| Model NO.: | ZZ4257N3247E1H | Power: | Diesel |
|---|---|---|---|
| Load Capacity: | 31-40t | Emission Standard: | Euro4/Euro5/Euro6 |
| Drive Wheel: | 6×4 | Seats: | ≤5 |
| Horsepower: | 351-450hp | Engine Capacity: | >8L |
| Tire Certification: | ECE, GCC, ISO, DOT | Tire Design: | Tubeless |
| Condition: | New | Usage: | Towing Semi Trailer |
| Fuel Tank: | 400L, 600L, 1000L | Driver Seat: | Air Suspension Seat |
| Color: | Customized | Cargo Box Material: | Carbon Steel |
| Steering System: | Hydraulic Steering With Power Assistance | Transport Package: | Nude Packing |
| Specification: | 6.8x2.5x3.8m | Trademark: | J6P |
| Origin: | China Shandong | HS Code: | 8708991000 |
| Supply Ability: | 1000pieces/Year | Package Size: | 705.00cm * 255.00cm * 398.00cm |
| Package Gross Weight: | 8005.000kg | After-sales Service: | 6 Months |
| Warranty: | 6 Months | Transmission Type: | Manual |
| Customization: | Available | Customized Request | Shipping Cost : | About Shipping Cost And Estimated Delivery Time. |
| : | Initial Payment Full Payment | Currency: | US$ |
| Return&refunds: | You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
| Basic Information | |||
| driver license: | A2 | Announcement Model: | CA4250P66K24T1A1E5 |
| Drive type: | 6X4 | Wheelbase: | 3450+1350mm |
| engine: | Xichai CA6DM2-42E51 | Gearbox: | FAW Jiefang CA12TAX210M |
| Rear axle ratio: | 4.111 | Body length: | 7.05m |
| Body width: | 2.55 m | Ride height: | 3.98 m |
| Front track: | 2056mm | Rear track: | 1852/1852mm |
| Vehicle weight: | 8.805 tons | Total mass: | 25 tons |
| Total traction mass: | 40 tons | Maximum speed: | 120km/h |
| Market segments: | shandongjinan | Origin: | Changchun/Qingdao/Chengdu |
| Engine parameters | |||
| engine model: | Xichai CA6DM2-42E51 | Engine Brand: | Xichai |
| Number of cylinders: | 6 cylinders | Fuel type: | diesel fuel |
| Cylinder arrangement: | In-line | Displacement: | 11.05L |
| Emission Standards: | National Five | Maximum horsepower: | 420 hp |
| Maximum output power: | 312kW | Maximum Torque: | 1900Nm |
| Maximum torque speed: | 1100-1400rpm | Rated speed: | 1900rpm |
| Engine oil change cycle: | 100,000 km long oil change cycle | ||
| Cab parameters | |||
| Upper berth width: | 750mm | Lower berth width: | 850mm |
| Number of passengers allowed: | 3 people | Number of Seat Rows: | Half row |
| Gearbox parameters | |||
| Gearbox Model: | FAW Jiefang CA12TAX210M | Gearbox brand: | FAW Jiefang |
| Shifting method: | Manual | Forward gears: | 12 gears |
| Reverse gear number: | 2 | Shell Material: | Aluminum Alloy |
| Transmission oil change cycle: | 200,000/500,000 km long oil change cycle | ||
| tank | |||
| Fuel tank/gas tank material: | Aluminum Alloy | Fuel tank capacity: | 600L |
| Chassis parameters | |||
| Rear Axle Description: | 457 punching and welding bridge | Permissible load on front axle: | 7000kg |
| Permissible load on rear axle: | 18000(two-axle group)kg | Speed €atio: | 4.111 |
| Number of springs: | 3/4,10/11,11/12,12/12,3/- | Steering gear: | Domestic |
| tire | |||
| Number of tires: | 10 | Tire specifications: | 11.00R20 16PR |
