Model NO.: | 6x4 Dump Truck | Power: | Diesel |
---|---|---|---|
Load Capacity: | 31-40t | Emission Standard: | Euro6 |
Drive Wheel: | 6×4 | Engine Capacity: | >8L |
Seats: | ≤5 | Horsepower: | 351-450hp |
Tire Certification: | ECE, GCC, ISO, DOT | Tire Design: | Tubeless |
Dumping Type: | Front Lifting Style | Condition: | New |
Tyre: | New | Steering System: | Hydraulic Steering With Power Assistance |
Chassis Brand: | Sinotruk Chassis | Color: | Customized |
Cargo Box Material: | Carbon Steel | Transport Package: | Naked Packing |
Specification: | 7.81m*2.53m*3.98m | Trademark: | Haowo |
Origin: | Shandong China | HS Code: | 8708991000 |
Supply Ability: | 1000pieces/Year | Package Size: | 781.00cm * 253.00cm * 398.00cm |
Package Gross Weight: | 8800.000kg | After-sales Service: | 6 Months |
Warranty: | 6 Months | Transmission Type: | Manual |
Customization: | Available | Customized Request | Shipping Cost : | About Shipping Cost And Estimated Delivery Time. |
: | Initial Payment Full Payment | Currency: | US$ |
Return&refunds: | You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
Basic Information | |||
Driving license: | A2 | Announcement Model: | ZZ4256V384HF1LB |
Drive type: | 6X4 | Gearbox: | ZF ZF16S2530 TO |
Rear axle ratio: | 3.7 | Origin: | Zhangqiu, Shandong |
Tonnage level: | Heavy Truck | Remark: | TGA Technology Frame-Version B |
Version: | LNG version | Fuel Type: | Liquefied Natural Gas (LNG) |
Engine parameters | |||
Engine Model: | Sinotruk MT13.48-60 | Engine Brand: | Sinotruk |
Number of cylinders: | 6 cylinders | Fuel Type: | Liquefied Natural Gas (LNG) |
Cylinder arrangement: | In-line | Displacement: | 12.419L |
Emission standards: | Euro 6 | Maximum horsepower: | 390 hp |
Maximum output power: | 356kW | Maximum Torque: | 2200Nm |
Maximum torque speed: | 1000-1400rpm | Rated speed: | 1900rpm |
Cab parameters | |||
Cab: | High Top | Number of passengers allowed: | 3 people |
Number of Seat Rows: | Half row | ||
Gearbox parameters | |||
Gearbox Model: | ZF ZF16S2530TO | Gearbox brand: | ZF |
Shifting method: | Manual | Forward gears: | 16 levels |
Reverse gear number: | 2 | ||
tank | |||
Fuel tank capacity: | 995L | ||
Chassis parameters | |||
Front axle description: | HR7 | Rear Axle Description: | MCY13 double rear axle |
Speed €atio: | 3.7 | Number of springs: | 3/-/- |
Suspension type (front/rear): | Front less, rear full air suspension | Saddle: | 90# |
tire | |||
Tire Brand: | Chaoyang | Number of tires: | 10 |
Tire specifications: | 295/80R22.5 |
