| Model NO.: | 6x4 Dump Truck | Power: | Diesel |
|---|---|---|---|
| Load Capacity: | 31-40t | Emission Standard: | Euro6 |
| Drive Wheel: | 6×4 | Engine Capacity: | >8L |
| Seats: | ≤5 | Horsepower: | 700HP |
| Tire Certification: | ECE, GCC, ISO, DOT | Tire Design: | Tubeless |
| Dumping Type: | Front Lifting Style | Condition: | New |
| Tyre: | New | Steering System: | Hydraulic Steering With Power Assistance |
| Chassis Brand: | Sinotruk Chassis | Color: | Customized |
| Cargo Box Material: | Carbon Steel | Transport Package: | Naked Packing |
| Specification: | 7.81m*2.53m*3.98m | Trademark: | Haowo |
| Origin: | Shandong China | HS Code: | 8708991000 |
| Supply Ability: | 1000pieces/Year | Package Size: | 781.00cm * 253.00cm * 398.00cm |
| Package Gross Weight: | 8800.000kg | After-sales Service: | 6 Months |
| Warranty: | 6 Months | Transmission Type: | Manual |
| Customization: | Available | Customized Request | Shipping Cost : | About Shipping Cost And Estimated Delivery Time. |
| : | Initial Payment Full Payment | Currency: | US$ |
| Return&refunds: | You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
| Basic Information | |||
| Driving license: | A2 | Announcement Model: | ZZ4257V424KF1LT |
| Drive type: | 6X4 | Wheelbase: | 3825+1350mm |
| engine: | Weichai WP13NG540E60 | Gearbox: | Fast F16JZ24A |
| Rear axle ratio: | 3.36 | Body length: | 7.815 m |
| Body width: | 2.53 m | Ride height: | 3.98 m |
| Front track: | 2022mm | Rear track: | 1860/1860mm |
| Vehicle weight: | 9.6 tons | Total mass: | 25 tons |
| Total traction mass: | 40 tons | Maximum speed: | 89km/h |
| Origin: | Jinan, Shandong | Tonnage level: | Heavy Truck |
| Fuel Type: | Liquefied Natural Gas (LNG) | ||
| Engine parameters | |||
| Engine Model: | Weichai WP13NG540E60 | Engine Brand: | Weichai |
| Number of cylinders: | 6 cylinders | Fuel Type: | Liquefied Natural Gas (LNG) |
| Cylinder arrangement: | In-line | Displacement: | 13.26L |
| Emission standards: | National VI | Maximum horsepower: | 540 hp |
| Maximum output power: | 397kW | Maximum Torque: | 2300Nm |
| Maximum torque speed: | 800-1300rpm | Rated speed: | 1900rpm |
| Cab parameters | |||
| Cab suspension: | Four-point airbag suspension | Number of passengers allowed: | 2 people |
| Number of Seat Rows: | Half row | ||
| Gearbox parameters | |||
| Gearbox Model: | Fast F16JZ24A | Gearbox brand: | Fast |
| Shifting method: | AMT | Forward gears: | 16 levels |
| Reverse gear number: | 2 | ||
| tank | |||
| Gas tank capacity: | 1500L | ||
| Chassis parameters | |||
| Permissible load on front axle: | 7000kg | Permissible load on rear axle: | 18000(two-axle group)kg |
| Speed €atio: | 3.36 | ||
| tire | |||
| Number of tires: | 10 | Tire specifications: | 12R22.5 18PR |
