate array of multiple wheels and axles, it becomes an integral part of transporting semi-trailers, luxury yachts, and heavy construction equipment. As a cornerstone of heavy transport logistics, the tractor is indispensable across numerous industries, delivering outstanding reliability and superior performance.
2. The Structure of the Tractor
Comprising essential components such as a powerful engine, sophisticated transmission system, durable tires, and a sturdy frame, a tractor is a masterpiece of engineering. Augmented with auxiliary features like robust tow hooks, advanced locking systems, and intuitive remote controls, it promises operational efficiency and precision control, ensuring peak performance in every task it undertakes.
3. Tractor Application Fields
1. Transportation: Within long-distance freight realms, tractors are essential for towing semi-trailers and large trucks, ensuring the safe and reliable delivery of goods with unwavering performance to their destinations.
2. Construction Field: Tractors are vital in towing various construction machinery, including excavators, bulldozers, and cranes, facilitating the seamless transportation of heavy equipment to job sites, thereby significantly boosting the efficiency of construction operations.

Basic Info.

Foton Heavy Duty 8X4 Used Dump Truck with Air Suspension Seat Daimler Foton Tipper
Foton Heavy Duty 8X4 Used Dump Truck with Air Suspension Seat Daimler Foton Tipper
Foton Heavy Duty 8X4 Used Dump Truck with Air Suspension Seat Daimler Foton Tipper



Foton Heavy Duty 8X4 Used Dump Truck with Air Suspension Seat Daimler Foton Tipper
Foton Heavy Duty 8X4 Used Dump Truck with Air Suspension Seat Daimler Foton Tipper
Foton Heavy Duty 8X4 Used Dump Truck with Air Suspension Seat Daimler Foton Tipper
Foton Heavy Duty 8X4 Used Dump Truck with Air Suspension Seat Daimler Foton Tipper
Foton Heavy Duty 8X4 Used Dump Truck with Air Suspension Seat Daimler Foton Tipper
Foton Heavy Duty 8X4 Used Dump Truck with Air Suspension Seat Daimler Foton Tipper


Foton Heavy Duty 8X4 Used Dump Truck with Air Suspension Seat Daimler Foton Tipper
Foton Heavy Duty 8X4 Used Dump Truck with Air Suspension Seat Daimler Foton Tipper
Foton Heavy Duty 8X4 Used Dump Truck with Air Suspension Seat Daimler Foton Tipper
Basic Information
Driving license: A1,A2,B2 Announcement Model: BJ3319Y6GRL-01
Drive type: 8X4 Wheelbase: 2100+2300+1400mm
engine: Foton DaimlerX12NS6B410 Gearbox: Fast 12JSD240A
Rear axle ratio: 5.92 Body length: 8.76 m
Body width: 2.55 m Ride height: 3.65 m
Front track: 2020/2020mm Rear track: 1880/1880mm
Vehicle weight: 15.5 tons Rated load: 15.37 tons
Total mass: 31 tons Tonnage level: Heavy Truck
Approach Angle: 18 degrees Departure angle: 16 degrees
Origin: Beijing Huairou Market Segments: Urban construction waste
Department: 9 Series Version: Basic
Fuel Type: diesel fuel
Engine parameters
Engine Model: Foton Daimler engineX12NS6B410 Engine Brand: Foton Daimler
Number of cylinders: 6 cylinders Fuel Type: diesel fuel
Displacement: 11.8L Emission standards: National VI
Maximum horsepower: 410 hp Maximum output power: 301kW
Maximum Torque: 2100Nm Maximum torque speed: 1000-1300rpm
Rated speed: 1900rpm
Cargo box parameters
Length of cargo box: 5.6 m Cargo box width: 2.35 m
Cargo box height: 1.5 m Cargo box form: Rear dump type
Cab parameters
Cab width: 2490mm
Gearbox parameters
Gearbox Model: Fast 12JSD240A Gearbox brand: Fast
Forward gears: 12 gears Reverse gear number: 2
tank
Fuel tank material: Aluminum Alloy Fuel tank capacity: 300L
Chassis parameters
Front axle description: 7.5T Permissible load on front axle: 6500/6500kg
Rear Axle Description: 16T Mercedes Benz Permissible load on rear axle: 18000(two-axle group)kg
Speed €atio: 5.92 Number of springs: 2010/10/12
tire
Tire specifications: 12.00R20 18PR Number of tires: 12
Foton Heavy Duty 8X4 Used Dump Truck with Air Suspension Seat Daimler Foton Tipper


Shipment

Our expertise in truck shipping is unparalleled, utilizing state-of-the-art RO-RO vessels or bulk vessels to ensure maximum safety and efficiency. We also offer specialized container shipping, meticulously addressing a wide array of logistical needs with utmost convenience.
Foton Heavy Duty 8X4 Used Dump Truck with Air Suspension Seat Daimler Foton Tipper


Original Spare Parts
We are committed to offering genuine spare parts, backed by an exemplary after-sales service system. Our devoted After-Market Division ensures superior service and rapid parts delivery through a highly efficient supply chain.
Foton Heavy Duty 8X4 Used Dump Truck with Air Suspension Seat Daimler Foton Tipper

Our Product
Foton Heavy Duty 8X4 Used Dump Truck with Air Suspension Seat Daimler Foton Tipper

Thank You for Choosing Us

Q: How about the delivery time?
A: We take pride in our swift delivery capabilities, with most trucks and machinery ready within a brisk 7 days. For custom orders, our meticulous production process generally spans 30 days, ensuring unparalleled quality and excellence.

Q: How many units of truck do you produce per year?
A: Our formidable manufacturing prowess is evident in our annual production capacity of approximately 30,000 units, maintaining an efficient and dynamic schedule with around 5,000 units manufactured or updated monthly.

Q: How do you control the quality of the product?
A: Quality is our utmost priority. Our facility boasts a cutting-edge production workshop with expertly trained professionals. Each product undergoes thorough inspection to ensure top-tier quality, and we recondition trucks and machinery on specialized production lines to uphold superior standards.

Q: Do you accept custom orders? What is your MOQ?
A: Absolutely, we enthusiastically welcome custom orders to meet your unique needs. Our minimum order quantity (MOQ) is just 1 unit, demonstrating our adaptability and unwavering commitment to customer satisfaction.
