Product Use
1. Definition of Tractor
A tractor is the epitome of versatility and high performance, meticulously engineered to haul a vast array of vehicles or objects with ease. Equipped with multiple sets of wheels and axles, it becomes an essential powerhouse in industries, adeptly towing semi-trailers, luxury yachts, and construction machinery among others. As the backbone of heavy-duty transport operations, tractors dominate with their indispensable capability to efficiently and securely transport large loads, delivering unwavering reliability across diverse sectors.
2. Structure of the Tractor
At the heart of any tractor lies its core structure, comprising essential components including the engine, transmission, tires, and frame. For enhanced functionality and precision control, optional enhancements such as tow hooks, locking mechanisms, and remote controls can be effortlessly integrated, significantly amplifying the tractor's overall performance and utility.
3. Tractor Application Fields
1. Transportation: In the realm of long-distance freight, tractors prove to be invaluable assets. They are primarily used to tow semi-trailers and other substantial trucks, ensuring that goods are delivered securely and efficiently over long distances, thus streamlining logistical operations.
2. Construction Field: Within the construction sector, tractors are indispensable for the transport of heavy machinery, including excavators, bulldozers, and cranes to various job sites. This ensures unrivaled efficiency and productivity, making them a cornerstone in construction logistics.
Basic Info.
| Basic Information | | | |
| Driving license: | A2 | Announcement Model: | SX4250X3L |
| Drive type: | 6X4 | Wheelbase: | 3175+1350mm |
| engine: | Xi'an Cummins ISM11E5 440 | Gearbox: | Fast 12JSD200TA |
| Rear axle ratio: | 4.266 | Body length: | 6.775 m |
| Body width: | 2.5 m | Ride height: | 3.58 m |
| Front track: | 1940mm | Rear track: | 1800mm |
| Vehicle weight: | 8.2 tons | Total mass: | 25 tons |
| Total traction mass: | 40 tons | Maximum speed: | 105km/h |
| Market Segments: | Coal Transportation | Origin: | Shandongjinan |
| Tonnage level: | Heavy Truck | Fuel Type: | diesel fuel |
| Engine parameters | | | |
| Engine Model: | Xi'an Cummins ISM11E5 440 | Engine Brand: | Xi'an Cummins |
| Number of cylinders: | 6 cylinders | Fuel Type: | diesel fuel |
| Cylinder arrangement: | series | Displacement: | 10.8L |
| Emission standards: | National Five | Maximum horsepower: | 440 hp |
| Maximum output power: | 324kW | Maximum Torque: | 2150Nm |
| Maximum torque speed: | 1100-1300rpm | Rated speed: | 1900rpm |
| Cab parameters | | | |
| Number of passengers allowed: | 3 people | Number of Seat Rows: | Half row |
| Gearbox parameters | | | |
| Gearbox Model: | Fast 12JSD200TA | Gearbox brand: | Fast |
| Shifting method: | Manual | Forward gears: | 12 gears |
| Number of downs: | 2 | Shell Material: | Aluminum Alloy |
| Chassis parameters | | | |
| Frame size: | 270/8+4 double layer mm | Rear Axle Description: | 13TMAN Double Level |
| Permissible load on front axle: | 18000(two-axle group)kg | Permissible load on rear axle: | 7000kg |
| Speed €atio: | 4.266 | Number of springs: | 2.4 |
| tire | | | |
| Number of tires: | 10 | Tire specifications: | 12.00R20 |
