Manual Transmission Type Auman Tractor Truck with Air Suspension Used Dump Truck Model

Certification
China Jining Huahang International Trade Co., Ltd. certification
China Jining Huahang International Trade Co., Ltd. certification
I'm Online Chat Now

Manual Transmission Type Auman Tractor Truck with Air Suspension Used Dump Truck Model

Manual Transmission Type Auman Tractor Truck with Air Suspension Used Dump Truck Model
Manual Transmission Type Auman Tractor Truck with Air Suspension Used Dump Truck Model Manual Transmission Type Auman Tractor Truck with Air Suspension Used Dump Truck Model Manual Transmission Type Auman Tractor Truck with Air Suspension Used Dump Truck Model Manual Transmission Type Auman Tractor Truck with Air Suspension Used Dump Truck Model Manual Transmission Type Auman Tractor Truck with Air Suspension Used Dump Truck Model Manual Transmission Type Auman Tractor Truck with Air Suspension Used Dump Truck Model

Large Image :  Manual Transmission Type Auman Tractor Truck with Air Suspension Used Dump Truck Model

Product Details:
Certification: SGS
Payment & Shipping Terms:
Delivery Time: 7-15days

Manual Transmission Type Auman Tractor Truck with Air Suspension Used Dump Truck Model

Description
Model NO.: BJ3319Y6GRL-01 Power: Diesel
Load Capacity: 31-40t Emission Standard: Euro 6
Drive Wheel: 8×4 Seats: ≤5
Horsepower: 351-450hp Engine Capacity: >8L
Tire Certification: ECE, GCC, ISO, DOT Tire Design: Tubeless
Condition: New Usage: Towing Semi Trailer
Fuel Tank: 400L, 600L, 1000L Driver Seat: Air Suspension Seat
Color: Customized Cargo Box Material: Carbon Steel
Steering System: Hydraulic Steering With Power Assistance Transport Package: Nude Packing
Specification: 8.76x2.55x3.65 Trademark: Futian
Origin: China Liangshan HS Code: 87019090
Supply Ability: 1000pieces/Year Package Size: 876.00cm * 255.00cm * 365.00cm
Package Gross Weight: 15500.000kg After-sales Service: 6 Months
Warranty: 6 Months Transmission Type: Manual
Customization: Available | Customized Request Shipping Cost : About Shipping Cost And Estimated Delivery Time.
 : Initial Payment Full Payment Currency: US$
Return&refunds: You Can Apply For A Refund Up To 30 Days After Receipt Of The Products.

Auman Tractor Truck with Air Suspension, Used Dump Truck Model

Product Use

1. Definition of Tractor
A tractor stands as the epitome of robust versatility and unmatched power. This meticulously engineered light truck is crafted to master the formidable task of towing vehicles or heavy loads across expansive highways. Equipped with multiple wheels and axles, the tractor plays a pivotal role in transporting semi-trailers, luxury yachts, and hefty construction equipment. As a foundational element in heavy transport logistics, it is indispensable across numerous industries, delivering remarkable reliability and exceptional performance, making it an integral part of modern transportation.
2. The Structure of the Tractor
Comprising essential components such as a powerful engine, sophisticated transmission system, durable tires, and a robust frame, a tractor stands as a masterpiece of engineering ingenuity. Enhanced with auxiliary features like sturdy tow hooks, advanced locking systems, and intuitive remote controls, it ensures superior operational efficiency and precise control, guaranteeing optimal performance in every endeavor it undertakes.
3. Tractor Application Fields
1. Transportation: Within the realm of long-distance freight, tractors are indispensable, towing semi-trailers and large trucks with ease, ensuring the safe, reliable delivery of goods to their intended destinations while exhibiting unwavering performance.
2. Construction Field: Tractors serve as vital instruments in towing various construction machinery, such as excavators, bulldozers, and cranes, facilitating the seamless transportation of heavy equipment to job sites, significantly boosting the efficiency of construction operations.

Basic Info.

Auman Tractor Truck with Air Suspension, Used Dump Truck Model
Auman Tractor Truck with Air Suspension, Used Dump Truck Model
Auman Tractor Truck with Air Suspension, Used Dump Truck Model



Auman Tractor Truck with Air Suspension, Used Dump Truck Model
Auman Tractor Truck with Air Suspension, Used Dump Truck Model
Auman Tractor Truck with Air Suspension, Used Dump Truck Model
Auman Tractor Truck with Air Suspension, Used Dump Truck Model
Auman Tractor Truck with Air Suspension, Used Dump Truck Model
Auman Tractor Truck with Air Suspension, Used Dump Truck Model


Auman Tractor Truck with Air Suspension, Used Dump Truck Model
Auman Tractor Truck with Air Suspension, Used Dump Truck Model
Auman Tractor Truck with Air Suspension, Used Dump Truck Model
Basic Information
Driving license: A1,A2,B2 Announcement Model: BJ3319Y6GRL-01
Drive type: 8X4 Wheelbase: 2100+2300+1400mm
engine: Foton DaimlerX12NS6B410 Gearbox: Fast 12JSD240A
Rear axle ratio: 5.92 Body length: 8.76 m
Body width: 2.55 m Ride height: 3.65 m
Front track: 2020/2020mm Rear track: 1880/1880mm
Vehicle weight: 15.5 tons Rated load: 15.37 tons
Total mass: 31 tons Tonnage level: Heavy Truck
Approach Angle: 18 degrees Departure angle: 16 degrees
Origin: Beijing Huairou Market Segments: Urban construction waste
Department: 9 Series Version: Basic
Fuel Type: diesel fuel
Engine parameters
Engine Model: Foton Daimler engineX12NS6B410 Engine Brand: Foton Daimler
Number of cylinders: 6 cylinders Fuel Type: diesel fuel
Displacement: 11.8L Emission standards: National VI
Maximum horsepower: 410 hp Maximum output power: 301kW
Maximum Torque: 2100Nm Maximum torque speed: 1000-1300rpm
Rated speed: 1900rpm
Cargo box parameters
Length of cargo box: 5.6 m Cargo box width: 2.35 m
Cargo box height: 1.5 m Cargo box form: Rear dump type
Cab parameters
Cab width: 2490mm
Gearbox parameters
Gearbox Model: Fast 12JSD240A Gearbox brand: Fast
Forward gears: 12 gears Reverse gear number: 2
tank
Fuel tank material: Aluminum Alloy Fuel tank capacity: 300L
Chassis parameters
Front axle description: 7.5T Permissible load on front axle: 6500/6500kg
Rear Axle Description: 16T Mercedes Benz Permissible load on rear axle: 18000(two-axle group)kg
Speed €atio: 5.92 Number of springs: 2010/10/12
tire
Tire specifications: 12.00R20 18PR Number of tires: 12
Auman Tractor Truck with Air Suspension, Used Dump Truck Model


Shipment

Our expertise in the art of truck shipping is unmatched, utilizing state-of-the-art RO-RO vessels or bulk vessels to ensure maximum safety and efficiency. Additionally, we offer specialized container shipping, meticulously addressing a wide array of logistical requirements with utmost convenience and precision.
Auman Tractor Truck with Air Suspension, Used Dump Truck Model


Original Spare Parts
We are committed to providing authentic spare parts, supported by an exemplary after-sales service system. Our dedicated After-Market Division ensures outstanding service and rapid parts delivery through a highly efficient supply chain, ensuring your operations remain uninterrupted.
Auman Tractor Truck with Air Suspension, Used Dump Truck Model

Our Product
Auman Tractor Truck with Air Suspension, Used Dump Truck Model

Thank You for Choosing Us

Q: How about the delivery time?
A: We take pride in our swift delivery capabilities, with most trucks and machinery ready within just 7 days. For custom orders, our meticulous production process extends to 30 days, guaranteeing unparalleled quality and excellence in every detail.

Q: How many units of truck do you produce per year?
A: Our formidable manufacturing prowess is showcased by our annual production capacity of approximately 30,000 units, with an estimated 5,000 units updated or manufactured monthly, maintaining a dynamic and highly efficient production schedule.

Q: How do you control the quality of the product?
A: Quality is our utmost priority. Our facility features a cutting-edge production workshop staffed by expertly trained professionals. Every product undergoes thorough inspection to ensure top-tier quality. We also recondition trucks and machinery on specialized production lines to uphold superior standards and deliver exceptional products.

Q: Do you accept custom orders? What is your MOQ?
A: Absolutely, we enthusiastically welcome custom orders to fulfill your unique requirements. Our minimum order quantity (MOQ) is just 1 unit, demonstrating our adaptability and unwavering commitment to customer satisfaction, ensuring your needs are met with precision and care.
