Model NO.: | Delong | Power: | Diesel |
---|---|---|---|
Load Capacity: | 31-40t | Emission Standard: | Euro6 |
Drive Wheel: | 6×4 | Seats: | ≤5 |
Horsepower: | 351-450hp | Engine Capacity: | >8L |
Tire Certification: | ECE, GCC, ISO, DOT | Tire Design: | Tubeless |
Condition: | New | Usage: | Towing Semi Trailer |
Fuel Tank: | 400L, 600L, 1000L | Driver Seat: | Air Suspension Seat |
Color: | Red | Cargo Box Material: | Carbon Steel |
Steering System: | Hydraulic Steering With Power Assistance | Transport Package: | Nude Packing |
Specification: | 6.775x2.5x3.58m | Trademark: | SHACMAN |
Origin: | China Liangshan | HS Code: | 8708991000 |
Supply Ability: | 1000pieces/Year | Package Size: | 677.00cm * 250.00cm * 358.00cm |
Package Gross Weight: | 8200.000kg | After-sales Service: | 6 Months |
Warranty: | 6 Months | Transmission Type: | Automatic |
Customization: | Available | Customized Request | Shipping Cost : | About Shipping Cost And Estimated Delivery Time. |
: | Initial Payment Full Payment | Currency: | US$ |
Return&refunds: | You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
Basic Information | |||
Driving license: | A2 | Announcement Model: | SX4250X3L |
Drive type: | 6X4 | Wheelbase: | 3175+1350mm |
engine: | Xi'an Cummins ISM11E5 440 | Gearbox: | Fast 12JSD200TA |
Rear axle ratio: | 4.266 | Body length: | 6.775 m |
Body width: | 2.5 m | Ride height: | 3.58 m |
Front track: | 1940mm | Rear track: | 1800mm |
Vehicle weight: | 8.2 tons | Total mass: | 25 tons |
Total traction mass: | 40 tons | Maximum speed: | 105km/h |
Market Segments: | Coal Transportation | Origin: | Shandongjinan |
Tonnage level: | Heavy Truck | Fuel Type: | diesel fuel |
Engine parameters | |||
Engine Model: | Xi'an Cummins ISM11E5 440 | Engine Brand: | Xi'an Cummins |
Number of cylinders: | 6 cylinders | Fuel Type: | diesel fuel |
Cylinder arrangement: | series | Displacement: | 10.8L |
Emission standards: | National Five | Maximum horsepower: | 440 hp |
Maximum output power: | 324kW | Maximum Torque: | 2150Nm |
Maximum torque speed: | 1100-1300rpm | Rated speed: | 1900rpm |
Cab parameters | |||
Number of passengers allowed: | 3 people | Number of Seat Rows: | Half row |
Gearbox parameters | |||
Gearbox Model: | Fast 12JSD200TA | Gearbox brand: | Fast |
Shifting method: | Manual | Forward gears: | 12 gears |
Number of downs: | 2 | Shell Material: | Aluminum Alloy |
Chassis parameters | |||
Frame size: | 270/8+4 double layer mm | Rear Axle Description: | 13TMAN Double Level |
Permissible load on front axle: | 18000(two-axle group)kg | Permissible load on rear axle: | 7000kg |
Speed €atio: | 4.266 | Number of springs: | 2.4 |
tire | |||
Number of tires: | 10 | Tire specifications: | 12.00R20 |
