Product Use
1. Definition of Tractor
A tractor is a marvel of engineering and an unrivaled powerhouse in the realm of transport, meticulously engineered to accommodate the towing of an array of vehicles and objects. Equipped with multiple pairs of wheels and axles, it forms the backbone of heavy-duty transportation, indispensable for towing semi-trailers, luxury yachts, construction equipment, and more. Tractors are vital across numerous industries, ensuring the seamless, secure, and reliable transport of large loads.
2. Structure of the Tractor
The heart of a tractor lies in its robust structure, comprising essential components like the engine, transmission, tires, and frame. For superior operability and precision control, additional features such as tow hooks, locking systems, and remote controls can be impeccably integrated, greatly enhancing its performance and versatility.
3. Tractor Application Fields
1. Transportation: For long-haul freight, tractors are key assets, primarily used to tow semi-trailers and other large trucks, ensuring the safe and efficient delivery of goods over long distances.
2. Construction Field: Within the construction arena, tractors are indispensable for moving heavy machinery like excavators, bulldozers, and cranes to job sites, streamlining operations and boosting productivity.
Basic Info.
| Basic Information | | | |
| Driving license: | A2 | Announcement Model: | SX4250X3L |
| Drive type: | 6X4 | Wheelbase: | 3175+1350mm |
| engine: | Xi'an Cummins ISM11E5 440 | Gearbox: | Fast 12JSD200TA |
| Rear axle ratio: | 4.266 | Body length: | 6.775 m |
| Body width: | 2.5 m | Ride height: | 3.58 m |
| Front track: | 1940mm | Rear track: | 1800mm |
| Vehicle weight: | 8.2 tons | Total mass: | 25 tons |
| Total traction mass: | 40 tons | Maximum speed: | 105km/h |
| Market Segments: | Coal Transportation | Origin: | Shandongjinan |
| Tonnage level: | Heavy Truck | Fuel Type: | diesel fuel |
| Engine parameters | | | |
| Engine Model: | Xi'an Cummins ISM11E5 440 | Engine Brand: | Xi'an Cummins |
| Number of cylinders: | 6 cylinders | Fuel Type: | diesel fuel |
| Cylinder arrangement: | series | Displacement: | 10.8L |
| Emission standards: | National Five | Maximum horsepower: | 440 hp |
| Maximum output power: | 324kW | Maximum Torque: | 2150Nm |
| Maximum torque speed: | 1100-1300rpm | Rated speed: | 1900rpm |
| Cab parameters | | | |
| Number of passengers allowed: | 3 people | Number of Seat Rows: | Half row |
| Gearbox parameters | | | |
| Gearbox Model: | Fast 12JSD200TA | Gearbox brand: | Fast |
| Shifting method: | Manual | Forward gears: | 12 gears |
| Number of downs: | 2 | Shell Material: | Aluminum Alloy |
| Chassis parameters | | | |
| Frame size: | 270/8+4 double layer mm | Rear Axle Description: | 13TMAN Double Level |
| Permissible load on front axle: | 18000(two-axle group)kg | Permissible load on rear axle: | 7000kg |
| Speed €atio: | 4.266 | Number of springs: | 2.4 |
| tire | | | |
| Number of tires: | 10 | Tire specifications: | 12.00R20 |
Our Factory
Shipment
We offer shipping solutions that encompass RO-RO vessel or bulk vessel, ensuring reliable and efficient transportation. For unique requirements, our container shipping options provide added convenience and adaptability.
Original Spare Parts
We provide authentic spare parts supported by a thorough after-sales service framework. Our After-market Division is dedicated to delivering exceptional service, leveraging an efficient supply chain to guarantee prompt parts delivery and enhance customer satisfaction.
Our Product
Thank You for Choosing Us
Q: How about the delivery time?
A: A majority of our trucks and machinery are available in stock, ready for shipment within 7 days. For custom or special orders, the production timeline is approximately 30 days, guaranteeing quality and precision in every detail.
Q: How many units of trucks do you produce annually?
A: We take pride in producing about 30,000 units each year, maintaining a strong production cadence with a monthly refresh rate of approximately 5,000 units, underscoring our dedication to excellence and market needs.
Q: How do you ensure product quality?
A: Our factory upholds rigorous production standards, staffed by highly skilled workers. Every product undergoes a thorough inspection process to ensure that all trucks and machinery are expertly reconditioned, maintaining superior quality benchmarks.
Q: Do you accept custom orders? What is your MOQ?
A: Absolutely, we gladly accept custom orders with a flexible minimum order quantity (MOQ) of just one unit, offering tailored service to accommodate your specific requirements.
