| Model NO.: | 6x4 Dump Truck | Power: | Diesel |
|---|---|---|---|
| Load Capacity: | 31-40t | Emission Standard: | Euro6 |
| Drive Wheel: | 6×4 | Engine Capacity: | >8L |
| Seats: | ≤5 | Horsepower: | 351-450hp |
| Tire Certification: | ECE, GCC, ISO, DOT | Tire Design: | Tubeless |
| Dumping Type: | Front Lifting Style | Condition: | New |
| Tyre: | New | Steering System: | Hydraulic Steering With Power Assistance |
| Chassis Brand: | Sinotruk Chassis | Color: | Customized |
| Cargo Box Material: | Carbon Steel | Transport Package: | Naked Packing |
| Specification: | 7.81m*2.53m*3.98m | Trademark: | Haowo |
| Origin: | Shandong China | HS Code: | 8708991000 |
| Supply Ability: | 1000pieces/Year | Package Size: | 781.00cm * 253.00cm * 398.00cm |
| Package Gross Weight: | 8800.000kg | After-sales Service: | 6 Months |
| Warranty: | 6 Months | Transmission Type: | Manual |
| Customization: | Available | Customized Request | Shipping Cost : | About Shipping Cost And Estimated Delivery Time. |
| : | Initial Payment Full Payment | Currency: | US$ |
| Return&refunds: | You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
| Basic Information | |||
| Driving license: | A2 | Announcement Model: | ZZ4256V384HF1LB |
| Drive type: | 6X4 | Gearbox: | ZF ZF16S2530 TO |
| Rear axle ratio: | 3.7 | Origin: | Zhangqiu, Shandong |
| Tonnage level: | Heavy Truck | Remark: | TGA Technology Frame-Version B |
| Version: | LNG version | Fuel Type: | Liquefied Natural Gas (LNG) |
| Engine parameters | |||
| Engine Model: | Sinotruk MT13.48-60 | Engine Brand: | Sinotruk |
| Number of cylinders: | 6 cylinders | Fuel Type: | Liquefied Natural Gas (LNG) |
| Cylinder arrangement: | In-line | Displacement: | 12.419L |
| Emission standards: | Euro 6 | Maximum horsepower: | 390 hp |
| Maximum output power: | 356kW | Maximum Torque: | 2200Nm |
| Maximum torque speed: | 1000-1400rpm | Rated speed: | 1900rpm |
| Cab parameters | |||
| Cab: | High Top | Number of passengers allowed: | 3 people |
| Number of Seat Rows: | Half row | ||
| Gearbox parameters | |||
| Gearbox Model: | ZF ZF16S2530TO | Gearbox brand: | ZF |
| Shifting method: | Manual | Forward gears: | 16 levels |
| Reverse gear number: | 2 | ||
| tank | |||
| Fuel tank capacity: | 995L | ||
| Chassis parameters | |||
| Front axle description: | HR7 | Rear Axle Description: | MCY13 double rear axle |
| Speed €atio: | 3.7 | Number of springs: | 3/-/- |
| Suspension type (front/rear): | Front less, rear full air suspension | Saddle: | 90# |
| tire | |||
| Tire Brand: | Chaoyang | Number of tires: | 10 |
| Tire specifications: | 295/80R22.5 |
